NuTone 1055 Specification Sheet

MODELS 1055 & 1059
TRASH COMPACTOR
MODEL 1055 BLACK
MODEL 1059 WHITE
The same powerful mechanism used in our deluxe
compactors - in a space-saving housing with drawer
latch.
FEATURES
Up to 5000 lbs. of compacting force
•
Patented double scissors ram
•
Compacts the equivalent of fourteen (14) 13-gallon trash
•
containers into one easy, disposable bag
Key operated switch for safety
•
Space-saving 12" wide design
•
Convenient swing open door for trash unloading
•
Air Scentry™ - accepts most popular solid deodorizers
•
with self adhesive
Four adjustable leveling legs
•
Reversible door panels offer choice of colors:
•
Black/Biscuit – Model 1055
Black/White – Model 1059
Safety latch – keeps drawer locked when closed
•
No. 93620008 reinforced plastic replacement bags (avail-
•
able twelve (12) to a pack)
Model 1004 Hardwood cutting board top (available
•
separately)
SPECIFICATIONS
VOLTS Hz AMPS CAPACITY
120 60 5.0 1.4 cu. ft. bin
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
REFERENCE QTY.
COMPACTION WEIGHT
Up to 5000 lbs. 128 lbs.
(incl. carton)
REMARKS
SPECIFICATION SHEET
TYPICAL SPECIFICATION
Trash compactor shall be Broan Model 1055 (Model 1059).
Unit shall produce up to 5000 lbs. of compacting force.
Compactor shall be 12" wide and installed (under countertop)
(freestanding). Door panels to offer two color choices.
Unit shall have a key switch, a deodorizing panel feature and
drawer latch.
Compactor to operate on 120 VAC, 60 Hz and not to exceed
5 AMPS. Unit to be U.L. listed.
Project
Location
Architect
Engineer
Contractor
Submitted by
30A
optional
*
cutting board
Date
99041310E
