TRASH
COMPACTORS
The industry's highest compaction force, narrow
cabinet width and deluxe features make the 1052
THE choice in home compactors.
FEATURES
Up to 5000 lbs. of compacting force
Patented double scissors ram
Compacts the equivalent of fourteen (14) 13-gallon trash
containers into one easy, disposable bag
Space-saving 12" wide design
Key operated switch for safety
Convenient swing open door for trash unloading
Bag storage compartment
Air Scentry
- accepts most popular solid deodorizers with
self/adhesive
Four adjustable leveling legs
Door panels offer choice of three decorative finishes:
Polished Stainless Steel (301 Grade) – Model 1052
Black/Biscuit – Model 1050
Black/White – Model 1051
Textured cabinet features a durable baked enamel finish
in Black
No. 93620008 reinforced plastic replacement bags
(available twelve (12) to a pack)
Model 1004 Hardwood cutting board top (available
separately)
Hands-free, toe pedal drawer opening (Models 1050 &
1051)
SPECIFICATIONS
VOLTS
Hz
AMPS
CAPACITY
120
60
5.0
1.4 cu. ft. bin
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
REFERENCE
QTY.
MODELS
1050 & 1051
COMPACTION
WEIGHT
Up to 5000 lbs.
134 lbs.
(incl. carton)
REMARKS
SPECIFICATION SHEET
TYPICAL SPECIFICATION
Trash compactor shall be Broan Model 1050 (Model 1051)
(Model 1052).
Unit shall produce up to 5000 lbs. of compacting force.
Compactor shall be 12" wide and installed (flush with
countertop) (freestanding). Door panel to be 24 ga. 304
stainless steel (Model 1052) or two colors (Model 1050)
(Model 1051).
Unit shall have a key switch and a deodorizing panel feature.
Compactor to operate on 120 VAC, 60 Hz and not to exceed
5 AMPS. Unit to be U.L. and C.S.A. listed.
Project
Location
Architect
Engineer
Contractor
Submitted by
30A
MODEL
1052
optional
*
cutting board
Date
99042244D
