MODELS 1050L & 1051L
TRASH COMPACTOR
All of Broan's industry-leading features plus a
drawer latch - meets all your installation
requirements.
FEATURES
Up to 5000 lbs. of compacting force
Patented double scissors ram
Compacts the equivalent of fourteen (14) 13-gallon trash
containers into one easy, disposable bag
Space-saving 12" wide design
Key operated switch for safety
Convenient swing open door for trash unloading
Bag storage compartment
Air Scentry
- accepts most popular solid deodorizers with
self adhesive
Four adjustable leveling legs
Door panels offer choice of two decorative finishes:
Black/Biscuit – Model 1050L
Black/White – Model 1051L
Textured cabinet features a durable baked enamel finish
in Black
Safety latch - keeps drawer locked when closed
No. 93620008 reinforced plastic replacement bags
(available twelve (12) to a pack)
Model 1004 Hardwood cutting board top (available
separately)
SPECIFICATIONS
VOLTS
Hz
AMPS
CAPACITY
120
60
5.0
1.4 cu. ft. bin
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
REFERENCE
QTY.
COMPACTION
WEIGHT
Up to 5000 lbs.
134 lbs.
(incl. carton)
REMARKS
SPECIFICATION SHEET
TYPICAL SPECIFICATION
Trash compactor shall be Broan Model 1050L (Model 1051L).
Unit shall produce up to 5000 lbs. of compacting force.
Compactor shall be 12" wide and installed (flush with
countertop) (freestanding). Door panels to be interchangeable
with two different color choices.
Unit shall have to a key switch and a deodorizing panel
feature, and drawer latch.
Compactor to operate on 120 VAC, 60 Hz and not to exceed
5 AMPS. Unit to be U.L. listed.
Project
Location
Architect
Engineer
Contractor
Submitted by
50K
optional
*
cutting board
Date
99042243E
