Summary of Contents for NuTone 1050L
- Page 1 MODELS 1050, 1051, 1050L, 1051L & 1052 COMPACTOR USE AND CARE GUIDE MODELS 1050L & 1051L MODEL1052 MODELS 1050 & 1051...
- Page 2 BAG STORAGE COMPARTMENT AIR FRESHENER PANEL DRAWER SAFETY LATCH (MODELS 1050L & 1051L ONLY) “HANDS FREE” DRAWER OPENING PEDAL (MODELS 1050 & 1051 ONLY) OPTIONAL CUTTING BOARD REMOVABLE DRAWER CONTAINER LATCH KEY LOCK SWITCH AIR FRESHENER (NOT INCLUDED) LEG LEVELERS...
-
Page 3: Grounding Instructions
SAVE THESE INSTRUCTIONS IMPORTANT SAFEGUARDS. READ ALL INSTRUCTIONS CAREFULLY BEFORE OPER- ATING COMPACTOR. Basic precautions should always be taken when using an electrical appliance – including the following: 1. Close supervision is necessary when any appliance is operated near children. Do not allow the appliance to be used as a toy, or to run unat- tended at any time. - Page 4 Remove drawer and set it on its back, with the door panels facing up. (See section “DRAWER REMOVAL”, page 7.) For Models 1052, 1050L & 1051L use instructions 6 thru 9 only. Fig. 4 DRAWER PEDAL RETAINER CAP...
- Page 5 DECORATIVE PANEL INSTALLATION A decorative panel insert can be installed in place of the colored door panel and corrugated spacer. Remove drawer assembly, foot pedal, trim strips, color panel and corrugated spacer following instructions under “Color Matching.” Panels over 1/4” thick: OPTION #1: Make sure panel fits inside the chrome door trim.
- Page 6 Although it is not necessary to compact until the drawer is full or nearly so, it is suggested that for maximum compac- tion, you start the compactor each time a significant amount of trash is added. At full stroke, the ram does not travel all the way to the bottom of the container.
- Page 7 Before you call for service, check these handy hints which may save you the cost of a service call: 1. Is electric cord plugged in securely? 2. Has a house fuse blown or a circuit breaker tripped? 3. Is the drawer pushed firmly shut? 4.
- Page 8 (c) describe the nature of any defect in the product or part. At the time of requesting warranty service, you must present evidence of the original purchase date. Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453) 93042445C...
