MPR Leg Extension Kit - Model 6908
Assembly, Installation and Operating Instructions
Kit No. 1124320
SAVE THESE INSTRUCTIONS
NOTE: Check ALL parts for shipping damage. In case of shipping damage, DO NOT use. Contact
Carrier/Dealer for further instruction.
To ensure the safe installation, operation and use of the MPR Leg Extension
Kit, these instructions MUST be followed:
DO NOT install or use this equipment without first reading and understanding
these instructions. If you are unable to understand the Warnings, Cautions or
Instructions, contact a healthcare professional, dealer or technical personnel before
attempting to install this equipment - otherwise injury or damage may occur.
After ANY adjustments, repair or service and before use, make sure all attaching
hardware is tightened securely - otherwise injury or damage may occur.
Leg Extension Kit (Part No. 1124320) contains the following items:
DESCRIPTION
5-inch Leg Extension
1/4-20 x 1-1/4-inch Hex Head Screw
1/4-20 Locknut

INSTALLING 5-INCH LEG EXTENSION (FIGURE 1)

1. Engage wheel locks.
2. Place recliner on its side to gain access to the casters.
3. Remove the screws and locknuts that secure the caster assemblies to the recliner
frame and remove the casters.
4. Insert the 5-inch leg extensions into each leg of the frame.
5. Secure into place by reinstalling existing screws and locknuts.
6. Insert casters into end of the leg extensions.
NOTE: Ensure that the casters with brakes are reinstalled onto the rear of the recliner.
7. Secure into place with screws and locknuts provided in kit.
For more information regarding Invacare products, parts, and services,
Part No. 1123852
