Smooth operation of working and return strokes possible.
Consistent speed control achieved by preventing jerky movement of working strokes.
Improved response time
Operation delay in a return stroke is reduced by the use of a quick supply and exhaust valve.
Delay in return
operation
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0.0
40
Easy piping
The body and one-touch fitting allow
360° rotation. The sealant on the
male thread is standardized.
Body

Other applications

Jerk prevention in
vertical operation of
the cylinder
Balancing pressure
Pressure valve
Speed controller
SHOP ONLINE at www.airlinehyd.com
Cylinder operation by conventional 2 pressure control
Cylinder operation by air saving valve
Cylinder operation by speed controller
Return stroke pressure
50 63 80
Cylinder bore size (mm)
Cylinder speed: 200 mm/sec
Cylinder stroke: 200 mm
The set pressure can be either fixed or variable.
Fixed set pressure type
Pressure valve
One-touch fittings
Quick air charge at the
end of stroke for press
applications
Flow valve
Speed controller
0.1 MPa 0.1MPa 0.1MPa
Pressure valve
0.2 MPa 0.2MPa 0.2MPa
0.3 MPa 0.3MPa 0.3MPa
Working stroke
0.1 MPa 0.1MPa 0.1MPa
Return stroke
0.2 MPa 0.2MPa 0.2MPa
0.3 MPa 0.3MPa 0.3MPa
Cylinder operating pressure ( MPa)
0.5 MPa 0.5MPa 0.5MPa
Working stroke
0.5
100
Variable set pressure type
(Fixed at 0.2 MPa)
Flow valve Pressure valve
Variation
Model
Pressure valve Flow valve
ASR430F-02 ASQ430F-02
ASR530F-02 ASQ530F-02
ASR530F-03 ASQ530F-03
ASR630F-03 ASQ630F-03
ASR630F-04 ASQ630F-04
Flow valve
Quick supply and
exhaust valve
Air consumption
reduction ratio (%)
Return stroke
0.5 0
17
0.3
25
0.2
0.1 33
Graduated knob
(Variable between
0.1 and 0.3 MPa)
2
3
Flow valve
A knob cap is
attached to the
variable set
pressure type.
Applicable tubing O.D. (mm)
Port
size
6 8 10
R1/4
R1/4
R3/8
R3/8
R1/2
12
Features 2
