- Page 1 USER MANUAL DR-TB9K, DR-TB15K, DR-TB22K, DR-TB30K, DR-TB40K, DR-TB50K, DR-TB60K, DR-TB70K Delta Regis Tools Inc. 7370 Commercial Circle Fort Pierce, FL 34951 www.deltaregis.com...
- Page 3 • Read all instructions before operating tool. • Keep this instruction manual with your tool. • These specifications and design may be changed for improvement without prior notice. Delta Regis Tools Inc. 7370 Commercial Circle Fort Pierce, FL 34951 www.deltaregis.com...
-
Page 4: Table Of Contents
6-1 Safety Device Lock Issues................9 6-2 Solution for Cable trapped between Drum and Case ........9 6-3 Disassembly and Assembly (Figure-5)............9 7. MAINTENANCE AND INSPECTION (Figure-6)..............10 Delta Regis Tools Inc. 7370 Commercial Circle Fort Pierce, FL 34951 www.deltaregis.com... -
Page 5: Safety Instructions
• Never work right under the suspended spring balancer and tool. • Never Alter the Spring Balancer. Delta Regis Tools Inc. 7370 Commercial Circle Fort Pierce, FL 34951 www.deltaregis.com... -
Page 6: Maintenance And Inspection
There is a coil spring in the body of Spring Balancer. If disassembled, the sudden expansion of the coil spring can cause personal injury. • If you need your Spring Balancer repaired, contact your sales agency or Delta Regis Tools Inc. directly 1-4 Disposal WARNING •... -
Page 7: Tool And Device Attachment & Tension Adjustment (Figure-2)
5. OPERATING INSTRUCTIONS 5-1 Manual stop operation DANGER • Make sure lock is engaged securely. You will hear a click if lock is engaged properly. Delta Regis Tools Inc. 7370 Commercial Circle Fort Pierce, FL 34951 www.deltaregis.com... -
Page 8: Tool Or Device Replacement
Attach the cable to the drum on inside of the housing. Assemble the cable set bolt (plug) VII. After attaching the tool or device to the hook, release the drum lock by using the manual stop. Delta Regis Tools Inc. 7370 Commercial Circle Fort Pierce, FL 34951 www.deltaregis.com... -
Page 9: Safety Device
5-4 Safety Device WARNING • Never remove the spiral spring from the spring case. Contact your sales agency or Delta Regis Tools Inc. directly for repair or replacement. 6. TROUBLESHOOTING WARNING • Stop working and take precautions when you have trouble in using Spring Balancer. -
Page 10: Maintenance And Inspection (Figure-6)
7. MAINTENANCE & INSPECTION Periodically (Recommended every 30 days) inspect balancer and replace any damaged parts Delta Regis Tools Inc. 7370 Commercial Circle Fort Pierce, FL 34951 www.deltaregis.com... - Page 12 Delta Regis Tools Inc. 7370 Commercial Circle Fort Pierce, FL 34951 www.deltaregis.com Delta Regis_DR-TB9-70K_M_0.0...
