Emerson ANDERSON GREENWOOD 4020HP Installation, Operation And Maintenance Instructions

ANDERSON GREENWOOD 4020HP PRESSURE AND VACUUM RELIEF VALVE
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
Before installation, these instructions must be read carefully and understood.

TABLE OF CONTENTS

1. Safety Precautions ........................................ 2
2. General Descriptions .................................... 2
3. Operation ....................................................... 2
4. Set Pressure/Vacuum Verification ............... 3
5. Installation ..................................................... 5
6. Maintenance .................................................. 5
7. Valve Disassembly ......................................... 5
8. Valve Refurbishment ..................................... 9
9. Valve Reassembly ......................................... 9
10. Testing Set Pressure and Vacuum ............. 10
