  • Page 1 Living Living Velvet Living Full Vision Living Thin Living...
  • Page 2 giunzioni/junctions 4 segementi / 4 segments 0009224 0009925 0002272 segmenti/segments giunzioni/junctions 6 segmenti/6 segments 0002275 0002278 0009900 0009224 GM8X16 GM8X8 0002272 segmenti/segments giunzioni/junctions 8 segmenti/ 8 segments 0002278 0002275 0002278 VM8X14 0009900 GM8X16 GM8X8 0002272 0009224 segmenti/segments...
  • Page 3 Seguire i seguenti passaggi per l’assemblaggio del telaio Follow the below steps for frame assembly 4 segmenti/4 segments 6 segmenti/6 segments 8 segmenti/8 segments...
  • Page 4 0009224 0002272 0009925 GM8X16 x4 GM8X8 x2...
  • Page 5 Assemblaggio tela Full vision Fabric assembly Full vision Assemblaggio tela Thin pag. Fabric assembly Thin pag. Assemblaggio tela Living e Living Velvet Fabric assembly Living and Living Velvet cava per tela fabric groove Accoppiare la tela al telaio inserendo il bordo freccia gommato all’interno dell oseguire con il restante perimetro.
  • Page 6 Assemblaggio tela Full vision / Thin Fabric assembly Full vision / Thin...
  • Page 7 Assemblaggio cornicetta nera Black and thin frame assembly CLICK! Installazione angolo protettivo. Angolo protettivo/Protection corner Protection corner installation. 0004680 CLICK! Procedere con l’installazione delle sta e. Si raccomanda di non adagiare lo schermo al suolo, lato tela, se non è presente un telo protettivo. Proceed with the installation of the brackets.
  • Page 8 16,26 Installazione a muro: 10,0 91 [3,58] 30 [1,18] Wall installation: 16,7 22 [0,85] 53 [2,07] "wall bracket" 9 [0,35] 47 [1,83] 28 [1,08] 8 [0,31] n. 3 sta e per schermi con base di LP < 400cm n. 3 wall brackets for screen with base viewing area < 400cm L/2 -100mm L/2 - 100 mm n.
  • Page 9 Installazione sta e per appendimento e aliscaf: Hanging and aliscaf brackets installation: n. 2 sta e per schermi con base di LP < 400cm n. 2 brackets for screen with base viewing area < 400cm L/2 - 100 mm n. 3 sta e per scher n.
  • Page 10 Installazione sta e per appendimento: 16,26 10,0 Hanging brackets installation: 30 [1,18] 91 [3,58] 16,7 22 [0,85] 53 [2,07] "hanging bracket" 9 [0,35] 47 [1,83] 28 [1,08] 8 [0,31] Vista sezione telaio/ frame section view Installazione stativi: Legs installation: Fissare gli stativi allo schermo garantendo solidità alla strut baricentro più...

  • Page 12: Norme Generali

    MANUALE D’USO Il presente manuale è parte integrante del prodotto e la sua lettura e comprensione sono di fondamentale importanza per la sicurezza. In esso sono descritte le norme e le modalità di impiego che consentiranno al cliente un corretto e sicuro uso dello schermo. Il manuale deve sempre accompagnare il prodotto e va custodito con cura in luogo idoneo a garantirne l’integrità INSTALLATION MANUAL parts that could pose a hazard.
  • Page 13 SMALTIMENTO DEL PRODOTTO PRODUCT’S DISPOSAL CARATTERISTICHE GENERALI DEL PRODOTTO GENERAL CHARACTERISTICS OF THE PRODUCT PULIZIA E MANUTENZIONE Lo schermo e le tele di proiezione degli schermi sono delicati, quindi bisogna prestare particolare attenzione e seguire le seguenti istruzioni per la loro pulizia:...

  • Page 14: Cleaning And Maintenance

    CLEANING AND MAINTENANCE DISIMBALLO DELLO SCHERMO E MOVIMENTAZIONE PRODOTTO UNPACKING AND HANDING THE SCREEN GARANZIA WARRANTY...
  • Page 15 Note _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________...
  • Page 16 Screenline Srl - Via Nazionale 1/n IT38060 Besenello (TN) Italy el +39 0464 830003 - www.screenline.it - info@screenline.it screenline.it...
