- Page 1 Maximilian 2.0 Pro...
- Page 2 Indice/Index: 1. Disegni tecnici, tabelle pesi, avvertenze Technical drawings, weight charts, warning pag. 2 2. Modalità di installazione Installation instructions pag. 6 2.1 Installazione staffa a golfare Eyebolt brackets pag. 6 2.2 Installazione staffa a soffitto Ceiling bracket installation pag. 7 2.3 Installazione staffa a soffitto con barre filettate Threaded rod ceiling bracket installation pag.
- Page 3 1. Disegni tecnici, tabelle pesi, avvertenze Technical drawings, weight charts, warning MISURE (m) PESO IMBALLATO (kg) PESO MAXIMILIAN(kg) A (cm) a (cm) MEASURES (m) WEIGHT PACKAGING (kg) MAXIMILIAN WEIGHT (kg) 1010 1060 1000 10,0 1050 1110 10,5 1100 1160 11,0 1150 1210 11,5...
- Page 4 263 [10,33] 180 [7,09] 263 [10,34] 350 [13,80] 200 [7,89] TUBE: 150 mm (5,9") Luce di proiezione / viewing area Lunghezza tubo: luce di proiezione + 133 mm (5,2") / Tube lenght: viewing area + 133 mm (5,2") 134 [5,26] Ingombri totali: luce di proiezione + 633,6 (24,9") / Overall width: viewing area + 633,6 mm (24,9")
- Page 5 104 [4,10] A-A ( 1 : 10 ) 53 [2,09] 45 [1,77] B ( 1...
- Page 6 ATTENZIONE / WARNING! Posizionare l’imballo all’interno della sala di installazione assicurandosi di preparare lo schermo con il verso nella giusta direzione. Place the empty packaging in the installation room making sure that the screen is positioned with its front side in the right direction. !FRONT SIDE! BE SURE TO TAKE INTO CONSIDERATION THIS DISPLAY L’Installazione deve essere eseguita da personale esperto: la squadra competente dovrà...
- Page 7 2. Modalità di installazione - Installation instructions 2.1 Staffe a golfare - Eyebolt brackets N. 3 staffe a golfare sempre incluse: utilizzabili come gancio per il sollevamento con paranco a catene. Three eyebolt brackets are always included: they can be used just as as a hook for hoisting. Il sollevamento dello schermo obbligariamente deve essere effettuato mediante 3 punti di ancoraggio l’azienda si rilleva sollevata da qualsiasi responsabilità...
- Page 8 STAFFA A SOFFITTO/CEIILING BRACKET 2.2 Installazione staffa a soffitto Ceiling bracket installation N. 3 staffe a soffitto. Per installazioni aderenti al soffitto. Three ceiling brackets for ceiling installations. La capacità di sollevamento dello schermo dovrà raggiungere un altezza pari o superiore alla posizione delle staffe installate a soffitto. Si consiglia di procedere all’installazione delle staffe a soffitto dopo aver sollevato sufficentemente lo schermo.
- Page 10 STAFFA A SOFFITTO CON BARRE FILETATTE CEILING BRACKETS WITH THREADED ROD WEIGHTS 2.3 Installazione staffa a soffitto con barre filettate Threaded rod ceiling bracket installation N. 3 staffe a soffitto. Per installazioni aderenti al soffitto. Three ceiling brackets for ceiling installations. Si consiglia di procedere all’installazione delle staffe a soffitto con barre filetatte dopo aver sollevato sufficentemente lo schermo.
- Page 12 2.4 Installazione staffa aliscaf Aliscaf bracket installation STAFFA ALISCAF/ALISCAF BRACKET N. 3 staffe aliscaf per installazioni su americane. Staffe regolabili per americane da 200cm a 400cm. Three adjustable aliscaf brackets for trusses from 200 cm to 400 cm. 250 [9,85] 60 [2,36] 120 [4,72] 405 [15,94]...
- Page 14 They can be used with the eyebolt brackets provided with the screen. Per le modalità di installazione e utilizzo dei paranchi a catena si rimanda alle istruzioni allegate al prodotto o disponibili sul nostro sito web www.screenline.it As to installation procedures and the use of chain hoists, see the instructions which come with the product or consult our website screenline.it Se si utilizza un argano non acquistato presso Screenline, scegliere il medesimo assicurandosi che abbia portata minima di 500 Kg per singolo paranco.
- Page 15 Screenline is not responsible for any damage caused to the screen, to third parties or to third parties' things occurred during the hoisting and installation process.
- Page 16 Ogni modifica dovrà essere preventivamente concordata con Screenline. Any tampering or modifications to the electrical system related to the control unit or to the end stroke will nullify the warranty of the screen and any responsibility for Screenline. In ogni caso, l’altezza della tela non potrà mai essere aumentata ma solamente ridotta (al massimo di 50 cm).
- Page 17 4. 1 Installazione centralina - Control box installation motore centralina lunghezza cavo 30 mt. lunghezza cavo su richiesta 230V lampeggiante incluso lunghezza cavo telecomando Telecomando manuale su richiesta su richiesta motor control unit cable length 30 m cable length as requested 230V blinking lamp included...
- Page 18 Note _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________...
- Page 19 Note _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________...
- Page 20 Screenline Srl - Via Nazionale 1/n IT38060 Besenello (TN) Italy el +39 0464 830003 - www.screenline.it - info@screenline.it screenline.it...
