- Page 1 www.idea-vision.de ISION GmbH INSTRUCTION MANUAL VacuMount The Right Choice! contact@idea-vision.de...
-
Page 2: Table Of Contents
7 - 12 Notes Examples 14 - 15 Directors Contact Office Gabriel Pecuch +49 (0)8031 90 85 795 IDEA VISION GmbH Mark Fellinger +49 (0)8031 90 85 796 Anzengruberstr. 16 District Court of email contact@idea-vision.de 83059 Kolbermoor Traunstein HRB 24094 www.idea-vision.de... -
Page 3: Safety Hints
1. Do not start operating the VacuMount System until you have read and understood the operating instruction. All safety hints and informations have to be observed. 2. The IDEA VISION VacuMount may only be operated by competent staff. 3. Cleanness and adhesion: To guarantee a proper adhesion of the suction cup it is most important to make sure that the surfaces of both, the suction cup and the mounting sur- face are clean. -
Page 4: The Vacumount System
The C3 VacuMount System C3 VacuMount Kit existing of: 1 x C3 structure 2 x Suction cup 125 mm 1 x Suction cup 80mm 1 x Micro-controlled Vacuum Pump System 1 x cable car power supply appr. 2m 1 x cable air supply appr. 5m... -
Page 5: Initial Operation
Initial Operation 1. Connect vacuum hose with the Micro-controlled Vacuum pump and C3, C1 structure. Push the hose into the connections. You can feel a distinct resistance during this process. vacuum hose into If there is a leak, the VacuMount system will not hold or the vacuum pump vacuum pump will always pump. -
Page 6: Micro-Controlled Vacuum Pump System
Micro-controlled Vacuum Pump System PUSH AUTO Vin 12.59 V 48.8 VacuMount Power Supply Status Power supply low Power supply in working range Power supply to high Voltage indicating system MANUAL Operating Mode MANUAL Operating Mode AUTO AUTO Warning ! Slow stop! Check the system! VacuumStatus Vacuum pressure to low Vacuum pressure in operating mode... -
Page 7: Assembling
2. Clean car surface and suction cups. Note: Clean, dry, dust free 3. Safety: Although the C3 VacuMount ́ s holding force is adequate for regular driving shots, tension belts must be used for additional safety. - Page 8 5. Open articulated links to level suction cups to surface. 6. Press firmly suction cups down and push green Button AUTO at the Micro-controlled Vacuum pump or push green Button at the C3 structure. The vacuum pump starts working for appr. 3 sec Note: Assure that the Vacuum Pump System is in Mode Automatic 7.
- Page 9 VacuMount 9. Secure C3 and camera with tension belt. Note: Test fixture before driving. 10. Place vacuum pump system e.g. inside the car and secure it properly. 11. Fix vacuum hose with e.g. adhesive tape. 10. End of using: Switch from Automatic into Manual Mode (push green Button).
- Page 10 Vertical assembling If you rigg the VacuMount e.g. on the side of a car you have to keep in mind same points as described above. However, keep in mind that the VacuMount will not hold on the door without the vacuum. Therefore, switch on the vacuum pump system before you place it.
- Page 11 Assembling with C3, C1 extension Use the Extension Kit if you want to place the camera from more distance. You have to keep in mind same points as described above when mounting the VacuMounts with Extension Kit. Individually place the VacuMounts to your require- ments and connect them with the vacuum pumps system.
- Page 12 Always use at least three mounting spots to get adequate stability. The more mounting spots, C3 ́ s , C1 ́ s you use the better stability you get. Assembling with C1 Note: In any case steadiness and holding force must always be tested before shooting or dri- ving using the maximum forces to be expected.
-
Page 13: Notes
6. Clean surface after use to remove possible prints. 7. Cut vacuum hose right after the bend if the hose is cracked. You can repeat this procedure until the vacuum hose becomes to short. 8. IDEA VISION recommends tubes with a size of 33mm (weight!). Directors Contact... - Page 14 VacuMount www.idea-vision.de...
-
Page 15: Contact Fon Fax
ISION GmbH Contact Office +49 (0)8031 90 85 795 IDEA VISION GmbH +49 (0)8031 90 85 796 Anzengruberstr. 16 The Right Choice! email contact@idea-vision.de 83059 Kolbermoor www.idea-vision.de Germany contact@idea-vision.de...
