HV2800 Kaze (Direct Mount) & HV2800D Venti (Ducted)
HV2800 Kaze/HV2800D Venti Whole House Fan Installation Manual, HV2800.4
©Tamarack Technologies, Inc All Rights Reserved 2020
WHOLE HOUSE FAN
INSTALLATION & OPERA TION MANUAL
HV2800 Kaze Direct-Mount
Whole House Fan
with
Drop Down Door
HV2800D
Venti Ducted
Whole House Fan
with
Drop Down Door
Order#:
S/N:
(Required for Warranty)
Page 1
Advertisement
Table of Contents
Related Manuals for Tamarack Technologies HV2800 Kaze
Summary of Contents for Tamarack Technologies HV2800 Kaze
- Page 1 INSTALLATION & OPERA TION MANUAL HV2800 Kaze Direct-Mount Whole House Fan with Drop Down Door HV2800D Venti Ducted Whole House Fan with Drop Down Door HV2800 Kaze/HV2800D Venti Whole House Fan Installation Manual, HV2800.4 ©Tamarack Technologies, Inc All Rights Reserved 2020 Page 1...
-
Page 2: Theory Of Operation
Test this fan outside of the attic Before in-stalling it. Connect the fan to its controls and to a power supply, and ensure it operates properly by turning it on and cycling through its speed settings. If any difficulties are encountered, contact Tamarack Technologies, Inc. technical support at 1 - 8 0 0 - 2 2 2 - 5 9 3 2 or by email at info@tamtech.com... - Page 3 Venting requirements vary by fan. We recommend a minimum of 1 square feet of “net free” ventilation area per 500 cfm at a fan’s highest speed. The Tamarack Technologies, Inc.® minimum attic venting requirements for drop down and ducted drop down door unit ole house fan is given in the chart at above.
-
Page 4: Safety Information
This is a good time to write down the serial number(s) on this manual, which will save you a trip to the attic if you require Tech Support. HV2800 Kaze/HV2800D Venti Whole House Fan Installation Manual, HV2800.4 Page 4 ©Tamarack Technologies, Inc All Rights Reserved 2020... -
Page 5: Electrical Requirements
INSTALLATION Ceiling or Wall? Tamarack Technologies, Inc. dampers can be mounted horizontally or vertically. We recommend installing this fan’s damper in the ceiling in a horizontal orientation, keeping in mind that locating the fan as high as possible helps exhaust the hottest indoor air from the home. The HV2800 can be installed in a wall... - Page 6 INSTALLING THE HV2800 DROP DOWN DOOR ASSEMBLY For HV2800 Kaze Direct Mount or HV2800D Venti Ducted Whole House Fan NOTE: place the actuator on the fan side (shortest route for the actuator wire from the fan (ducted unit only)) Press the (yellow) Clutch on the actuator to open the door fully.
- Page 7 Do not over tighten the screws, since this may reduce the vibration isolation qualities of the foam gasket. HV2800 Kaze/HV2800D Venti Whole House Fan Installation Manual, HV2800.4 Page 7 ©Tamarack Technologies, Inc All Rights Reserved 2020...
- Page 8 Connect the Molex Connector to the Actuator Harness and secure the wire with a Zip-Tie. HV2800 Kaze/HV2800D Venti Whole House Fan Installation Manual, HV2800.4 Page 8 ©Tamarack Technologies, Inc All Rights Reserved 2020...
- Page 9 Pull lightly on the Actuator Cable (previously installed) and apply caulk to the bushing to seal the hole. Apply a bead of caulk to the edge where the fan meets the HV2800 KAZE Box Assembly, to seal the air path.
- Page 10 1½" or longer wood screws include washers (NOT provided) through multiple layers of webbing and into the joists. Duct Collar Low Torque Screws Actuator Cable HV2800 Kaze/HV2800D Venti Whole House Fan Installation Manual, HV2800.4 Page 10 ©Tamarack Technologies, Inc All Rights Reserved 2020...
- Page 11 (see Note 2:) HV2800 Kaze/HV2800D Venti Whole House Fan Installation Manual, HV2800.4 Page 11 ©Tamarack Technologies, Inc All Rights Reserved 2020...
- Page 12 If purchased , the wireless remote receiver is connected to the fan-mounted electrical box at the blue RMT RJ45 port. HV2800 Kaze/HV2800D Venti Whole House Fan Installation Manual, HV2800.4 Page 12 ©Tamarack Technologies, Inc All Rights Reserved 2020...
-
Page 13: Start-Up And Operation
The Tamarack Technologies, Inc. HV2800 KAZE and HV2800D VENTI has ten speed settings. Turn on the Fan by touching FAN UP or TIMER UP. Its door(s) will open and there will be a 10 second delay before the fan begins to operate . -
Page 14: Operating Tips
By running your fan through the night, you speed up this cooling process and can then further “pre-cool” your home, reducing or eliminating the need to use air conditioning the next day. Tamarack Technologies, Inc. fans are extremely efficient, so operating your fan in this way is very inexpensive, especially compared to the cost of air conditioning. - Page 15 ** Time delay allows the door(s) to open before the fan starts Rear View of the Digital Touch Controller RJ45 Jack Jumper Dip Switch HV2800 Kaze/HV2800D Venti Whole House Fan Installation Manual, HV2800.4 Page 15 ©Tamarack Technologies, Inc All Rights Reserved 2020...
-
Page 16: Maintenance
In the case of a power surge, this breaker can be reset by simply pushing the button back in. If you Purchased the HV2800 Kaze Direct Mount or HV2800D Ducted Whole House Fan Lift-Lock with Actuated Drop Down Door, it would be prudent to inspect the door lever hardware (are all screws, nuts tight) and the glide assemblies and lubricate them if needed. - Page 17 ** Tested at 45º and 1 meter from source. Due to continual product improvement, performance ratings and specifications are subject to change without notice. HV2800 Kaze/HV2800D Venti Whole House Fan Installation Manual, HV2800.4 ©Tamarack Technologies, Inc All Rights Reserved 2020...
- Page 18 ** Tested at 45º and 1 meter from source. Due to continual product improvement, performance ratings and specifications are subject to change without notice. HV2800 Kaze/HV2800D Venti Whole House Fan Installation Manual, HV2800.4 ©Tamarack Technologies, Inc All Rights Reserved 2020 Page 18...
