Window Ventilation Economizer
PRODUCT MANUAL & INSTALLATION GUIDE
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN THE PRODUCT.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH
INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE. KEEP INSTRUCTIONS FOR
FUTURE REFERENCE.
Material Included
CapeBreeZ*
(2) 7" Weather Strip
(2) 42" Weather Strip
(1) 42" Center Sash 2ply Insulation
(1) Wire Tie, 6"
(1) Support Bracket
*
Includes factory installed filter
CONTENTS
Important Safety Instructions
Installation
Operating Instructions
Troubleshooting & Maintenance
Specifications
Warranty
READ AND SAVE THESE INSTRUCTIONS
(1) Leveling Adjustment Screw 1 ¾ x 1"
(3) Installation Screws #8 x ¾"
(2) Slider Extenders
(2) Insulated Foam Panels 7" x 9"
Glue Dots
PAGE
2
3
4
5
5
6
(Model TTi-CB08H)
Spring, summer and fall tend to be warm during the day and
cool in the evenings. Use the CapeBreeZ to cool your home
naturally with healthy, filtered air.
The CapeBreeZ is designed to run alone and will also
compliment air conditioning systems by monitoring the
temperature and humidity inside and outside of your home.
This fan is for residential use only. It is not intended to
be used in commercial, industrial or agricultural settings.
Tools and Supplied Needed
20 Patterson Brook Rd / West Wareham, MA 02576
774-678-4433 / 800-222-5932 / Fax 774-678-4436
for use in double hung window
Phillips Screwdriver
•
Scissors
•
Drill, 3/16 bit (
•
Suggested for metal clad
windows and may be helpful on vinyl or wood
)
window sills
Danger, Electrical Shock, Fire
CB08H.1
(not provided)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tamarack Technologies CapeBreeZ TTi-CB08H
Summary of Contents for Tamarack Technologies CapeBreeZ TTi-CB08H
- Page 1 CB08H.1 Window Ventilation Economizer (Model TTi-CB08H) for use in double hung window PRODUCT MANUAL & INSTALLATION GUIDE READ AND SAVE THESE INSTRUCTIONS Spring, summer and fall tend to be warm during the day and cool in the evenings. Use the CapeBreeZ to cool your home naturally with healthy, filtered air.
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING : TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: 1. Make certain the power source conforms to the electrical requirement of the fan. 2. Make sure the room is equipped with a working smoke detector. 3. - Page 3 Installation Instructions – Double Hung Window Choose a window to install the fan. The fan will fit into a double hung window 15.75" to 36"wide with an opening height of at least 12". There must be a polarized outlet within 6' from the window.
- Page 4 Operating Instructions – Digital Control Panel The CapeBreeZ can be customized for different conditions or user preferences. The standard settings are: Fan Speed – 7 for 350 square foot room Display Light Setting - Bright ˚ Filter Change – 50 (500 hours) Temperature Scale –...
- Page 5 Trouble Shooting and Maintenance The fan will not run when “Outdoor Temp” is illuminated on the display or, if the humidity lock is on, when the “Outdoor Humidity” is illuminated. This fan will not bring warmer, humid air into the space. Issue Reason/Action CapeBreeZ is Not Running...
- Page 6 If, within the period of one (1) year from the date of purchase, the CapeBreeZ (the Product) is defective or malfunctions in normal home use, Tamarack Technologies, Inc. will repair or replace the Product, at its discretion. Customer is responsible for shipping charges.
