Summary of Contents for Dimplex Contempra KDS6401E
- Page 1 CONTEMPRA MODEL KDS6401E PARTS & SERVICE MANUAL "Click" on the replacement part number to view price and availability. www.morelectricheating.com 7400060000R02...
-
Page 2: Table Of Contents
Table of Contents OPERATION ..........................2 MAINTENANCE ........................5 EXPLODED DIAGRAM ......................6 REPLACEMENT PARTS ......................7 WIRING DIAGRAM ........................8 LIGHT BULB REPLACEMENT ....................9 TO REPLACE MAIN ON/OFF SWITCH .................. 10 TO REPLACE FLAME MOTOR/FLAME ROD ................. -
Page 3: Operation
OFF position and wait five minutes before switching the unit back on. CAUTION If you need to continuously reset the heater, unplug the unit and call Dimplex North America Limited at 1-800-668-6663. - Page 4 KDS6401E REMOTE CONTROL USAGE This stove is supplied with a radio frequency remote control. This remote control has a range of approximately 50 feet (15.25m); it does not have to be pointed at the fireplace and can pass through most obstacles (including walls). It is supplied with one of 243 independent frequencies to prevent interference with other units.
- Page 5 KDS6401E OPTIONAL EXTERNAL REMOTE CONTROL The remote control has a range of approximately 50ft. (15.25m) it does not have to be pointed at the stove and can pass through most obstacles (including walls). It is supplied with one of 243 independent frequencies to prevent interference with other units.
-
Page 6: Maintenance
KDS6401E MAINTENANCE LIGHT BULB REPLACEMENT Allow at least 5 minutes for light bulbs to cool off before touching bulbs to avoid accidental burning of skin. Light bulbs need to be replaced when you notice a dark section of the flame or when the clarity and detail of the log exterior disappears. -
Page 7: Exploded Diagram
KDS6401E EXPLODED DIAGRAM... -
Page 8: Replacement Parts
"Click" on the replacement part number to KDS6401E view price and availability. www.morelectricheating.com REPLACEMENT PARTS STOVE- CONTEMPORARY - MATTE BLACK PART NO. 6900940159 MOD LEVEL NONE REPLACEMENT PART REPLACEMENT PART NO. 1. FRONT GLASS 5900230100RP 2. LEFT HAND & RIGHT HAND SIDE GLASS 5900240100RP 3. -
Page 9: Wiring Diagram
KDS6401E WIRING DIAGRAM With Integrated On/Off Receiver Board HEATER THERMOSTAT On/Off Main ON/OFF Integral On/Off Receiver Switch LOWER ELEMENT LIGHTS A.C. FLICKER MOTOR MOTOR THERMAL CUTOUT With Optional External Plug-In Remote Control... -
Page 10: Light Bulb Replacement
KDS6401E If unit was operating prior to servicing allow at least 10 minutes for light bulbs and heating element to cool off to avoid accidental burning of skin. Disconnect power before attempting any maintenance or cleaning to reduce the risk of electric shock or damage to persons. -
Page 11: To Replace Main On/Off Switch
KDS6401E If the stove was operating prior to servicing allow at least 10 minutes for light bulbs and heating element to cool off to avoid accidental burning of skin. Disconnect power before attempting any maintenance or cleaning to reduce the risk of electric shock or damage to persons. -
Page 12: To Replace Flame Motor/Flame Rod
KDS6401E If the stove was operating prior to servicing allow at least 10 minutes for light bulbs and heating element to cool off to avoid accidental burning of skin. Disconnect power before attempting any maintenance or cleaning to reduce the risk of electric shock or damage to persons. -
Page 13: To Replace Heater On/Off Switch
KDS6401E If the stove was operating prior to servicing allow at least 10 minutes for light bulbs and heating element to cool off to avoid accidental burning of skin. Disconnect power before attempting any maintenance or cleaning to reduce the risk of electric shock or damage to persons. -
Page 14: To Replace Heater Thermostat
KDS6401E If the stove was operating prior to servicing allow at least 10 minutes for light bulbs and heating element to cool off to avoid accidental burning of skin. Disconnect power before attempting any maintenance or cleaning to reduce the risk of electric shock or damage to persons. -
Page 15: To Replace Power Cord
KDS6401E If the stove was operating prior to servicing allow at least 10 minutes for light bulbs and heating element to cool off to avoid accidental burning of skin. Disconnect power before attempting any maintenance or cleaning to reduce the risk of electric shock or damage to persons. -
Page 16: To Replace The Heater Assembly
KDS6401E If the stove was operating prior to servicing allow at least 10 minutes for light bulbs and heating element to cool off to avoid accidental burning of skin. Disconnect power before attempting any maintenance or cleaning to reduce the risk of electric shock or damage to persons. -
Page 17: Troubleshooting Guide
KDS6401E TROUBLESHOOTING GUIDE GENERAL Service Manual Problem Cause Solution Reference Additional appliances may exceed the current rating of Circuit breaker trips the circuit breaker or fuse. or fuse blows when Improper circuit current rating Plug unit into another outlet unit is turned on or install unit on a dedicated 15 amp circuit Optional remote control has a... -
Page 18: Heater
KDS6401E TROUBLESHOOTING GUIDE HEATER Service Manual Problem Cause Solution Reference Defective heater on/off switch Replace heater on/off switch Page 11 Heater is not turning off Improper operation See Operation Section Page 2 Loose wiring Trace wiring in unit Page 7 Defective heater On/Off Replace heater On/Off Page 11... -
Page 19: Noise
KDS6401E TROUBLESHOOTING GUIDE HEATER (CONTINUED) Service Manual Solution Problem Cause Reference Loose wiring Trace wiring in unit Page 7 Defective heater On/Off Replace heater On/Off Heater fan runs Page 11 switch switch continuously Defective heater assembly Replace heater assembly Page 14 NOISE Service Manual Problem...
