NuAire DRI-365 Installation Manual

Whole house positive input ventilation unit
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
1.0 SAFETY INFORMATION
•
The provision of the electrical supply and the connection of the unit to the electrical supply must
be carried out by a qualified electrician.
•
Isolate from power supply before removing any covers. During installation / maintenance ensure
all covers are fitted before switching on the mains supply.
•
All-pole disconnection from the mains as shown in the wiring diagram must be incorporated
within the fixed wiring and shall have a minimum contact separation of 3mm in accordance with
latest edition of the wiring regulations.
•
This unit must be earthed.
•
Ducting must be securely fixed with screws to the spigot to prevent access to live parts. Duct
runs terminating close to the fan must be adequately protected by suitable guards.
•
This appliance should not be used by children or persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge, unless they have been given supervision
or instruction concerning the safe use of the appliance by a person responsible for their safety.
Children shall not play with the appliance. Cleaning and user maintenance shall not be carried
out by children.
•
Precautions must be taken to avoid the back-flow of gases into the room from the open flue or
gas or other fuel-burning appliances.
1.1 Symbols
GENERAL WARNING
Signifies a general warning regarding hazard specified by supplementary information.
ELECTRIC SHOCK
This unit must be completely electrically isolated before any panels are removed. Check
mains supply and control connections.
ROTATING PARTS
This unit contains fast moving rotational parts which may start automatically. It is the
sole responsibility of the installer to adequately guard these components.
REFER TO INSTRUCTION MANUAL
Read and understand the installation and maintenance manual before installing,
operating or maintaining this product.
Nuaire |
Western Industrial Estate
DRI-365
Whole House Positive Input Ventilation Unit
Installation Manual
|
|
| nuaire.co.uk
Caerphilly
CF83 1NA
20. 05. 21. Document Number 671771
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRI-365 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NuAire DRI-365

Summary of Contents for NuAire DRI-365

  • Page 1 DRI-365 Whole House Positive Input Ventilation Unit Installation Manual 1.0 SAFETY INFORMATION • The provision of the electrical supply and the connection of the unit to the electrical supply must be carried out by a qualified electrician. • Isolate from power supply before removing any covers. During installation / maintenance ensure all covers are fitted before switching on the mains supply.

  • Page 2: Personal Protective Equipment

    Check to ensure that the loft has adequate ventilation. There may be Nuaire would always recommend a site specific risk assessment by a occasions where a loft is so well sealed that additional ventilation may competent person to determine if any additional PPE is required.
  • Page 3 Ceiling Vent 3.3.2 Mounting Fan Unit (Optional Configuration) Using a similar procedure the two ‘L’ shape fixing brackets can also be mounted on the short sides of the DRI-365 unit if an alternative Di user Cap mounting position is required.
  • Page 4 (Part No. PVC130-6WH). dynotie connector •Wall Installation: Wall grille and ducting, supplied by others. (Part No. FLDI150). The following installation materials, not supplied with the unit, can be purchased separately, direct from Nuaire. Tel: 02920 858500 E-mail: info@nuaire.co.uk Part No. Description...

  • Page 5: Remote Sensor Installation

    DRI-365 Installation Manual 3.5 Remote Sensor Remote Sensor Installation 15m sensor DRI-365 units are supplied with 15 metres of 2 core cable pre-wired and connection ready to connect to the Remote Sensor. wire (pre-wired The Remote Sensor is used in conjunction with the units internal sensor to unit).

  • Page 6: Electrical Installation

    DRI-365 Installation Manual 4.0 ELECTRICAL INSTALLATION 5.0 CONTROLS The electrical connection of the unit must be carried out by a 5.1 Fan Speed Adjustment qualified electrician. The unit has 6 air volume (speed) settings. The setting switch is located 4.1 Electrical Information on the rear of the fan case.

  • Page 7: Maintenance

    9.0 END-OF-LIFE AND RECYCLING A clear distance of 500mm should be available above the unit to allow access for maintenance. Ensure that Nuaire product is made safe from any electrical / water / refrigerant supplies before dismantling commences. This work 6.1 Filter Replacement should only be undertaken by a qualified person in accordance with Once every 5 years the filter requires replacement.
  • Page 8 DRI-365 Installation Manual NOTES Nuaire | | nuaire.co.uk 20. 05. 21. Document Number 671771 Western Industrial Estate Caerphilly CF83 1NA...
