1.0 SAFETY INFORMATION
The provision of the electrical supply and the connection of the unit to the mains must be
carried out by a qualified electrician.
Isolate from power supply before removing any covers. During installation / maintenance ensure
all covers are fitted before switching on the mains supply.
All-pole disconnection from the mains as shown in the wiring diagram must be incorporated
within the fixed wiring and shall have a minimum contact separation of 3mm in accordance with
latest edition of the wiring regulations.
This unit must be earthed.
Ensure the flexible duct (maximum length 2m) is connected to the base unit by inserting the
duct over the outlet duct and fix in place using the supplied cable tie. When installing the duct
to the heater unit, insert the duct over the back of the heater, over the protruding screw heads
(3mm from the face of the duct) and fasten the cable tie below the screws.
This ensures that the duct will be held on securely, check all duct joints are air tight.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
Precautions must be taken to avoid the back-flow of gases into the room from the open flue of
gas or other fuel-burning appliances.
This appliance should not be used by children or persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge, unless they have been given supervision
or instruction concerning the safe use of the appliance by a person responsible for their safety.
Children shall not play with the appliance. Cleaning and user maintenance shall not be carried
out by children.
In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance
must not be supplied through an external switching device, such as a timer, or connected to a
circuit that is regularly switched on and off by the utility.
The fan unit is supplied with a fused spur. The three core mains cable from the fan unit should
be connected to a fixed wiring installation, via the spur, in accordance with current IEE wiring
regulations.
The heater unit must be connected to the ceiling vent and fan unit using the 3 looms that
protrude from the heater module.
The CO2 sensor requires a 230V power supply. Remove the front panel as per the humidity
sensor and release the terminal cover via a fixing lug on the rear of the sensor. Refer to the
wiring diagram provided and connect the supply to the terminal box. Finally the sensor may be
mounted to the wall (screws are not provided).
Nuaire |
Western Industrial Estate
DRI-ECO-NOX-HEAT
Whole House Ventilation Unit with RF Enabled
Hall Control, Heating & Carbon Filters
Installation Manual
|
|
| nuaire.co.uk
Caerphilly
CF83 1NA
05. 08. 20. Document Number 671943
EMC Directive
2014/30/EU
LVD Directive
2014/35/EU
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRI-ECO-NOX-HEAT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NuAire DRI-ECO-NOX-HEAT

  • Page 1 DRI-ECO-NOX-HEAT Whole House Ventilation Unit with RF Enabled Hall Control, Heating & Carbon Filters EMC Directive 2014/30/EU Installation Manual LVD Directive 2014/35/EU 1.0 SAFETY INFORMATION • The provision of the electrical supply and the connection of the unit to the mains must be carried out by a qualified electrician.
  • Page 2: Electric Shock

    Once installed, the airflow can be set to suit the house size and, if Nuaire would always recommend a site specific risk assessment by a required, the way it responds to the temperature changes within.
  • Page 3: Mechanical Installation

    Installation Manual DRI-ECO-NOX-HEAT Speed Setting Minimum Distance From Diffuser To Wall IMPORTANT 100 mm Isolate from power supply before removing any covers. 155 mm During installation/maintenance ensure all covers are fitted 400 mm before switching on the mains supply. 625 mm 850 mm 3.0 MECHANICAL INSTALLATION...
  • Page 4: Filter Installation

    If AV mounting is required, the kit can be purchased direct from Nuaire using the following code number: 771393. •Repeat process for the remaining air inlet of the unit. The unit can then be attached to the roof via the cord provided (or fixed Lower the unit with battens (not supplied) attached onto the joists.
  • Page 5: Electrical Installation

    Installation Manual DRI-ECO-NOX-HEAT 4.0 ELECTRICAL INSTALLATION IMPORTANT In the event of conducted RF Please note: the electrical connection of the unit must be carried out by interference between 80 to 127 MHz or transient a qualified electrician. radiated interference between 80 to 87 MHz, the unit...
  • Page 6 Installation Manual DRI-ECO-NOX-HEAT DRI-ECO-4S Option Temperature Operating Mode Description At loft temperatures below 19°C the unit will operate on “Normal Operation Mode”. At loft temperatures above 18°C but less than 24°C, the unit will switch automatically to “Intelligent Heat Recovery Mode”. At loft temperatures above 23°C the unit will switch itself...
  • Page 7: Filter Maintenance

    'C' once this time has elapsed. 7.6 Binding Sensor New particulate filters can be purchased direct from Nuaire using the Putting the unit into binding mode (Section 7.4) before powering the following part number: DRIPOS2001-FILTERKIT (five year filter). To sensors will automatically bind the sensors to the unit.
  • Page 8 Fan not the unit. with Clause 14 of our Conditions of Sale. Customers purchasing from running. outside of the UK should contact Nuaire International Sales office for Fan has failed and a Fan failure - Power to the unit further details.
