View Panel

The view panel provides real-time instrument status and additional functionality pertinent to the selected
operation. A list of available functions is described below.
Table 2: View Panel Functions on the User Interface
Button Name
System Info
Signals
Settings
Autosampler
Method
Utilities
Discovery DSC™ Getting Started Guide
Description
Displays instrument information such as the serial number, IP configu-
ration, and network configuration.
User can select signals to display the real-time signal data generated
directly from the instrument.
Displays options for manual controls, such as Event, Air Cool, Ship,
and Standby Temperature.
Displays a graphical representation of the Autosampler tray, indicating
the status of the active sequence (e.g., which pan positions have been
configured in the active sequence and which runs are active or pending).
In addition, this panel provides access to other Autosampler operations
such as calibration functions and utilities (manually loading pans).
Provides a summary of the sample and method information for the cur-
rent run and allows the user to manually advance the method.
Displays system health and shut down button.
