5. Setting up the power supply

5.1 Parent unit
1. Remove the belt clip 4 by sliding it
downwards.
2. Open the battery compartment by sliding
the cover 6 downwards.
3. Place both the batteries supplied with the
device inside the battery compartment.
Note: When inserting the batteries make
sure that the polarity (+/–) is correct. The
correct polarity is engraved inside the
battery compartment.
4. Close the battery compartment.
5. Reattach the belt clip 4.
6. Insert a mains adapter jack into the
connector socket 5.
7. Plug the mains adapter into a power socket
that conforms to the technical data (see
"4. Technical data" on page 22).
The batteries in the parent unit 7 will then
start to charge. Charging the batteries
completely will take approximately 15 hours.
Note: As a very low current is used to
charge the batteries, the mains adapter
can remain constantly plugged in without
this damaging the batteries. As a result, the
parent unit 7 will be ready for mobile use at
any time.
5.2 Baby unit
The baby unit 13 doesn't need batteries.
1. Insert the jack of the second mains adapter
into the connector socket 12.
2. Plug the mains adapter into a power socket
that conforms to the technical data (see
"4. Technical data" on page 22).
The baby unit 13 is now ready for use.
The mains adapter
illuminated.
23
indicator 14 is
