Connection to the hydraulics
The HPM110 is available with male thread G1/4 (BSPP) or
7/16-20 UNF for the corresponding versions (bar/PSI).
Observe specified torques when fitting the HPM110
The spanner size of the pressure connection is 27 mm
Pressure connection
7/16-20 UNF
1/4 BSPP
Torque
35 Nm
25 Nm
