H-3867
ECONOMY GONDOLA
SHELVING
1.
Insert front panel into front base sides.
(See Figure 1)
Figure 1
Base Sides
2. Place bottom shelf on the base sides.
(See Figure 2)
Figure 2
PAGE 1 OF 3
1-800-295-5510
uline.com
ASSEMBLY
Front Panel
Base Shelf
Pour le français, consulter la page 3.
3. Insert pegboard back panel into track in uprights
and slide down until it rests in channel in the back
of the base shelf. (See Figure 3)
Figure 3
Upright
4. To attach top cap, bend tabs down to correct
position and place over top of unit. (See Figure 4)
Figure 4
Top Cap
Tabs
Para Español, vea página 2.
Pegboard
Panel
0721 IH-3867
