Pearl-2 User Guide
6. Enter the URL of the SRT destination (decoder) using the format srt://<decoder-ip-address>:<port>,
where the <decoder-ip-address> and <port> values are provided by the CDN, media server, or an SRT
decoder device such as a second Pearl-2 at the destination.
7. (Optional) Check Encryption and choose the AES key length if the SRT destination requires AES
encryption. These settings must match the encryption settings of the destination device, see
encryption and a passphrase for
8. (Optional) If the SRT destination has a required security Passphrase along with the AES encryption,
you can enter that here.
9. (Optional) In the Latency field adjust the amount of latency to apply to the stream. The default value
is 125 ms.
We recommend using the default latency and recovery bandwidth overhead values for an
initial test stream. After you perform a test stream, you can determine the Quality of
Service (QoS) and calculate the latency requirements. To set the SRT stream latency, see
Adjust latency and view the SRT stream
10. (Optional) In the Recovery bandwidth overhead field, adjust the % value of the bandwidth that's
dedicate for SRT control and recovery packets. The default value is 25%.
11. (Optional) Rename the stream. Click the current name and enter a different name, then press Enter.
Refresh your browser if the new stream name doesn't immediately display.
12. Click Apply.
13. When your ready to start streaming, click Start
What's next?
If you also need to set up Pearl-2 as an SRT destination and ingest an SRT stream from a remote source, you
must add the SRT stream as a input, see

Set up an SRT stream using caller and listener modes

When setting up SRT streaming on Pearl-2, you can configure Pearl-2 as an SRT source encoder and send an
SRT stream over the Internet to other SRT destinations (decoders) such as a CDN or another Pearl-2.
Caller and listener modes work together to establish the SRT link between your SRT source and destination
device when traversing the firewall is difficult and Rendezvous mode didn't work.
Set up an SRT stream using caller and listener modes
SRT.
status.
Connect an SRT stream as an input.
Set AES
365
