Table of Contents

Advertisement

Quick Links

Download this manual
User Guide
Epiphan Pearl-2
Pearl-2 Rackmount
Pearl-2 Rackmount Twin




Release 4.14.1
April 15, 2021
UG115-24
© and ™ 2021, Epiphan Systems, Inc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pearl-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for epiphan video Pearl-2

Summary of Contents for epiphan video Pearl-2

  • Page 1 User Guide Epiphan Pearl-2 Pearl-2 Rackmount Pearl-2 Rackmount Twin         Release 4.14.1 April 15, 2021 UG115-24 © and ™ 2021, Epiphan Systems, Inc...
  • Page 2 Canadian copyright law, United States copyright law, trademark law, international conventions and other intellectual property laws. Epiphan, Epiphan Video, Epiphan Systems, Epiphan Systems Inc., and Epiphan logos are trademarks or registered trademarks of Epiphan Systems Inc., in certain countries. All Epiphan product names and logos are trademarks or registered trademarks of Epiphan.
  • Page 3 Warranty All Epiphan Video systems have a 100% return to depot warranty for one year from the date of purchase. Technical support Epiphan’s products are backed by our professional support team. You can reach our team several ways:  ...
  • Page 4 Configure Pearl-2's touch screen to show the Content Management System (CMS) events screen at start up. Add a PIN to restrict user access to the start screen. Locking the start screen is useful when operating Pearl-2 in public spaces, classrooms, and unmanned kiosks.
  • Page 5 Unpairing from Epiphan Cloud using the touch screen We listened to your concerns about people inadvertently unpairing Pearl-2 from Epiphan Cloud and so we removed the unpair option from the touch screen. You can still unpair the device using the Admin panel or...

  • Page 6: Table Of Contents

    What's new in release 4.14.1? Table of contents Start here About this Guide What is Pearl-2? Feature add-ons Front and back view of Pearl-2 What's in the Box? Quick start Live video mixing / switching Monitoring audio Selecting an audio source...
  • Page 7 Remote login to the Admin panel and Epiphan Live PART 1: Setup Rackmount installation Configure network settings Network ports used by Pearl-2 Verify IP address and MAC address of Pearl-2 Configure a static IP address Configure DHCP Configure DHCP Option 81 Configure Dynamic DNS...
  • Page 8 Configure 802.1x network security and manage user certificates Manage CA and self-signed certificates Configure HTTPS Configure date and time View the current date and time settings Configure a time server Manually set the date, time, and zone Configure device info, name, description, and location Audio input ports Configure audio ports for stereo or mono Assign audio sources to an input...
  • Page 9 User administration User types and privileges Assign administrator privileges to operators Set or change user passwords Remove user passwords Overcome lost passwords Configure LDAP user authentication Change the logged-in user Restrict viewers by IP address IP restriction examples Status and monitoring Monitoring audio and VU sensitivity Channel monitoring using the touch screen View system information using the touch screen...
  • Page 10 What is downstream chroma keying? Set up chroma key for a green screen video source Add chroma key titler effects using Microsoft Powerpoint slides Add external titler software effects to Pearl-2 Video and audio input sources About connecting video and audio sources...
  • Page 11 Add a custom No Signal image PART 3: Stream What is streaming? Streaming to a CDN, multicasting, and streaming to multiple destinations Directly sharing channel stream URLs with viewers About streaming using SRT Secure streaming Suggested stream settings Streaming a channel direct to viewers Share a live broadcast stream (HTTP, HTTPS or RTSP) Enable HLS (pull) Restrict viewer access to channel streams...
  • Page 12 Stream using UPnP Enable UPnP Disable UPnP Viewing with UPnP Change UPnP device name Streaming NDI About streaming NDI Start and stop an NDI stream PART 4: Record About recording Record a channel Record using Single Touch control Configure recording settings, file size and type Restart recording to a new file Recorders Add a recorder...
  • Page 13 Configure AFU to WebDav server parameters AFU or copy to USB AFU to a USB storage device Do a one-time copy/move all recordings to USB storage device Manually copy recordings to a USB storage device View file transfer status and cancel file copy to a USB device View available USB storage space Safely eject USB storage device Add recordings to an AFU queue...
  • Page 14 Schedule when CMS event recordings upload Upload the local Panopto webcast recording Recover channel backup recordings PART 6: Maintenance Power down and system restart Backup your Pearl-2 setup Perform a factory reset Firmware upgrade Support Register your device Storage capacity and maintenance...

  • Page 15: Start Here

    Pearl-2 is fully integrated with Kaltura and Panopto Content Management Systems (CMSs) and is easily setup using the Admin panel. The Integration section of this guide details how to register and set up Pearl-2 as a remote recording and streaming device for Kaltura and Panopto.

  • Page 16: What Is Pearl-2

    What is Pearl-2? This guide assumes that all feature add-ons for Pearl-2 are activated. If a documented feature or task is only available when a specific feature add-on is activated, it is indicated by a link to the activation page for that feature add-on.

  • Page 17: Feature Add-Ons

    RTMPS. Pearl-2 does not capture from HDCP encrypted sources. Feature add-ons Pearl-2 offers add-on features so you can do even more with your system. Start from the base model of Pearl- 2 and add feature add-ons for extra functionality.
  • Page 18 Pearl-2 User Guide Feature add-ons Add-ons overview for details about the availability of add-ons for your system, as well as instructions to purchase and install add-ons. Where you see this symbol in the guide, that means the feature or function applies only if you...

  • Page 19: Front And Back View Of Pearl-2

    Pearl-2 User Guide Front and back view of Pearl-2 Front and back view of Pearl-2 Table 1 Pearl-2 front panel descriptions Label Name Description Used for confidence monitoring and simple configuration, obtaining system information, and starting/stopping recordings and streams. Touch screen front panel...
  • Page 20 The XLR ports are professional line-level inputs and are calibrated for + 4.0 dBu signals. Four HDMI 1.4 ports that connect HDMI and DVI signals to Pearl-2. HDMI in The first two ports allow for any signal up to full HD, and the second two inputs allow for any input resolution up to 4K Connects SDI signals to Pearl-2, including 3G-SDI;...
  • Page 21 Requires 4K feature add on The SDI ports on the back of Pearl-2 can be delicate. Be careful to avoid sharp impacts or pressure such as balancing the system on its back with the SDI ports against a hard surface. Rough treatment of the SDI ports could result in loss of functionality for that port.
  • Page 22 Pearl-2 User Guide Front and back view of Pearl-2 Pearl-2 Rackmount and Pearl-2 Rackmount Twin Pearl-2 Rackmount Twin consists of two completely independent Pearl-2 systems, each with identical sets of controls and ports. Table 3 Pearl-2 Rackmount front panel descriptions...
  • Page 23 Pearl-2 User Guide Front and back view of Pearl-2 Label Name Description Can be used to connect a USB mouse or keyboard when the local console feature is enabled. A web camera or USB microphone cannot be connected to this port, only to the ports on the rear panel.
  • Page 24 Pearl-2 User Guide Front and back view of Pearl-2 Pearl-2 Rackmount Twin consists of two completely independent Pearl-2 systems, each with identical sets of controls and ports. Table 4 Pearl-2 Rackmount and Pearl-2 Rackmount Twin back panel descriptions Label Name Description Plug the power supply in here.
  • Page 25 Requires 4K feature add on The SDI ports on the back of Pearl-2 can be delicate. Be careful to avoid sharp impacts or pressure such as balancing the system on its back with the SDI ports against a hard surface. Rough...

  • Page 26: What's In The Box

    Pearl-2 Rackmount Twin   The standalone Pearl-2 model is shipped in a hard shell case that you can re-use for storing or moving the system between jobs. Cable storage is located under the custom foam tray that holds Pearl-2 in the case.
  • Page 27 Connect SDI sources to the SDI ports SDI cable (12G-SDI capable). Connect HDMI or DVI (using adapter) HDMI cable sources to the HDMI ports. DVI (female) to HDMI (male) Connect DVI sources to the HDMI port. adapter RJ-45 Ethernet Connect Pearl-2 to your network. cable...

  • Page 28: Quick Start

    Before you start, make sure you have:   A video source such as a camera or a computer and cables to connect them to Pearl-2. For HDMI, the source must not be HDCP protected.   An audio source coming from either your SDI , USB videoor HDMI video source (must not be encrypted).
  • Page 29 My network IP address and channel monitoring You can get the network IP address of your Pearl-2 from the touch screen so that you can do things like view the channels using a web browser or access the configuration Admin panel. Just make sure that your admin computer is connected to the same network as Pearl-2.
  • Page 30  2. Using a browser on the admin computer, go to one of the following URLs to preview the channel. For Auto A: http://<IP Address for Pearl-2>/preview.cgi?channel=1 For Auto B: http://<IP Address for Pearl-2>/preview.cgi?channel=2 For example:http://192.1.10.100/preview.cgi?channel=2  1. (Optional) Open a new tab in your browser and enter the URL to login to the Admin panel.
  • Page 31 Pearl-2 User Guide Quick start Record the channel The channel is set up and streaming. This may be all you need, but if you like, you can also record the stream. You can choose to initiate and control channel recording from either the touch screen or the Admin panel.
  • Page 32 For higher security, we recommend setting admin, operator and viewer-level passwords on Pearl- 2, see Set or change user passwords. When you're done setting up Pearl-2, make sure you back up the system configuration using the procedure described in Create a configuration preset Register Pearl-2 to get firmware updates Keep Pearl-2 up-to-date and get all the latest features and firmware updates.

  • Page 33: Live Video Mixing / Switching

    Live video mixing / switching Create dynamic content for your viewers to watch while you record and stream your program using Pearl-2. Using the custom layout editor, you can create different layouts, like picture in picture or side-by-side views of a camera and slides, then easily switch between layouts with either a tap on the touch screen, using Epiphan Live on a mobile device, or from the Admin panel.

  • Page 34: Monitoring Audio

    Monitoring audio Monitoring audio Pearl-2's front panel includes a 3.5 mm headphones audio jack for monitoring audio. To monitor the audio for a channel, just select the channel using the touch screen. The audio you hear depends on the audio source configured in the live channel layout.
  • Page 35 Pearl-2 User Guide Monitoring audio Audio VU meter A VU meter on the touch screen shows the audio levels for the channel you are monitoring. The value is displayed in dBFS (decibels relative to full scale). Colored bars represent the audio level. Channels that have stereo audio display two bars. The top bar is the left audio channel and the bottom bar is the right audio channel.

  • Page 36: Selecting An Audio Source

    Configure audio ports for stereo or mono. The XLR B audio ports and the RCA audio ports are linked. You can configure Pearl-2 to use both or just one of the audio sources using the Admin panel, see Assign audio sources to an input.
  • Page 37 XLR B/RCA is used. To choose a different audio device for the channel:  1. Using a web browser on the admin computer, go to the IP address of your Pearl-2 and log in, see Connect to Admin panel.

  • Page 38: Connecting Microphones To The Xlr Line Level Inputs

    The XLR analog audio input ports on Pearl-2 are professional line level inputs rated at + 4.0 dBu up to 12.3 V RMS, (+24 dBu). You can't connect microphones directly to the XLR ports because the microphone signal is too low.

  • Page 39: Specifications

    (SRT, RTSP, or NDI). Only content that is not HDCP-protected is captured from HDMI and USB video sources. Pearl-2 supports the following AV inputs. However, Pearl-2 does support common signal converters and input adapters. Pearl-2 Rackmount Twin has two complete sets of these inputs.

  • Page 40: Tech Specs

    The input and output connectors are listed for Pearl-2 and Pearl-2 Rackmount. Pearl-2 Rackmount Twin is made up of two completely independent Pearl-2 systems, therefore it has double the number of inputs and outputs that are listed in this table. ...
  • Page 41 Pearl-2 User Guide Tech specs (2) HDMI™ 1.4a¹ / DVI (2) 4K HDMI 1.4a (UHD/DCI) / DVI (2) USB 3.0 (UVC) - rear panel RTSP Video over ® 4.1 and NDI HX 4.1 (Alpha channel support) Ethernet SRT (push) (4) HDMI type A (female)
  • Page 42 Pearl-2 User Guide Tech specs (2) SDI (4) HDMI (3) USB (rear panel) Digital audio inputs (6) RTSP (embedded from RTSP input over Ethernet) (3) NDI (embedded from NDI input over Ethernet) (6) SRT (embedded from SRT input over Ethernet)
  • Page 43 Pearl-2 User Guide Tech specs Chroma keying Upstream/downstream keying Key frames 1/2 s, and 1 s up to 5 s in 1 second intervals Compression MP3, AAC, and PCM MP3: 22 kHz, 44 kHz, 48 kHz Audio processing Sampling rate...
  • Page 44 Pearl-2 User Guide Tech specs SRT: 128 bits, 192 bits, or 256 bits AES encryption (negotiated) and configurable passphrase Stream encryption HLS (push): MD5, SHA-256, and SHA-512 and authentication MPEG-DASH: MD5, SHA-256, and SHA-512 RTMPS: encryption plus CA certificate negotiation Recorded: 480p to 2160p Streamed H.264: 480p to 2160p...
  • Page 45 Pearl-2 User Guide Tech specs -Kuando BusyLight models: UC Alpha and UC Omega -Delcom Products USB HID single color and multi-color signal indicators Record formats AVI, MOV, MP4, and MPEG-TS Upload image JPEG, PNG formats Internal hard drive 512 GB SSD...
  • Page 46 UI for confidence monitoring, administration, and control. Admin panel Local Admin panel access using a USB mouse, keyboard, and monitor connected directly to Pearl-2 with built-in virtual keyboard and touch-screen monitor support. Administration and control Local web-based UI to easily control streaming, recording, Epiphan Live and switching.
  • Page 47 Pearl-2 User Guide Tech specs and more from the Internet. Multiple user accounts and passwords. Secure access HTTPS for secure Admin panel and Epiphan Live access, as well as local network access to the live channel broadcast. Remote login to cloud versions of the Admin panel and Remote access: Epiphan Live.
  • Page 48 General Pearl-2: 11.81″ × 9.45″ × 3.54″ (300mm × 240mm × 90mm) Pearl-2 Rackmount: 19 ⅛" × 3½" × 10 ⅞" (485 mm × 89 Dimensions (W x D mm × 276 mm) - dimensions include mounting tabs x H) Pearl-2 Rackmount Twin: 19 ⅛"...

  • Page 49: Optimum Cpu Performance

    Requires an Epiphan Cloud Pro account. Optimum CPU performance Pearl-2, Pearl-2 Rackmount and Pearl-2 Rackmount Twin are powerful live video production systems; however, there's a limit to the number of concurrent tasks the onboard CPU can perform efficiently. The number of concurrent tasks depends on many factors, like: how many channels you have, how many layouts you have per channel, how often you switch layouts, is the system resizing (scaling) video sources, what frame rate and bitrate is used per channel, are the video output ports used, etc.
  • Page 50 Pearl-2 User Guide Optimum CPU performance To check the CPU usage from the touch screen, tap the gear icon and select System Status. If the system load is higher than recommended, you can:   Disable the video output port (if unused).

  • Page 51: International Character Support

    Pearl-2 User Guide International character support   Ensure video sources come in at the right resolution so that Pearl-2 doesn't have to up scale or down scale the video source. International character support You can include certain international characters in the channel name, layout name, video and audio input names, text overlays, and in the name of recorded files.

  • Page 52: User Interfaces And Remote Access

    User interfaces and remote access Pearl-2 has several user interfaces:   Touch screen: Easily accessible on the front panel of Pearl-2, the touch screen is primarily used for confidence monitoring, live switching, and Single Touch streaming and recording control, see About the touch screen.

  • Page 53: The Touch Screen

    When you power on Pearl-2, a grid view appears. The grid view displays all channels that are configured for your system. If you haven't created any channels yet, the grid view shows only the two default auto channels: Auto-A and Auto-B.
  • Page 54 Grid icon A No Channels screen appears if there are no channels configured on your Pearl-2 and the automatic channels Auto A and Auto B have been deleted. Tap anywhere on this screen to go to the system settings screen.

  • Page 55: The Channel View

    Each channel you configure on Pearl-2 can be monitored and controlled using the touch screen. After you power on Pearl-2 and the grid view opens, you can select a channel and open the channel view. Just tap the channel you want in the grid view and the channel view opens.
  • Page 56 Pearl-2 User Guide The Channel view Table 10 Parts of the touch screen for the individual channel view Item Description Channel name. Streaming status. Gray means streaming is stopped, flashing blue means streaming is in progress. The streaming timer shows the length of time that streaming has been in progress.

  • Page 57: Record A Channel Using The Touch Screen

    Record a channel using the touch screen Use Pearl-2's touch screen to easily start and stop recording of a channel. Simply tap the recording control button that appears in the channel view. If the red Record icon doesn't appear in the top right corner of the screen, recording is disabled.

  • Page 58: Stream A Channel Using The Touch Screen

    Stream a channel using the touch screen Use Pearl-2's touch screen to easily start and stop streaming a channel. Simply tap the streaming control button that appears in the channel view. If the gray (or blue) Stream icon doesn't appear in the top left corner of the screen, streaming is disabled.

  • Page 59: Switching / Mixing Using The Touch Screen

    Pearl-2 User Guide Switching / mixing using the touch screen Pearl-2 also features One Touch, which lets you control recording and streaming of multiple channels and recorders at the same time with the touch of a button. See Single Touch streaming and recording control for more information.
  • Page 60 Pearl-2 User Guide Switching / mixing using the touch screen  3. Tap any layout that appears in the carousel to load it in to the Preview panel.  4. Tap Apply or double tap inside the Preview panel to switch that layout to the Live panel. The layout that was in the Live panel moves to the Preview panel so that it's ready for the next time you switch.

  • Page 61: Single Touch Streaming And Recording Control

    Single Touch streaming and recording control  6. Tap Back to exit the Live Switcher view. Single Touch streaming and recording control You can easily control streaming and recording from the touch screen on Pearl-2 with just one touch of a button. Topics include:  ...
  • Page 62 Pearl-2 User Guide About Single Touch streaming and recording Table 11 One Touch control screen components Label Description Start/stop button: Press the Single Touch control button to start or stop streaming and recording for all specified channels and recorders. The number of recorders and/or channels that are actively...

  • Page 63: Customize The Single Touch Control Display

    Single touch control: The Single Touch control start screen displays automatically on the touch screen when you power on Pearl-2. Operators can still navigate to other screens from the Single Touch control screen by tapping the Home icon in the top right corner of the screen.
  • Page 64 You must enter the PIN to unlock the Single Touch control start screen and access the other screens using the touch screen. When you return to the Single Touch control start screen, Pearl-2 automatically locks itself and you must re-enter the 4-digit PIN to unlock the touch screen.

  • Page 65: Specify Channels And Recorders For Single Touch Recording

    Specify channels and recorders for Single Touch Pearl-2 User Guide recording  5. Click Apply. If you chose Single Touch control, the touch screen automatically refreshes to display the Single Touch control screen. Specify channels and recorders for Single Touch recording All channels and recorders are enabled for Single Touch recording control by default.
  • Page 66 Specify channels and recorders for Single Touch Pearl-2 User Guide recording Enable Single Touch control for a recorder using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. To enable or disable Single touch control for a recorder.

  • Page 67: Specify Channels For Single Touch Streaming

    Pearl-2 User Guide Specify channels for Single Touch streaming Single Touch control. Then click Apply when you're done. Specify channels for Single Touch streaming Channels are not enabled for Single Touch streaming by default. You can enable and disable one touch streaming control for individual channels using the Admin panel.

  • Page 68: Cms Event Controls Using The Touch Screen

    Apply. CMS event controls using the touch screen Pearl-2 starts recording scheduled events automatically; however, you can use the touch screen to start and stop scheduled events sooner. The touch screen can also be used to authenticate with your Content...
  • Page 69 About Kaltura recording and webcasting About Panopto recording and webcasting. Table 12 Events screens using Pearl-2 for scheduled Kaltura and Panopto events Events screens Description The Calendar icon appears on the touch screen of Pearl-2 when CMS is setup using the Admin panel.
  • Page 70 To create an ad hoc recording or webcast, tap Create event and authenticate using your CMS credentials. Note: Scheduled events override ad hoc events. Pearl-2 stops the ad hoc event and starts the scheduled event when it's time for the scheduled event to start.
  • Page 71 Unscheduled ad hoc event screens Description Panopto login screen: When Pearl-2 is registered with Panopto, this authentication screen appears when you tap Create event from the Events screen. Tap in a field and enter your credentials, then tap Sign in.

  • Page 72: Configure The Touch Screen

    Configure the touch screen The touch screen on Pearl-2 is enabled by default and all its features are available. You can disable the entire screen or some of its features using the Admin panel. For information about how to connect to and use the...

  • Page 73: Disable Or Enable The Touch Screen

    Set a PIN security code Disable or enable the touch screen You can enable or disable Pearl-2 from displaying anything on the touch screen. The touch screen remains touch-sensitive even when the display is disabled. Disable or enable the touch screen display using the Admin panel  1.

  • Page 74: Disable Or Enable The System Status Screen

    Disable or enable the system status screen The system status screen displays network and system related information, such as the IP address needed to access Pearl-2. You may not want this information visible on the touch screen after you've configured Pearl-2.

  • Page 75: Disable Or Enable Configuration Using The Touch Screen

     4. Click Apply. Disable or enable configuration using the touch screen You can apply configuration presets and configure network settings using the touch screen on Pearl-2 by default. You can disable this ability using the Admin panel. If configuration is blocked and system status is permitted, touch screen users see an i icon instead of the configuration gears icon in the lower right corner of the touch screen.

  • Page 76: Disable Or Enable Recording, Streaming And Switching From The Touch Screen

    Disable or enable recording, streaming and switching from the touch screen Recording, streaming, and live switching control using the touch screen on Pearl-2 is enabled by default. You can disable this function using the Admin panel to stop users from switching layouts and from starting or stopping live streams and recordings.

  • Page 77: Set The Touch Screen Timeout

    Pearl-2 User Guide Set the touch screen timeout  3. Uncheck Allow start/stop recording and streaming to disable recording, streaming, and live switching control from the touch screen. Check the check box to enable recording, streaming, and live switching control.  4. Click Apply.

  • Page 78: Set A Pin Security Code

     4. Click Apply. Set a PIN security code You can set a 4-digit PIN code to protect the touch screen of Pearl-2 from unauthorized access. By default, the PIN is not set. If a PIN is configured, users are prompted to enter the PIN code whenever:  ...
  • Page 79 You must enter the PIN to unlock the start screen and access other screens using the touch screen. When you return to the Single Touch control or CMS start screen, Pearl-2 automatically locks itself and you must re-enter the 4-digit PIN to unlock the touch screen.

  • Page 80: The Admin Panel

    The Admin panel The Admin panel is used primarily to set up your Pearl-2 and perform administrative tasks. Most tasks in this user guide are performed using the Admin panel. This section contains what you need to get started using the Admin panel.
  • Page 81 Name Description The channels that are available for the current configuration of your Pearl-2 are listed. Select a channel to access the drop down list of Channels menu options that are available to configure channel encoding, add video and audio sources, create layouts, perform confidence monitoring,...
  • Page 82 Link to Epiphan Live Click to open Epiphan Live in a new tab. Click to log out of Pearl-2. Click icon again to display the log in Log out window. The role of the currently logged in user displays beside the icon.

  • Page 83: Connect To Admin Panel

     b. If your system doesn't have any channels showing, tap the touch screen anywhere to go to the system settings screen, then tap System Status.  2. When you have the IP address of Pearl-2, enter the following into the address bar of your web browser to launch the Admin panel.

  • Page 84: Enable Local Console Access To The Admin Panel

    External keyboard option. Use the Admin panel or the touch screen on Pearl-2 to enable local console and the external USB keyboard. Once enabled, simply connect your USB mouse, USB keyboard, and an HDMI monitor to the HDMI OUT port that has local console enabled.
  • Page 85 Pearl-2 User Guide Enable local console access to the Admin panel   Epiphan Live is not accessible from the local console.   The live preview link is not accessible from the Channel Status page using the local console.   You cannot upload/download the following types of media using the local console:  ...
  • Page 86  8. (Optional) Check Disable authentication if you don't want users to have to use their credentials to login before using the local console to access the Admin panel on Pearl-2.  9. Under Settings, select Local console in the Source drop-down menu.

  • Page 87: Connect Using A Dns-Based Service Discovery

    Connect using a DNS-based service discovery Pearl-2 uses DNS-based messages to advertise details about itself, including its host name. With a compatible utility installed on your computer, you can access the system simply by typing its serial number and the suffix ".local"...
  • Page 88 For example: http://95dd40d5.local/admin If HTTPS is enabled on Pearl-2, replace http with https in the URL.  3. Enter your user name and password when prompted, then click OK. The administrative user name is admin. Initially no password is set. To set a password, see User administration.

  • Page 89: Connect Using Persistent Static Ip Address

    Pearl-2 has a default persistent static IP address, also known as the recovery IP address. If ever you need to set up Pearl-2 on a network that does not support DHCP, or you need to recover from a previous static IP address setting, you can use this procedure to connect directly to the system for configuration.

  • Page 90: Switching / Mixing Using The Admin Panel

    Pearl-2 User Guide Switching / mixing using the Admin panel  2. Record the network settings of the workstation that are used to connect to Pearl-2 so that they can be restored later.  3. Temporarily change the network configuration on the workstation to the following:  ...
  • Page 91 Pearl-2 User Guide Switching / mixing using the Admin panel  4. To switch to a different layout as the active "live" layout, click the gray circle beside the layout you want to make go live. The circle turns red to indicate that it's now the active "live" layout.

  • Page 92: Epiphan Live

    Remote login to the Admin panel and Epiphan Live. About Epiphan Live The Epiphan Live interface lets you easily operate your Pearl-2 using a computer or mobile device such as a tablet. You can:   Control streaming and recording of channels and recorders.

  • Page 93: The Dashboard Interface

    Pearl-2 User Guide The Dashboard interface Operating system Supported web browser(s) or mobile device   Google Chrome Windows   Microsoft Edge   Google Chrome   Safari Linux   Google Chrome Android phone or   Google Chrome tablet   Google Chrome iPhone or iPad  ...
  • Page 94 Pearl-2 User Guide The Dashboard interface Table 16 Elements in the Dashboard interface Number Title Description   Warning – This icon displays only if there are any configuration errors in your channels, sources, streams or recordings. Clicking the icon displays more detail about the errors.

  • Page 95: Access Epiphan Live Using A Web Browser Or Mobile Device

    You can open Epiphan Live using a web browser on your Windows, Mac, or Linux computer. You can also use Epiphan Live on an Android phone or tablet, an iPhone, or an iPad. You need the IP address of your Pearl-2 to connect to Epiphan Live, see Connect to Admin...

  • Page 96: Access Epiphan Live From The Admin Panel

    Firefox or update the version of your web browser, then add the security certificate for the website to the exceptions list. Access Epiphan Live from the Admin panel You need the IP address of your Pearl-2 to log in to the Admin panel for this procedure, see Connect to Admin panel.

  • Page 97: Stream, Record, And Monitor Using The Dashboard Interface

    The current streaming bandwidth (bitrate)   Automatic file upload status (enabled or disabled). See FTP and automatic file transfers.   Storage available on your Pearl-2. Other logged in operators and admins must refresh their web browsers to see the latest changes to the Dashboard.
  • Page 98 Stream, record, and monitor using the Dashboard Pearl-2 User Guide interface Up to 8 Epiphan Live preview panels can be open at the same time. The limit of 8 live preview panels applies across all open instances of Epiphan Live, including multiple users accessing Epiphan Live simultaneously from different web browsers, or duplicate instances of the same Epiphan Live interface open on multiple browser tabs at the same time.
  • Page 99 Monitor video and audio input sources using Epiphan Live Use the Dashboard to monitor your video and audio inputs. The video inputs section of the Dashboard lists all inputs configured on your Pearl-2 and displays the video resolution.   A green dot means that the video source is connected and a signal is received.
  • Page 100 Stream, record, and monitor using the Dashboard Pearl-2 User Guide interface The audio inputs configured on your Pearl-2 appear in the Audio inputs section of the Dashboard.   A grayed-out audio source means that the audio source is not used in any channels.
  • Page 101 Stream, record, and monitor using the Dashboard Pearl-2 User Guide interface Show or hide audio inputs You can pick which audio inputs display in the Dashboard view. Just tap the Audio inputs header and then check the checkbox next to the name of each source you want showing in the Dashboard view. Tap Save when you're done.
  • Page 102 Stream, record, and monitor using the Dashboard Pearl-2 User Guide interface By default, video output ports are configured to maintain aspect ratio, use the display's default resolution, include audio at 100% and they don't include the audio VU meter. You can change these defaults in the Admin panel.
  • Page 103 Stream, record, and monitor using the Dashboard Pearl-2 User Guide interface  3. To enable or disable audio for the output port, tap the speaker icon to toggle audio On and Off for the port. A green icon means audio is enabled. A gray icon means audio is disabled.
  • Page 104 Stream, record, and monitor using the Dashboard Pearl-2 User Guide interface If multiple streams are configured for a channel, a pair of control buttons is displayed for each stream. Click the channel name to open a preview thumbnail view. When you're ready to start streaming and recording the channel, tap the streaming and recording control buttons.

  • Page 105: Switching / Mixing Using Epiphan Live

    This feature is useful when you're capturing a video source and multiple languages from different audio sources. Multi-track recorders appear on the Dashboard if they are configured on your Pearl-2. Each multi-track recorder has a recording control button to start and stop recording. When a Recorder is not recording, the button is gray and the timer is set to 00:00:00.
  • Page 106 Elements in the Switcher view Number Title Description A list of channels configured on your Pearl-2. When a channel is Channel selector selected, you can switch between the different layouts that are configured for that channel. Displays links to the Dashboard view and the Admin panel when Menu icon clicked.
  • Page 107 Pearl-2 User Guide Switching / mixing using Epiphan Live Number Title Description channel. Select a layout from the carousel to add it to the Preview panel. Note that the layout selected for the Preview panel has a green border and the layout in the Live panel has a red border.
  • Page 108 Pearl-2 User Guide Switching / mixing using Epiphan Live switching. All the layouts for the selected channel are displayed in a carousel along the bottom of the screen. The layout that is live is displayed in the Live panel on the right side of the interface, see...

  • Page 109: Your Recordings

    Pearl-2 User Guide Your recordings  5. Tap the Switch button to switch the layout that is currently in the Preview panel to the Live panel. The layout that was in the Live panel moves to the Preview panel so that it's ready for the next time you switch.
  • Page 110 Pearl-2 User Guide Your recordings After recoding a file, you can manage it and any other files using the following tools on the page: Number Title Description Select a From and a To date from the pop-up calendar to create a Date selector date range.

  • Page 111: Cloud-Based Device Management

    Guide. About device management with Epiphan Cloud Epiphan Cloud is your remote management and control center for all your Pearl-2 devices. All you need is a free Epiphan Cloud account. After you pair Pearl-2 with your Epiphan Cloud account, you can access Pearl-2 from anywhere there's an Internet connection.

  • Page 112: Enable Or Disable Epiphan Cloud Access

    Epiphan Cloud is where you go to remotely manage and control all your Pearl-2 devices. Access is enabled on Pearl-2 by default. All you need to do is pair Pearl-2 to your free Epiphan Cloud account for access to your device over the Internet.
  • Page 113  4. Tap Epiphan Cloud. The Epiphan Cloud settings page shows the status as enabled and displays a pairing code by default.  5. Uncheck Enable Epiphan Cloud to disable the feature or leave it checked to allow Pearl-2 to access Epiphan Cloud.

  • Page 114: Pair And Unpair From Epiphan Cloud

    Epiphan Cloud account. Easily pair Pearl-2 directly from the Admin panel or add Pearl-2 as a new device in Epiphan Cloud using Pearl- 2's device ID paring code. To manually pair Pearl-2 in Epiphan Cloud using Pearl-2's pairing code, see the Epiphan Cloud online user guide.
  • Page 115  2. From the Configuration menu, select Epiphan Cloud. The Epiphan Cloud status page opens. The pairing code device ID for Pearl-2 is shown, as well as a link to pair the device.  3. Select Click to pair. The Epiphan Cloud login page opens in a new tab (https://go.epiphan.cloud)  4.
  • Page 116 Pair and unpair from Epiphan Cloud  6. In the Admin panel, the status of Pearl-2 updates to paired on the Epiphan Cloud status page.  7. To unpair Pearl-2 using the Admin panel, select Unpair on the Epiphan Cloud status page.

  • Page 117: Remote Login To The Admin Panel And Epiphan Live

    You can remotely login to Pearl-2 for full administration access to configure and operate Pearl-2 over the Internet using a cloud version of the Admin panel and Epiphan Live. You just need to pair Pearl-2 to an Epiphan Cloud account that has one of the Pro plans.
  • Page 118 Pearl-2 User Guide Remote login to the Admin panel and Epiphan Live   Make sure Pearl-2 is paired to your Epiphan Cloud account, see Pair and unpair from Epiphan Cloud.   Upgrade to one of the Epiphan Cloud Pro plans.
  • Page 119 Pearl-2 User Guide Remote login to the Admin panel and Epiphan Live The Admin panel Epiphan Live for instructions to use the interface or to access the local web version.

  • Page 120: Part 1: Setup

    PART 1: Setup This section contains tasks that are needed to get your Pearl-2 configured to connect to your local network, make system settings, add passwords, make backups of your configuration, and covers how to access status information and monitor the performance of your Pearl-2.

  • Page 121: Rackmount Installation

    Rackmount installation Rackmount installation All Pearl-2 models can be used in desktop mode, with the system placed on any flat, stable surface. They are also all rackmountable into fixed racks or portable rack cases like the one depicted below. If you purchased Pearl-2 Rackmount or Pearl-2 Rackmount Twin, you can install your system directly into a 19-inch rack.

  • Page 122: Configure Network Settings

    The following table lists the default incoming and outgoing network ports that Pearl-2 uses. Do not block traffic over these ports. If you want Pearl-2 to operate properly, make sure that your firewall is configured to open these ports. Blocking a port will cause the service that uses that port to fail. It is possible to use the Admin panel to change the default ports that are used for some services.

  • Page 123: Network Ports Used By Pearl-2

    Pearl-2 User Guide Network ports used by Pearl-2 Port (or range) Protocol Description TCP/UDP NTP server, if enabled. See Configure a time server. 319 and 320 PTP server, if enabled. See Configure a time server. HTTPS for the Admin panel and HLS streaming if enabled. Port is open only when HTTPS is enabled.

  • Page 124: Verify Ip Address And Mac Address Of Pearl-2

    AFU file recording transfer port - the actual ports used for AFU depends on your configuration. See FTP and automatic file transfers. Verify IP address and MAC address of Pearl-2 There are two ways to view the current IP address and MAC address of Pearl-2:   From the Network configuration page using the Admin panel.  ...
  • Page 125 Pearl-2 User Guide Verify IP address and MAC address of Pearl-2 View network information using the touch screen  1. Tap the gear icon to open the System settings screen. If the control icons aren't showing, tap anywhere on the touch screen.

  • Page 126: Configure A Static Ip Address

    Pearl-2 User Guide Configure a static IP address Configure a static IP address There are two ways you can set up Pearl-2 to use a static IP address:   From the Network configuration page using the Admin panel.   From the Settings menu using the touch screen on Pearl-2 TIP: Using the touch screen, you can choose to apply a configuration preset that contains a static network IP.
  • Page 127 The default gateway and DNS Server fields cannot be left blank. If you do not have a default gateway or a DNS server for your network, enter the static IP address in those fields.  4. Reboot Pearl-2 when prompted. From the Configuration menu, select Maintenance and click Reboot Now on the Maintenance page.

  • Page 128: Configure Dhcp

     5. Reboot Pearl-2 to apply the network changes. Configure DHCP If you need to switch Pearl-2 from using static IP address allocation to using dynamic allocation with DHCP, you can do this three different ways:   Restore factory settings, which clear all your custom settings. See Perform a factory reset.
  • Page 129 Only change this value if you know that other nodes use a different value.  4. Reboot Pearl-2 when prompted. From the Configuration menu, select Maintenance and click Reboot Now on the maintenance page.  5. After the system has finished rebooting, log back in to the Admin panel as admin and verify that all changes were applied.

  • Page 130: Configure Dhcp Option 81

    DHCP server may change Pearl's IP address. Pearl-2 automatically asks the DHCP server to tell the Domain Name Server (DNS) to update Pearl-2's record with any changes to Pearl-2's IP address or FQDN. DHCP Option 81 is disabled by default.

  • Page 131: Configure Dynamic Dns

    You can use Dynamic Domain Name Server (DDNS) to ensure that whenever the DHCP server changes Pearl- 2's IP address, Pearl-2 informs the DDNS to update it's domain name records. That way, you can keep using Pearl-2's FQDN without worry.
  • Page 132 IP detection IP detection. This is enabled by default. The status of the connection to the DDNS server, the last external IP address of Pearl-2 that was reported to the DDNS server, and the time when the IP address was reported is shown.
  • Page 133  5. Enter the Username and Password for your DDNS server.  6. In the Hostname field, enter the hostname of your Pearl-2, for example: mypearl. The default hostname is the serial number of Pearl-2.

  • Page 134: Change The Http/Https Port Values

    Change the HTTP/HTTPS port values On Pearl-2, the default HTTP port is 80 and the default HTTPS port is 443. If the default ports used by Pearl-2 are not available on your network, you can change them using the Admin panel. Consult your system administrator for the correct port values to use for HTTP and HTTPS traffic.

  • Page 135: Perform Network Diagnostics

    Pearl-2 User Guide Perform network diagnostics  4. Reboot Pearl-2 when prompted. After the system has finished rebooting, log back in to the Admin panel as admin and verify that all changes were applied. Perform network diagnostics Network diagnostic tools are available to help you troubleshoot your setup. Easily run diagnostics like traceroute, ping, and others from the touch screen or using the Admin panel.

  • Page 136: Disable The Network Discovery Port

    Disable the network discovery port You can disable the network discovery port on Pearl-2 using the Admin panel so that services can no longer discover Pearl-2 systems using multicast DNS (mDNS). The network discovery port on Pearl-2 is port 5557 and is enabled by default.
  • Page 137 Pearl-2 User Guide Disable the network discovery port  ...

  • Page 138: Configure Network Security

    Set or change user passwords. Configure 802.1x network security and manage user certificates You can enable 802.1x security and configure the EAP method for Pearl-2 to use for secure network access using the Admin panel. Supported EAP methods include:   PEAP (default)  ...
  • Page 139 Configure 802.1x network security and manage user Pearl-2 User Guide certificates  4. (Optional) Check Verify server's identity.  5. Choose an Authentication method if you selected EAP-TTLS as the EAP method. The authentication method is automatically selected if PEAP or EAP-TLS is the EAP method.

  • Page 140: Manage Ca And Self-Signed Certificates

    If you need to delete the user certificate or private key, click Delete certificate. Manage CA and self-signed certificates You can view the list of CA and self-signed certificates that come preloaded on Pearl-2. CA and self-signed certificates are used for server authentication if Verify server's identity is selected when 802.1x network security is configured, see Configure 802.1x network security and manage user...

  • Page 141: Configure Https

    Configure HTTPS You can configure Pearl-2 to use HTTPS for secure, local network access to the Admin panel, as well as for viewing the live channel preview stream on the local network using the Live broadcast URL.
  • Page 142 The default HTTP port 80 redirects traffic to the default HTTPS port 443 when HTTPS is enabled. If the default ports used by Pearl-2 are not available on your network, you can change them using the Admin panel, see Change the HTTP/HTTPS port values.
  • Page 143  6. Click Apply when you're done.  7. Reboot Pearl-2 when prompted. After the system has finished rebooting, log back in to the Admin panel as admin and verify that all changes were applied. If you need to delete the certificate you uploaded and the private key, click Delete...

  • Page 144: Configure Date And Time

    Configure date and time Configure date and time Pearl-2 uses the current date and time in naming recorded files and when synchronizing and timestamping inputs from multiple sources (i.e. when synchronizing an audio and a video source). The Admin panel lets you specify date and time settings to ensure they are correctly configured for your time zone and your network.
  • Page 145 Pearl-2 User Guide View the current date and time settings Table 25 Date and Time configuration options Label Description/Options Time Zone The currently selected time zone. Enable time Whether or not a time synchronization protocol is being used for setting time. If not synchronization selected, time is set manually.

  • Page 146: Configure A Time Server

    See Configure the touch screen to enable system information. Configure a time server Pearl-2 uses the Network Time Protocol (NTP) server from the National Research Council of Canada by default. You can change to a different time server using the Admin panel. Contact your system administrator for the time synchronization server settings you should use.

  • Page 147: Manually Set The Date, Time, And Zone

    Manually set the date, time, and zone Pearl-2 uses NTP for time synchronization by default. However, you can manually set the date and time for Pearl-2 using the Admin panel. You can also set the time zone. Pearl-2 uses the Eastern (Canada) time zone by...
  • Page 148 Pearl-2 User Guide Manually set the date, time, and zone default. Set the date, time, and zone manually using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. From the Configuration menu, click Date and Time. The Date and Time configuration page opens.

  • Page 149: Configure Device Info, Name, Description, And Location

    Configure device info, name, description, and location You can assign Pearl-2 a unique device name using the Admin panel and add information such as a description and location. Alphanumeric characters and hyphens are supported. The serial number of Pearl-2 is the default device name.
  • Page 150 Pearl-2 User Guide Configure device info, name, description, and location  b. Enter a description using alphanumeric characters including hyphens up to a maximum of 50 characters.  c. Enter a location using alphanumeric characters including hyphens up to a maximum of 50...

  • Page 151: Audio Input Ports

    The four XLR audio inputs are configured as two stereo pairs by default: XLR A (left/right) and XLR B (left/right). The XLR B audio ports and the RCA audio ports are linked. You can configure Pearl-2 to use both or just one of the audio sources using the Admin panel.

  • Page 152: Assign Audio Sources To An Input

    Assign audio sources to an input When mono is selected, two sets of parameters and two audio VU meters appear in the interface - one for each audio input port on Pearl-2. Parameters that are listed only once apply to both ports.

  • Page 153: Adjust Audio Gain And Delay

     3. From the Input menu, select the audio source and click Apply. Adjust audio gain and delay Pearl-2 does not introduce audio delay and has near-zero latency when capturing. However, other external factors can cause audio to become de-synchronized, such as the length of audio cables or the configuration of your equipment.
  • Page 154 Adjust audio gain and delay The analog audio input ports on Pearl-2 are calibrated for +4.0 dBu XLR or -10.0 dBV RCA audio signals and provide moderate to significant signal headroom. For the analog audio inputs, you can add up to +30 dB of gain.

  • Page 155: Mute Audio

    Some audio input ports share internal audio processing resources in Pearl-2. Muting an audio input that shares internal resources mutes all the associated audio sources. The following table lists the audio input ports that share internal processing and the results of applying mute.
  • Page 156 Pearl-2 User Guide Mute audio Audio input Shared audio Results (Admin panel) input resources Both XLR-B ports (left and right) are muted. Both RCA ports (left and right) are muted In mono mode (Analog B audio Left muted): Both the XLR-B left and RCA left ports are muted.
  • Page 157 Pearl-2 User Guide Mute audio...

  • Page 158: Video Output Ports

    About video output ports Pearl-2's rear panel includes two HDMI video output ports. HDMI 1 is set to show Auto A and HDMI 2 is set to show Auto B by default. Both video output ports are configured to maintain aspect ratio, use the display's...
  • Page 159 You can use the Admin panel to configure the video output port parameters. If you're simply selecting a video source or channel and enabling/disabling audio for the output port, you can use your choice of either the Admin panel, the touch screen on Pearl-2, or Epiphan Live.  For channels that have audio, the audio is enabled by default.

  • Page 160: Video Output Port Resolution

    For example, the resolution 1920×1080 (1080p) produces an image that is 1920 pixels wide by 1080 pixels tall. Pearl-2 always assumes that the output display uses square pixels. The aspect ratio (eg. 4:3 or 16:9) describes the proportional relationship between the video output's pixel width and height.

  • Page 161: Set Up The Video Output Port Using The Admin Panel

    Pearl-2 User Guide Set up the video output port using the Admin panel Set up the video output port using the Admin panel You can send a channel or a video source to the video output port using the Admin panel. You can also adjust the video output resolution, aspect ratio, and choose to include audio.
  • Page 162 Pearl-2 User Guide Set up the video output port using the Admin panel  3. In the Resolution field, select the resolution for the video output port. Value Description Set the output to the same resolution as the channel or video source. If that resolution is not supported by the...

  • Page 163: Select The Video Output Source Using The Touch Screen

    Select the video output source using the touch screen It's easy to change the video source that appears at the video output port using the touch screen on Pearl-2. For video sources that have audio, you can enable and disable the audio as well. Audio is enabled by default.

  • Page 164: Preview The Video Output Port

    Pearl-2 User Guide Preview the video output port  1. From Pearl-2's touch screen, tap the gear icon to open the System settings screen. If the control icons aren't showing, tap anywhere on the touch screen.  2. Tap the arrow icon in the lower-right corner of the screen to go to the second Settings page.

  • Page 165: Disable The Video Output Port

    Pearl-2 User Guide Disable the video output port If the video output port is showing a source and that source has no signal, the source's no signal image is displayed. If the video output port is showing a channel and that channel is unavailable or has no signal, a no signal message is shown for 2.5 seconds, then the display output is changed to a black screen.

  • Page 166: Disable Or Enable Audio And Output Port Volume

    Pearl-2 User Guide Disable or enable audio and output port volume Disable or enable audio and output port volume If you're displaying a channel as the source for your video output port, audio for that channel is also encoded and sent over the port by default. You can disable the audio on the output port using the Admin panel. You can also adjust the volume of the audio on the video output port using the Admin panel.
  • Page 167 Pearl-2 User Guide Disable or enable audio and output port volume  c. (Optional) For a channel with audio enabled, choose whether or not to display the audio meter from the Audio meter drop-down menu.  d. If displaying the audio meter, select horizontal or vertical from the Audio meter orientation drop-down menu to change the orientation of the displayed audio meter.

  • Page 168: Display And Reposition The Audio Vu Meter

    Pearl-2 User Guide Display and reposition the audio VU meter  5. Click Apply. You can also disable or enable audio on the video output port and adjust the volume using Epiphan Live, see Monitor and select the video output source using Epiphan Live.

  • Page 169: Rename A Video Output Port

    Pearl-2 User Guide Rename a video output port Value Description do not display No audio meter is displayed. left top corner Audio meter is displayed at the top left side of the display. right top corner Audio meter is displayed at the top right side of the display.

  • Page 170: Mirror The Video Output Port Display

    Pearl-2 User Guide Mirror the video output port display  4. Press Enter using your keyboard to save the changes. You must press Enter to save the new name. The Apply button does not save the source name change. Mirror the video output port display You can use the Admin panel to mirror the original video source on the output port so that it appears reversed on the connected display.

  • Page 171: Connect An External Keyboard

    Apply Connect an external keyboard Instead of using the built-in virtual keyboard on Pearl-2's touch screen, you can connect a USB keyboard to Pearl-2 and use that. Simply enable the external keyboard feature using the Admin panel and connect your keyboard directly to any available USB port on Pearl-2.
  • Page 172 Pearl-2 User Guide Connect an external keyboard   Portuguese (European)   Spanish (Spain)   Swiss   Russian When an external keyboard is connected to the USB port, the Lock Caps key on the external keyboard controls both the external keyboard and the virtual keyboard.

  • Page 173: Connect A Usb Status Light

    Kuando BusyLight models: UC Alpha and UC Omega   Delcom Products USB HID single color and multi-color signal indicators The status light is activated as soon as it is connected to a USB port on Pearl-2 and flashes once. Table 30 Status light indicator...

  • Page 174: Feature Add-Ons

    Pearl-2 User Guide Feature add-ons Feature add-ons Pearl-2 offers add-on features so you can do even more with your system. Start from the base model of Pearl- 2 and add feature add-ons for extra functionality. Add-ons overview for details about the availability of add-ons for your system, as well as instructions to purchase and install add-ons.
  • Page 175 Install purchased add-ons The 4K feature add-on is required to enable that feature on Pearl-2. Your purchased add-on can be installed and activated on only one Pearl-2 system. Pearl-2 Rackmount Twin requires a separate 4K add-on for each Pearl-2 system.
  • Page 176 After you've activated your feature add-ons and the system reboots, the Purchase button beside those features is replaced by an Activated indicator. Current list of add-ons As of firmware 4.0.1, the 4K feature add-on is the only add on available for Pearl-2.

  • Page 177: 4K Feature Add-On

    About 4K on Pearl-2 Pearl-2 supports resolutions from low-res SD to 4K, which means that you can use Pearl-2 to capture both DCI 4K and 4K UHD digital signals. You need the 4K feature add-on to access this feature, see Add-ons overview.
  • Page 178 Pearl-2 User Guide 4K feature add-on...

  • Page 179: Configuration Presets

    Configuration presets are groups of settings that get applied to the system, leaving other important settings intact. They make it easy to manage multiple Pearl-2 systems in shared spaces, like a studio, and ensures a consistent setup each time you go to use your Pearl-2.
  • Page 180 Example of presets in action You could upload custom background images to Pearl-2 in advance of a conference and create custom channel configuration presets for several different keynote speakers, each with a different setup, and then apply them later when you need them. ...

  • Page 181: Configuration Preset Considerations

    At the conference, simply apply the configuration preset that you need for the appropriate session using either the Admin panel or the touch screen on Pearl-2. When applying the configuration preset, all other preset groups remain unchanged. The preset only affects channels and their configuration.
  • Page 182 Access to presets and privacy considerations   Recorded files are not removed when you apply a configuration preset. Any user with access to Pearl-2 has access to all the saved recordings, custom channel layout, etc that are associated with an applied configuration preset.
  • Page 183 Pearl-2 User Guide Configuration preset considerations Configuration presets that contain the channels configuration group specify the channels in the preset by their index number. This means if you have channels 1, 2, 3 and 4 when you save your preset, applying that preset will overwrite the configuration of your current channels with indexes 1, 2, 3 and 4.
  • Page 184 Pearl-2 User Guide Configuration preset considerations Recorded files in a channel or recorder A channel and recorder keep a list of recordings in the Recordings section in the Admin panel. These files remain on the system even if the channel or recorder configuration is changed or removed as a result of applying a configuration preset.

  • Page 185: Configuration Groups

    Reassign a registered resource. If you apply a configuration preset to set up a replacement Pearl-2 with the settings from a Pearl-2 that is currently registered with Kaltura, the replacement Pearl-2 assumes the identity of the registered resource. However, you risk having two active Pearl-2 resources with the same identity, which can effect recording and the content that's uploaded to Kaltura for scheduled events.
  • Page 186 Pearl-2 User Guide Configuration groups Table 31 Configuration group definitions Group Symbol Settings included in the configuration group Name Date and time settings, serial port settings, remote support settings, custom System disk check schedule, access passwords, deny/allow lists and LDAP configuration settings.

  • Page 187: The Factory Default Configuration Preset And Factory Reset

    The Factory default configuration preset and Factory reset Administrators can apply the default factory configuration preset to Pearl-2, which resets most of the settings in each of the main configuration groups. Applying the factory default configuration preset is similar to a factory reset, but a Factory reset is more invasive.

  • Page 188: Create A Configuration Preset

    Configuration groups for which settings are included in each group. After you're finished configuring your Pearl-2, it's good practice to save a full backup with all groups selected so that you can restore your full configuration at a later date.
  • Page 189 Pearl-2 User Guide Create a configuration preset   If you try to save a configuration preset but one or more of the related image files is missing, an error message is displayed. You'll be unable to save the preset until the missing files are restored or the layouts referencing the missing files are modified to remove the bad references.

  • Page 190: Apply A Configuration Preset Using The Admin Panel

    Pearl-2 User Guide Apply a configuration preset using the Admin panel What's next? You can export the configuration preset to your admin computer and then import it to another Pearl-2, see Export and import configuration presets, and you can Apply a configuration preset using the Admin panel Apply a configuration preset using the Admin panel When you apply a configuration preset, the system settings for all included configuration groups are updated.

  • Page 191: Apply A Configuration Preset Using The Touch Screen

    Apply a configuration preset using the touch screen You can use Pearl-2's touch screen to apply configuration presets. Configuration presets that only contain the network configuration group can also be applied using an alternative method, which is also described in this procedure.
  • Page 192 Pearl-2 User Guide Apply a configuration preset using the touch screen  3. Use the arrows at the bottom of the page to navigate through the list and tap the name of the preset you want to apply.  4. Click OK when prompted to apply the configuration preset. If the configuration preset includes the network or system configuration groups, a reboot is required.

  • Page 193: Export And Import Configuration Presets

    You can download configuration presets to your local computer, then upload and apply the preset to another Pearl-2 system or save the configuration preset as a backup of your current configuration. Either way, it's a simple two-step process to download the preset from one system and upload it to another.
  • Page 194 Pearl-2 User Guide Export and import configuration presets Import a configuration a preset using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. From the Configuration menu, click Maintenance. The maintenance page opens.

  • Page 195: Update A Configuration Preset

    Pearl-2 User Guide Update a configuration preset What's next After you upload a configuration preset file, you must apply the configuration preset to Pearl-2. To apply the configuration preset, see Apply a configuration preset using the Admin panel Apply a configuration preset using the touch screen.

  • Page 196: Delete A Configuration Preset

    Pearl-2 User Guide Delete a configuration preset  3. Copy the name of the preset you want into the Name field and select the configuration groups to include, then click Save.  4. Click OK when prompted to overwrite the existing configuration preset with the new one.
  • Page 197 Pearl-2 User Guide Delete a configuration preset  2. From the Configuration menu, select Maintenance. The maintenance page opens.  3. Click Delete beside the configuration preset that you want to delete, and then click OK when prompted.

  • Page 198: User Administration

    No password is assigned to these user levels by default and you cannot change the default user names or disable these user levels. When you log in to Pearl-2, you must log in as one of these three user levels. Private profiles with individually set passwords are not used.
  • Page 199 Operator The operator account allows users limited Pearl-2 configuration control with limited access to the web-based Admin panel, local console, and Pearl-2 remote login access. The default user name used to log in to Pearl-2 is operator. Operators can to do the following:  ...
  • Page 200 The viewer account is for all users who are permitted to view the streamed channels. The default user name used to log in to Pearl-2 is viewer. If no password is assigned, then viewers are not prompted for a user name and password to view a channel.
  • Page 201 Pearl-2 User Guide User types and privileges Action or Menu Option viewer operator admin ü ü Rename recorded files   Download recorded files   ü ü Delete recorded files   ü ü Input Source Operations View input source configuration   ü ü...
  • Page 202 Pearl-2 User Guide User types and privileges Action or Menu Option viewer operator admin System Configuration Operations View system configuration   ü ü Configure Automatic File Upload (AFU)     ü ü Select External USB drive behavior     Cancel USB file transfers  ...

  • Page 203: Assign Administrator Privileges To Operators

      ü Assign administrator privileges to operators Pearl-2 administrators can assign additional administrative-level privileges to operators from the Security menu in the Admin panel. The following table lists the available options and their associated privileges. Table 34 Options with additional operator privileges...
  • Page 204 Disable CMS or deregister Configure CMS settings and default event parameters Configure Automatic File Upload (AFU) Select external USB drive behavior Configure Pearl-2 as an FTP server System configuration Configure UPnP sharing Configure the date and time preferences Configure the touch screen...
  • Page 205 Pearl-2 User Guide Assign administrator privileges to operators Option Operator admin functions Upgrade firmware Apply configuration presets Enable remote support Reboot device (Admin panel) Maintenance configuration Shutdown device (Admin panel) Restore factory configuration Configure the device name, location, and description Perform disk check...

  • Page 206: Set Or Change User Passwords

    Admin and operator-level users have access to the Admin panel to control Pearl-2. If the admin password is defined and the operator password is undefined, by default the operator must use the admin password.

  • Page 207: Remove User Passwords

    Pearl-2 User Guide Remove user passwords Changing the admin password while live streaming disrupts the view of the stream for viewer-level users. Complete any admin password changes when there is no live stream in progress. Set a user password using the Admin panel  1.

  • Page 208: Overcome Lost Passwords

    If remote support is disabled, you must return the system to Epiphan for password recovery. Contact Epiphan support. Alternatively, you can regain access to Pearl-2 if you apply the factory default configuration preset using the touch screen, see Apply a configuration preset using the touch screen.
  • Page 209 Pearl-2 User Guide Configure LDAP user authentication When enabled, LDAP authentication is an alternative to the regular system user names and passwords. You may still login as admin, operator or viewer using the passwords for those accounts. LDAP replaces the local viewer account instead of working side-by-side with it when LDAP is enabled and the viewer account has no password (either there is no global viewer password configured or the channel overrides the global password with a blank password).
  • Page 210 Pearl-2 User Guide Configure LDAP user authentication Connection Description/Default port used encryption No Encryption No encryption is used to connect to the LDAP server. The default port is 389. SSL encryption is used to connect to the LDAP server. The default port is 636.

  • Page 211: Change The Logged-In User

    After you log in to the Admin panel as an Administrator or Operator, your browser remembers this configuration and automatically logs you in using the same user account the next time you log in to Pearl-2. Log in using a different user account  1.
  • Page 212 Pearl-2 User Guide Restrict viewers by IP address Item Description to a rule in the allow list. If your viewer account has a password, your viewers must connect to the system from a computer (or gateway) with a permitted IP address and must also supply the user name (viewer) and password before they can view the broadcast.

  • Page 213: Ip Restriction Examples

    Pearl-2 User Guide IP restriction examples  5. Enter the allowed IP addresses or address ranges in the Allow IP’s field and enter denied IP addresses or address ranges in the Deny IP's field. Separate addresses with a comma. To specify a range, use a hyphen (-).
  • Page 214 Pearl-2 User Guide IP restriction examples Example Description 192.168.1.250) and also want to add the desktop, laptop and tablet computers of the CEO (IP addresses 192.168.1.50, 192.168.1.51, and 192.168.1.75, respectively). Note the first two IP addresses are consecutive, so they can be added as a second range. Add these IP addresses to the list as...
  • Page 215 Pearl-2 User Guide IP restriction examples Example Description computers except the boardroom computer: Deny: 192.168.1.211 As with allow lists, your deny list can specify a range of IP addresses, and can specify multiple ranges or distinct IP addresses in a comma-separated list.

  • Page 216: Status And Monitoring

    Monitoring audio and VU sensitivity You can connect headphones to the 3.5 mm audio jack on the front panel of Pearl-2. To monitor audio for a specific channel, just select the channel using the touch screen. The audio you hear depends on which layout is currently live because different layouts can have different audio sources configured.

  • Page 217: Channel Monitoring Using The Touch Screen

    The grid view opens by default when you turn on Pearl-2. If necessary, tap the touch screen once to turn it on and tap again to display the controls.
  • Page 218 Pearl-2 User Guide Channel monitoring using the touch screen Item Description Streaming has an error and recording is started. Streaming is disabled and recording is started. TIP: You stop and start recording from the individual channel view. Each channel has an audio VU meter that uses quasi-peak ballistics with samples averaged every 10 ms.

  • Page 219: View System Information Using The Touch Screen

    To get back to the grid view, tap the grid icon View system information using the touch screen Find the serial number, check the installed firmware version of your Pearl-2 and more on the System Status screen using the touch screen.
  • Page 220 Pearl-2 User Guide View system information using the touch screen Label Description Device Information   Serial number   Video grabber number   Firmware version Network Information   IP Address   MAC Address Device Status   System date   System time  ...
  • Page 221 Pearl-2 User Guide View system information using the touch screen  1. Tap the gear icon. If the control icons aren't showing, tap anywhere on the touch screen.  2. Tap System Status to see the System Status page.  3. Tap CPU load to toggle between the operating temperature (°Celsius) and CPU load (%).

  • Page 222: View System Information Using The Admin Panel

    View system information using the Admin panel View system information using the Admin panel Get useful information about your Pearl-2 on the Info page from the Configuration menu. You can view your current firmware level, the system hardware version (if available), and currently configured settings for a channel.
  • Page 223 Pearl-2 User Guide View device information using the touch screen  1. Tap the gear icon. If the control icons aren't showing, tap anywhere on the touch screen.  2. Tap System Status to see the System Status page.  3. Tap below Device to show the device information. Tap a second time to show the serial number, grabber, and firmware values again.

  • Page 224: View Network Status

    If the system settings control icon won't appear when you tap the touch screen, it may be disabled. See Configure the touch screen to enable system information. View network status Get useful status information about your Pearl-2 network connection from the Network configuration page using the Admin panel, including:  ...

  • Page 225: View Channel Status And Stream Information

    View channel status and stream information If you attempt to connect to a network that isn't 802.1x enabled when 802.1x is configured on Pearl-2, a consistent 802.1x status: failed status message appears on the Network Configuration page in the Admin panel.
  • Page 226 Pearl-2 User Guide View channel status and stream information Active unicast and multicast stream information displays under Connections. NDI connections aren't currently displayed on the channel's status page under Connections.

  • Page 227: View The Video Output Port Status

    Pearl-2 User Guide View the video output port status View the video output port status The current status of the video output port and attached video display appears at the top of the video output port configuration page. You can view the status using the Admin panel.

  • Page 228: View Afu And File Transfer Progress

    In this example, AFU is scheduled to occur at specified time intervals so the start of the next scheduled file transfer is shown. If the Pearl-2 is configured to allow copying recordings to a connected USB drive instead of AFU, the USB drive status displays. If AFU is not enabled, the screen displays AFU File upload is disabled.
  • Page 229 Pearl-2 User Guide View AFU and file transfer progress For more information, see Manage the AFU queue Manage USB file transfer queue View file transfer status using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.
  • Page 230 Pearl-2 User Guide View AFU and file transfer progress  1. Tap the gear icon. If the control icons aren't showing, tap anywhere on the touch screen. If the gear icon is not visible on the touch screen, tap the screen once to activate the control buttons.

  • Page 231: View Scheduled Cms Events And History

    Using the Admin panel, select the Events menu to see up to 90 days of upcoming scheduled events and up to 90 days of ongoing and completed events for this Pearl-2 resource. Click the page arrows at the bottom of each list to navigate through multiple pages.
  • Page 232 Pearl-2 to match the time and zone of Kaltura's scheduling server, see Configure date and time. From the touch screen on Pearl-2, you can tap the Scheduled events icon at any time to display the Events screen. The icon only appears when Kaltura or Panopto CMS is enabled on Pearl-2.

  • Page 233: Part 2: Capture

    PART 2: Capture Capturing is the process of taking the signals from your video and audio sources and encoding them so they're ready for streaming and recording. You add the captured video and audio to channels, which you customize for live streaming, switching, and recording. This section covers how to create channels and add custom layouts so that you can capture, stream, and record exactly what you want - how you want! Whether that's a simple channel with a single video and audio source or channels that have multiple video and audio sources and custom layouts like picture in picture.

  • Page 234: What Is A Channel

    What is a channel? Your video and audio sources that are connected to the input ports on Pearl-2 can be combined and added to a channel, which you can stream and record. A channel is essentially an encoding instance that you associate with your video and audio inputs to produce outputs such as video recordings and live streams.

  • Page 235: Channel Layout Examples

    Pearl-2 User Guide Channel layout examples Important note for channels with multiple layouts When a channel has only one layout and that layout has only one video source, the default channel name is the same as the name of the video source. So for example, a channel with one layout that has HDMI-A in it is named HDMI-A by default.
  • Page 236 Pearl-2 User Guide Channel layout examples Layout example Description One video source with a logo (.png with transparency) in the bottom left corner. To get this look: Upload an image with transparency. Using the custom layout editor, add one video source to the layout, select keep aspect ratio and stretch to fill the entire layout area.
  • Page 237 Pearl-2 User Guide Channel layout examples Layout example Description Two video sources (a slideshow and a presenter cropped to a new aspect ratioCrop a video source), a background image, and a logo. Make sure the background image has the correct aspect ratio.

  • Page 238: About Automatic Channels Auto A And Auto B

    About automatic channels Auto A and Auto B To get you started as quickly as possible, Pearl-2 comes pre-configured with two automatic channels called Auto A and Auto B. Simply plug a source into one of the "A" inputs and a second source into one of the "B"...
  • Page 239 If you attach more than one video source to the "A" inputs while Pearl-2 is powered on, the first source you attach has the highest priority. If you attach more than one source to inputs that are labeled with the same...
  • Page 240 Pearl-2 User Guide About automatic channels Auto A and Auto B Priority Connector Type USB video (with USB audio) The auto channel uses a source until that source no longer has a signal. Then, it switches to the next highest priority signal.

  • Page 241: Channel Configuration

    Channel encoding settings may be automatically overwritten when using Pearl-2 with a Content Management System, see About Panopto recording and webcasting Topics include:  ...

  • Page 242: Configure An Auto Channel

    Configure an auto channel Configure an auto channel Auto channels are included with Pearl-2 to make setup quick and simple. However if you want to set custom encoding or streaming configuration for the channel, you can configure it like any other channel.

  • Page 243: Create A Channel

    Create a channel You create channels on Pearl-2 using the Admin panel. New channels automatically use the same aspect ratio as the default frame size setting for the channel, which is 16:9. You can change the encoding settings for a channel after the channel is created.
  • Page 244 Pearl-2 User Guide Create a channel  3. Click Add new item and select Video Source.  4. From the Source settings, select a video source in the Source drop down.
  • Page 245 Pearl-2 User Guide Create a channel For best results, Keep aspect ratio when scaling should be checked under Source settings. The selected video source appears in the layout area.  5. Click and drag the red and white handles on the corners of the source to re-size it in the layout editor area.

  • Page 246: Add Video Sources Or A Channel As A Source

    Pearl-2 User Guide Add video sources or a channel as a source If a channel is selected as a video source, the corresponding audio for that channel is selected by default.  7. Click Save. Your channel is ready for basic streaming and recording.
  • Page 247 Pearl-2 User Guide Add video sources or a channel as a source If more than one video source is added to a channel, we recommend configuring the channel encoding to use a fixed resolution as the frame size instead of automatically using the resolution of the video source as the frame size (default).
  • Page 248 Pearl-2 User Guide Add video sources or a channel as a source For best results, check Keep aspect ratio when scaling in the Source settings. The selected video source appears in the layout editing area. When adding an RTSP network source, a preview image may not display in the layout area until you Save the layout.
  • Page 249 Pearl-2 User Guide Add video sources or a channel as a source To layer video sources over top of each other, like for picture in picture, you can click and drag the video sources that appear in the item list beneath Add new item and change their order.

  • Page 250: Add An Audio Source To A Layout

      The XLR-B audio inputs and the RCA audio inputs are linked within Pearl-2. If you use both at the same time, their audio is mixed. If the two audio sources share the same audio signals, the common audio...
  • Page 251   If an audio source is added to a layout and then the audio device is disconnected from the input port on Pearl-2, some residual noise may be detected in the layout. Remove the audio source from the layout. Add an audio source to a layout using the Admin panel  1.

  • Page 252: Duplicate A Channel

    Pearl-2 User Guide Duplicate a channel What's Next You can check the audio encoding settings for your channel and ensure that audio is enabled, see Configure encoding. To adjust the gain for an audio input source, see Adjust audio gain and delay.

  • Page 253: Rename A Channel

    To revert the channel name back to the auto channel's default name, delete the channel name and leave the name field blank. When you save, Pearl-2 will automatically repopulate the name field with the default name.

  • Page 254: Delete A Channel

    Delete a channel Do not include any special currency, mathematical symbols, and other special characters such as slashes or spaces in the channel name. Pearl-2 replaces special characters with an underscore. Rename a channel using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.

  • Page 255: Preview A Channel

    Pearl-2 User Guide Preview a channel Delete a channel using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. From the Channel menu, select a channel and click Status. The Status page for the channel opens.
  • Page 256 PCM audio encoding with a sampling bitrate of 48 kHz.   If HTTPS is configured for Pearl-2, the live broadcast URL will start with https instead of http. The Info page has preview links for all the channels that are configured on Pearl-2.
  • Page 257  1. Open a new tab in your web browser on the Admin computer.  2. Go to the following URL to open the preview web page for your Pearl-2, where <ip address> is the IP address of Pearl-2. To find the IP address of your system, see...

  • Page 258: Add Or Remove Channel Metadata

    Pearl-2 User Guide Add or remove channel metadata where<ip address> is the IP address of Pearl-2 and X is the channel's index number. Add or remove channel metadata When you configure metadata for a channel, that metadata is embedded in all channel recordings and streams.

  • Page 259: Configure Encoding

    Table 42 Supported video codes Value Description H.264 is the default video codec configured for the channels on Pearl-2. This codec H.264 provides high quality video while using low bandwidth and is the preferred codec to use with the system.
  • Page 260 Pearl-2 User Guide Codecs and file format compatibility Value Description The maximum bitrate for mono encoding of a 44 kHz signal is 264 kbps. For stereo, 320 kbps is supported. Note that lower bitrates (e.g. 32 kbps) with a 44 kHz signal may result in distorted audio.

  • Page 261: Configure Video Encoding

    Options are H.264 (default) and Motion JPEG.   Hardware or software encoding: Hardware encoding is the default setting and is the recommended encoding for use with Pearl-2.   Video encoding profile: This can be set to High, Main, or Baseline.
  • Page 262 Bitrate value. Video with a high level of motion and high resolution, such as sporting events, requires a higher bitrate. By default, Pearl-2 automatically uses the incoming video source frame size as the frame size for streaming and recording when the channel has only one layout with a single video source. If you're channel has multiple video sources or layouts, you must manually set a frame size for the channel.
  • Page 263 Pearl-2 User Guide Configure video encoding smaller frame size for the channel and let Pearl-2 downscale the video. For example, if the input video signal resolution is 1920×1080 (a 16:9 aspect ratio) and the channel's frame size is set to 1280×720, Pearl-2 downscales the video and streams/records the channel at the lower frame size, using less bandwidth and producing smaller recorded files.
  • Page 264 Pearl-2 User Guide Configure video encoding Setting Description pixels;   available network bandwidth;   the source and stream frame size (resolution);   the type of motion that is captured; and   number of users accessing the stream. When adjusting the frame rate, you may need to try different values to achieve the best outcome.
  • Page 265 Pearl-2 User Guide Configure video encoding  2. Select a video Codec and do one of the following:  a. If Motion JPEG is selected, click Page refresh time and enter a time in seconds.  b. If H.264 is selected, select a Video encoding preset and a Video encoding profile.

  • Page 266: Configure Audio Encoding

    Pearl-2 User Guide Configure audio encoding  b. Select a Frame size from the list of options or enter a custom frame size in pixels.  4. Change the Limit frame rate. The default should be adequate in most applications. While decreasing...
  • Page 267 Pearl-2 User Guide Configure audio encoding Value Description Most digital signals (HDMI or SDI sources) use 48 kHz audio. Matching the encoded level with the source level provides the best sound quality by avoiding audio resampling. For analog signals, 44 kHz provides higher sampling.

  • Page 268: Multi-Encoding And Channel As A Source

    256 kbps or 320 kbps.  7. Click Apply. Multi-encoding and channel as a source Pearl-2 lets you easily do multi-encoding so you can record and stream the same content at different encoding settings. This is useful when you want to:  ...
  • Page 269 Pearl-2 User Guide Multi-encoding and channel as a source Follow these steps:  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. Create Channel 1 with your video and audio inputs. Add all your live switching layouts.

  • Page 270: Custom Layout Configuration

    When you add multiple layouts to a channel, you can switch between the different layouts for a more interesting and dynamic presentation. Each layout you add to your channel adds overhead to Pearl-2, and more complex layouts consume more of the system's resources. So, it's a good idea to delete any layouts you're not using.
  • Page 271 Pearl-2 User Guide About the custom layout editor Layout editing Below the layout list is the layout editing area where you can add images, add and edit video sources, and add text overlays to your layout. You can also choose the backgro und matte, as well as crop images and video.

  • Page 272: Move And Size Items In The Layout Editing Area

    Pearl-2 User Guide Move and size items in the layout editing area Move and size items in the layout editing area You can use the mouse to click and drag an image, text overlay, or video source into position, or you can type values into the fields along the side and bottom of the layout area and manually position the selected item.

  • Page 273: Audio Source Selection And Saving Edits

    Pearl-2 User Guide Audio source selection and saving edits If you need to specify an exact amount in pixels (rather than percent) you can type a pixel value in any of the positioning value squares followed by the characters px (e.g. 56px). You can mix and match pixels and percents changing only the boxes you want to use pixel values.

  • Page 274: Resize And Position Items Using Percents Or Pixels

    Pearl-2 User Guide Resize and position items using percents or pixels Resize and position items using percents or pixels You can resize layout items (images, overlay text, and multiple video sources) using the percent/pixel adjustment boxes in a layout using the custom layout editor. You can also reposition video sources. See...
  • Page 275 Pearl-2 User Guide Resize and position items using percents or pixels Table 48 Adjustment boxes for item resizing and positioning Item Description The area of your layout item. The four red/white dots represent the boundaries of your layout item. There may be some black space between your item and its boundaries if Keep aspect ratio...
  • Page 276 Pearl-2 User Guide Resize and position items using percents or pixels Item Description If using percents, this is the items percentage of total height on the layout's vertical axis. (I.e. the item takes up 80% of the layout's height – represented by a thin red bar to the left of the percent box).
  • Page 277 Pearl-2 User Guide Resize and position items using percents or pixels In the example, the presenter video source is resized to 60% of the layout's width and 70% of the layout's height (with aspect ratio maintained). (Alternatively, pixels could be used to resize the layout item in a similar fashion.)
  • Page 278 Pearl-2 User Guide Resize and position items using percents or pixels   Alternatively, you can position your layout items using the keyboard by selecting the item with your mouse cursor, and pressing the arrow keys to move the selected item by 5% in any direction.
  • Page 279 Pearl-2 User Guide Resize and position items using percents or pixels For example, using pixels to move a layout item that is set to 756px in height to the top of the layout while leaving a small margin of background (say 25px), you could either enter "25px" into the top percent box (to specify the small margin from the top down) or enter 27% into the bottom percent box (to specify a 27% margin from the bottom up –...

  • Page 280: Open The Custom Layout Editor For A Channel

    Pearl-2 User Guide Open the custom layout editor for a channel Open the custom layout editor for a channel  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. From the Channels menu, select the channel and click Layouts. The custom layout editor opens.

  • Page 281: Configure A Custom Layout For A Channel

    Pearl-2 User Guide Configure a custom layout for a channel Configure a custom layout for a channel If you want to do live switching on your channel for a more dynamic video presentation, then you need to add different layouts that you can switch between. We recommend that you rename your channel and layouts to...
  • Page 282 Pearl-2 User Guide Configure a custom layout for a channel  2. From the Channels menu, select the channel and click Layouts. The custom layout editor opens.  3. Select a layout from the layout list or click Add Layout to create a new layout. If this is a new channel or layout, the layout area is empty and you see a black background matte.

  • Page 283: Rename A Layout

    If you're using the touch screen for live switching, consider using shortened names for layouts. Long names get truncated on the touch screen. You can include certain international characters in layout names. Pearl-2 supports common character sets for Western and Central European languages, Nordic languages, and Russian. For a complete list, see...

  • Page 284: Delete, Move, Or Duplicate A Layout

    Pearl-2 User Guide Delete, move, or duplicate a layout  4. Click the name of the layout so that the name turns red. Type a new name and then press the Enter key. Delete, move, or duplicate a layout Layouts appear listed in the layouts list in the same order that they are presented on the touch screen. It's simple to re-order, remove, and duplicate layouts using the custom layout editor.
  • Page 285 Pearl-2 User Guide Delete, move, or duplicate a layout  2. From the Channels menu, select a channel and click Layouts. The custom layout editor opens.  3. In the layouts list, click and drag the icon with the three horizontal bars at the left side of the row to rearrange the order of your layouts.

  • Page 286: Set The Background Color

    Pearl-2 User Guide Set the background color  4. Click OK. Set the background color You can select the background color to fill any unused space in a layout using the custom layout editor. For example you can add a color from your corporate color scheme.
  • Page 287 Add an image to a layout Pearl-2 supports .PNG and .JPEG images up to a maximum size of 4096×2160. For many applications like a background, you will want your image to have the same aspect ratio as the channel in which the image appears.
  • Page 288 Pearl-2 User Guide Add an image to a layout For best results, check Keep aspect ratio when scaling in the Source settings.  5. Your picture appears in the Picture settings preview and is added to the layout area.  6. In the layout area, use the mouse, the keyboard or the manual position value fields to position and resize your image.

  • Page 289: Upload Or Remove An Image Using The Media Page

    Pearl-2 User Guide Upload or remove an image using the Media page  7. Re-order the items in your layout by clicking and dragging items in the item list. To layer items over top of each other, like for background images or a transparent logo, you can click and drag elements that appear in the item list beneath Add new item and change their order.
  • Page 290 Pearl-2 User Guide Upload or remove an image using the Media page For best results always upload images that are already the correct size needed in your layout. Background images should match the frame size of your channel (frame size is set in the Encoding configuration page).

  • Page 291: Add A Text Overlay

    Pearl-2 User Guide Add a text overlay If you delete an image that is used as part of the layout for any channel, select a different image or no image by using the drop-down list in the Picture settings box within that channel's layout before deleting the file using the steps below.
  • Page 292 (assuming the total number of characters in the text string doesn't change). You can include certain international characters in text overlays. Pearl-2 supports common character sets for Western and Central European languages, Nordic languages, and Russian. For a complete list, see...
  • Page 293 Pearl-2 User Guide Add a text overlay You can change the order in which items appear on the layout editing area by re-arranging the order the items appear in the list beneath Add new item. Items at the top of the list appear in front, and items lower down the list appear behind.

  • Page 294: Custom System Variables For Text Overlays

    Pearl-2 User Guide Custom system variables for text overlays  6. Resize the overlay text box using the padding settings. The handles on the corner of the overlay text box are not click-and-drag and do not resize the text box. To resize the text box, use the padding fields to add space above, below, and on either side of the text.

  • Page 295: Crop A Video Source

    Cropping a source gives you a lot of advantages and can help to conserve the overall amount of processing CPU usage for your Pearl-2. You can capture a 1080p section from a 4K source, a specific aspect ratio or size from a source, or select a crop that fits into your layout better than the full area of your video.
  • Page 296 Pearl-2 User Guide Crop a video source  4. Click Crop. Your video source appears in a pop-up editing window.  5. The Crop window has several tools for creating the best crop possible.   Free form is the default crop mode. In this mode, you can change the size, aspect ratio, and position of the crop with minimal restrictions.
  • Page 297 Pearl-2 User Guide Crop a video source you can alter the size by dragging the red handles. When you have selected a size, you can change its position by dragging the box.   The number boxes allow you to make precise crops. Click the text boxes and enter a number to determine how many pixels of distance from the edge that line is drawn.

  • Page 298: Configure Chroma Keying

    Configure chroma keying Pearl-2 supports chroma keying so you can add special effects to any video source in a custom channel. Add great looking effects such as animated lower thirds using a titler software or add a custom background using green screen.

  • Page 299: Performance Considerations

    Pearl-2. You can monitor the performance of Pearl-2 from the Info tab using the Admin panel for the custom channel that has chroma keying enabled. For more information about performance monitoring, see What is Pearl-2?.

  • Page 300: What Is Downstream Chroma Keying

    What is downstream chroma keying? To get an upstream key effect using Pearl-2, you can create custom layouts for each video source using the custom layout editor. Then set up chroma keying on just one custom layout. Only the video source that appears in the custom layout with chroma key enabled has the chroma key effect applied to it.

  • Page 301: Set Up Chroma Key For A Green Screen Video Source

    A common use of downstream keying is to display a persistent image, like a company logo, so that it always appears on screen. To get a downstream key effect using Pearl-2, you can enable the same chroma key effect on all your custom layouts. This way, the same chroma key effect gets applied to everything you stream or record.
  • Page 302 Your chroma key source can come from a video camera or an effects computer connected to Pearl-2. The background you use can be from another video source, a still image that you've uploaded to Pearl-2, or from an effects computer.
  • Page 303 Click OK when your done to return to the custom layout editor. Cropping the green screen video source helps optimize the performance of Pearl-2.  8. In the layout area, position the green screen video source over top the other video source. To optimize...
  • Page 304 Pearl-2 User Guide Set up chroma key for a green screen video source  9. With the green screen video source selected, check Enable Chroma keying in the custom layout editor. The chroma keying options appear.
  • Page 305 Pearl-2 User Guide Set up chroma key for a green screen video source White, grey, and black are not recommended colors for chroma keying. Pearl-2 treats them as the same color with different luminance values. As such, chroma keying affects all shades ranging from white to black.
  • Page 306 Pearl-2 User Guide Set up chroma key for a green screen video source  12. Click Save when you're done. A note about item positioning and sizing There are multiple ways to position and size images, text overlays, and video sources in the layout area  1.

  • Page 307: Add Chroma Key Titler Effects Using Microsoft Powerpoint Slides

    Add chroma key titler effects using Microsoft Powerpoint slides You can use the chroma key feature on Pearl-2 with Microsoft Powerpoint slides to add animated titles and other Powerpoint effects. The setup is really the same as using a dedicated titling software on an effects computer with Pearl-2.
  • Page 308 Add chroma key titler effects using Microsoft Pearl-2 User Guide Powerpoint slides  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. Follow the steps in Configure a custom layout for a channel to create a custom channel.
  • Page 309 Add chroma key titler effects using Microsoft Pearl-2 User Guide Powerpoint slides Cropping the Powerpoint computer video source helps optimize the performance of Pearl-  8. In the layout area, position the Powerpoint video source over top the other video source. To optimize...
  • Page 310 Add chroma key titler effects using Microsoft Pearl-2 User Guide Powerpoint slides  9. With the Powerpoint video source selected, check Enable Chroma keying in the custom layout editor. The chroma keying options appear.
  • Page 311 Add chroma key titler effects using Microsoft Pearl-2 User Guide Powerpoint slides  10. Click the eye dropper and then click on a color in the thumbnail image to choose the chroma key color. The background video image shows through all the colored areas on the chroma key video layer that match the color you select as the chroma key.

  • Page 312: Add External Titler Software Effects To Pearl-2

    See Resize and position items using percents or pixels for more information. Add external titler software effects to Pearl-2 You can use Pearl-2 with titling software that provides chroma key output to add effects like animated lower thirds.
  • Page 313 This example shows an HDMI camera connected to the HDMI-A port on Pearl-2 and an effects computer with titler software connected to the HDMI-B port. To the computer, Pearl-2 is treated just like an external display. You can connect the effects computer with the titling software to any supported port that is available on Pearl-2.
  • Page 314 Pearl-2 User Guide Add external titler software effects to Pearl-2  4. Click Source and select the video source that you want showing in the background. For detailed steps, Add video sources or a channel as a source.  5. In the layout editing area, click and drag to position the video. See the note after this procedure for positioning techniques.
  • Page 315 Pearl-2 User Guide Add external titler software effects to Pearl-2 Cropping the effects computer video source helps optimize the performance of Pearl-2.  8. In the layout area, position the effects video source over top the other video source. To optimize...
  • Page 316 Pearl-2 User Guide Add external titler software effects to Pearl-2  9. With the effects video source selected, check Enable Chroma keying in the custom layout editor. The chroma keying options appear.
  • Page 317 Pearl-2 User Guide Add external titler software effects to Pearl-2  10. Click the eye dropper and then click on a color in the thumbnail image to choose the chroma key color. The background video image shows through all the colored areas on the chroma key video layer that match the color you select as the chroma key.
  • Page 318 Pearl-2 User Guide Add external titler software effects to Pearl-2 A note about item positioning and sizing There are multiple ways to position and size images, text overlays, and video sources in the layout area  1. Using the mouse.  2.

  • Page 319: Video And Audio Input Sources

    The Admin panel automatically discovers all video and audio sources that you connect to the input ports on Pearl-2 and lists them in the Inputs menu of the Admin panel. You can also configure a video source's settings using the Admin panel.
  • Page 320 Audio Audio input port: XLR or RCA You can also connect RTSP sources such as IP cameras and even another Pearl-2 over the network using the Admin panel. Application of amplified speaker signals to the audio line inputs exceeds the recommended ratings and may permanently damage the device.
  • Page 321 Add a custom No Signal image Audio mixers and other line level devices can be connected to the XLR and RCA audio input ports on Pearl-2. Embedded audio from sources connected to the HDMI, SDI, and USB video ports is also supported. For...
  • Page 322 About connecting video and audio sources Tested RTSP-based IP cameras Pearl-2 is compatible with all Ethernet-based IP cameras and other RTSP sources. The cameras listed in the following table represent a sample of common third-party cameras that have been tested to work with Pearl- 2.
  • Page 323 Pearl-2 supports most webcams and USB audio sources, such as USB microphones. The following list of web cameras have been tested for compatibility with Pearl-2. If your web camera doesn't appear in the list, that just means your model hasn't been tested. It's likely that it will work without any issues.

  • Page 324: Connect An Rtsp Source

    720p. If no settings are changed, the camera simply outputs video at 720p in this case. Connect an RTSP source You can connect RTSP sources such as IP cameras and other Pearl-2 systems to your Pearl-2 over a network using the Admin panel. For a list of tested cameras and their URL syntax, see Tested RTSP-based IP cameras.
  • Page 325  2. From the Inputs menu, click Add input, and then click Add RTSP input The RTSP input page opens.  3. Enter the Input URL, Username and Password for your RTSP source and select either UDP or TCP as the Preferred transport. If you're using another Pearl-2 as an RTSP source, see Share a live broadcast stream (HTTP, HTTPS or RTSP).
  • Page 326 Pearl-2 User Guide Connect an RTSP source  4. (Optional) Select Use hardware acceleration for improved performance (default).  5. (Optional) Rename the RTSP source, see Rename an input port.  6. (Optional) Configure a custom "No signal" image, see Add a custom No Signal image  7.

  • Page 327: Connect An Srt Stream As An Input

    (decoders), such as CDNs and other SRT decoders such as a Pearl-2. You can configure Pearl-2 as an SRT destination (decoder) and ingest SRT streams as video inputs that you can add to custom layouts for switching, recording, and streaming.
  • Page 328 Connect an SRT stream as an input When adding an SRT input on Pearl-2, be sure to select the correct SRT mode. For example, if the SRT source stream is using rendezvous mode, ensure you set the SRT input on Pearl-2 to rendezvous mode. If the SRT source stream is using caller mode, then set the SRT input on Pearl-2 to listener mode.
  • Page 329 Network ports used by Pearl-2 to determine available ports.  c. If Rendezvous mode is selected, enter the URL of the SRT source (encoder) using the format srt://<encoder-ip-address>:<port>, where the <encoder-ip-address> and <port> values are provided by the SRT encoder device such as a second Pearl-2.

  • Page 330: Connect An Ndi Source

    Connect an NDI source ® lets you to transmit and receive low latency video over Gigabit Ethernet networks. Pearl-2 accepts multicast and unicast NDI video content, high efficiency NDI|HX, and supports Alpha channel. Video and audio can come from a variety of NDI sources, including:...
  • Page 331 Pearl- Pearl-2 shows up on the network as an NDI resource for other NDI devices to access as soon as an NDI stream is started on Pearl-2, see Start and stop an NDI stream.
  • Page 332 NDI resources in that group. Select Add beside an NDI resource to select  c. If a remote NDI resource is on a different network or subnet than Pearl-2, or the network has mDNS disabled, enter the IP address of the remote NDI resource in the Extra source IP addresses field, then click Discover.

  • Page 333: Change An Ndi Input Resource

    If you created an NDI input on Pearl-2 without assigning an NDI resource to it, you can go back later and assign one. You can also change the assigned NDI resource at any time from the NDI input configuration page using the Admin panel.

  • Page 334: Connect An Av.io Video Grabber

    Connect an AV.io video grabber You can connect an Epiphan AV.io frame grabber to a USB input port just the same as you would connect a web camera. Pearl-2 treats the video source from the frame grabber just like any other video source.

  • Page 335: Preview A Video Source Using The Admin Panel

    Preview a video source using the Admin Panel Use AV.io frame grabbers to connect extra HDMI, DVI, or SDI sources. Using AV.io HD, you can add up to two VGA sources to Pearl-2. You can set up and operate frame grabbers using the same Configure a video input source  ...

  • Page 336: Rename An Input Port

    Rename a channel. You can include certain international characters for video and audio input port names. Pearl-2 supports common character sets for Western and Central European languages, Nordic languages, and Russian. The name should not include special characters, slashes, or spaces. For a complete list, see International character support.

  • Page 337: Configure A Video Input Source

    Captured video sources don't usually need configuration, but you can change some of the video settings using the Admin panel, including:   HDMI and DVI video settings   SDI video settings   USB video and web camera settings For details to configure networked video sources on your Pearl-2 like RTSP, NDI, and SRT, see:...

  • Page 338: Hdmi And Dvi Video Settings

    Pearl-2 User Guide HDMI and DVI video settings   Connect an RTSP source   Connect an NDI source   Connect an SRT stream as an input Open the configuration page for an input source using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.

  • Page 339: Sdi Video Settings

    Selecting this option means that your 4K UHD source will be automatically downscaling downscaled to 1080p using Pearl-2's hardware. This menu allows you to choose a custom no-signal image for the channel. The Image drop-down list gives you the option to choose the default image or any image...

  • Page 340: Usb Video And Web Camera Settings

    Pearl-2 User Guide USB video and web camera settings Value Description This menu allows you to choose a custom no-signal image for the channel. The Image drop-down list gives you the option to choose the default image or any image...
  • Page 341 Pearl-2 User Guide USB video and web camera settings Value Description This feature is useful for simultaneously dictating the resolution and fps at which Capture mode the video source is captured. The drop down list of available resolutions and frame rates changes depending on the attributes of the connected device.
  • Page 342 Pearl-2 User Guide USB video and web camera settings Value Description is achieved. The contrast of the video can be adjusted by entering a numerical value from 0 to Contrast 100. Estimate values and view the result in the preview area until desired result is achieved.

  • Page 343: Add A Custom No Signal Image

    (or expected resolution time) using the no signal image. Before you can specify a custom No Signal image for an input port on Pearl-2, you must upload it, see Upload or remove an image using the Media page.

  • Page 344: Part 3: Stream

    Smart TVs, and Content Distribution Networks. Pearl-2 is flexible, easy to setup, and supports all the standard codecs, as well as the most common media players. Streaming options include: unicast, multicast, SRT, HLS, MPEG-DASH, RTMP, SAP, UPnP, and more.

  • Page 345: What Is Streaming

    Pearl-2 provides many different streaming options and supports a variety of streaming protocols. Probably the easiest way to stream a single Pearl-2 channel directly to viewers on the same local network is to share the channel's live broadcast URL. Various stream types are available so users can watch using their favorite devices, including: HTTP/HTTPS, HTTP FLASH (.FLV), MPEG-TS (HTTP), and RTSP.

  • Page 346: Streaming To A Cdn, Multicasting, And Streaming To Multiple Destinations

    Streaming to a CDN, multicasting, and streaming to Pearl-2 User Guide multiple destinations   Are you streaming live video or recorded video?   Do you need to stream the content to one client (peer-to-peer) or deliver a single stream to multiple clients (multicast)?  ...
  • Page 347 Multicasting is useful for training sessions when there is a specific time frame for the audience to view the content live. Whether you're streaming to CDNs or multicasting across a LAN, Pearl-2 can publish to multiple destinations at the same time. Streaming a channel to CDNs and multicast streaming at the same time is available only when the H.264 codec is configured as the channel encoding, see...
  • Page 348 Streaming to multiple destinations There are a few different ways to stream to multiple destinations using Pearl-2. One option is to configure a channel on Pearl-2 as your switched program channel, then use the Admin panel to create multiple streaming destinations for that channel.

  • Page 349: Directly Sharing Channel Stream Urls With Viewers

    Directly sharing channel stream URLs with viewers People on the same local network as Pearl-2 can easily view a channel's live broadcast stream. You can provide people separate URLs for streams coming from each channel, or one URL that includes all the streams for the channel.

  • Page 350: About Streaming Using Srt

    You can configure Pearl-2 as an SRT source encoder and stream video using SRT. You can also configure Pearl- 2 as an SRT decoder and ingest SRT streams as video inputs.
  • Page 351 Pearl-2 User Guide About streaming using SRT Up to six of the video inputs configured for Pearl-2 can come from SRT sources (or one 4K SRT input) and Pearl-2 can stream up to six SRT streams. Before content is streamed between the SRT source and destination, a communication link must be established between them for SRT control and recovery packets.

  • Page 352: Secure Streaming

    SRT includes latency controls to adjust for poor network quality while maintaining an acceptable amount of delay. Pearl-2 provides statistics to determine the amount of packet loss. Using the Admin panel, you can increase or decrease the amount of latency applied to the stream to help mitigate any Quality of Service (QoS) issues.

  • Page 353: Suggested Stream Settings

    The following table provides suggested settings to maximize your video quality while minimizing system resource usage when streaming video content from your Pearl-2. Table 53 Suggested stream settings for video...
  • Page 354 Pearl-2 User Guide Suggested stream settings Option Setting Video encoding preset Hardware accelerated Video encoding profile High Key frame interval 2 sec Limit frame rate 4 Mbps for HD; 6 Mbps for Full HD; 12 Mbps for Bitrate 4K UHD...

  • Page 355: Streaming A Channel Direct To Viewers

    Streaming a channel direct to viewers Pearl-2 is ready to stream content directly to viewers on the local network using the default streaming settings as soon as you've powered on the system and configured a channel. Just choose the live broadcast method that's right for your viewers.

  • Page 356: Share A Live Broadcast Stream (Http, Https Or Rtsp)

    If HTTPS is configured for Pearl-2, the live broadcast URL will start with https instead of http. If Pearl-2 is behind a firewall and you want to share a stream with remote viewers, you need to set up port forwarding on your network. Consult with your network administrator.

  • Page 357: Enable Hls (Pull)

    URLs with the IP address, see Connect to Admin panel. Enable HLS (pull) Stream a live broadcast of a channel directly to viewers on the same local network as Pearl-2 using HTTP over port 80. This gives viewers with iOS devices convenient access to the channel's live broadcast. If HTTPS is configured for Pearl-2, the traffic from port 80 is redirected to HTTPS port 443.
  • Page 358 HLS stream's video data without having to provide a viewer password or LDAP authentication as configured on Pearl-2. A viewer password or LDAP authentication that is configured on Pearl-2 is still needed to access the HLS stream’s playlist.

  • Page 359: Restrict Viewer Access To Channel Streams

     7. To share the HLS (pull) URL with viewers, click Status from the Channels menu, then copy the HLS URL and provide that to your viewers. Restrict viewer access to channel streams Pearl-2 can restrict access to all viewer streams from the channel using global viewer passwords and IP allow/deny lists. See Set or change user passwords Restrict viewers by IP address.

  • Page 360: Restrict Viewers By Ip Address

    Restrict viewers by IP address Pearl-2 permits you to restrict which computers can access broadcasts by building a list of allowed and denied IP addresses. You can do this at a global level for the system and can also override these settings on a per- channel basis.
  • Page 361 Pearl-2 User Guide Restrict viewers by IP address Item Description system, provided their IP address is not in the Deny IP’s list. To allow all except IP addresses in the deny list, if any, leave the field blank. You can use the Allow list by itself, or in conjunction with the Deny IP’s list as an exception to a rule in the allow list.

  • Page 362: Ip Restriction Examples

    Pearl-2 User Guide IP restriction examples  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. From the Channels menu, select a channel and click Streaming. The channel's streaming configuration page opens.  3. From the Stream access control drop-down, select Use these Settings to enable local password and Allow/Deny IP lists are enabled.
  • Page 363 Pearl-2 User Guide IP restriction examples Example Description Allow: 192.168.1.200-192.168.1.250 Note that we could have specified two of the IP addresses in the previous example as a range. Putting the first two examples together, we want to permit access to IP addresses in the range of boardroom computers (192.168.1.200-...

  • Page 364: Change Http And Rtsp Streaming Port Values

    Pearl-2 User Guide Change HTTP and RTSP streaming port values Table 59 Example deny lists Example Description Another simple allow/deny list is to use the list of known IP addresses to list specific denied IP addresses. All other addresses are allowed access to the broadcast.
  • Page 365 Pearl-2 User Guide Change HTTP and RTSP streaming port values For RTSP streaming directly to users on your LAN, the only information that's needed to view the broadcast is the URL and the RTSP port number used to stream the broadcast.

  • Page 366: Disable And Enable Direct Channel Streaming

    Pearl-2 User Guide Disable and enable direct channel streaming  4. Set the RTSP Streaming port to specify which port to use when you are streaming live video via RTSP. This value along with the URL is used by viewers to access the broadcast. The default for channel one is 554.

  • Page 367: Viewing A Channel's Live Broadcast Stream

    When you set up a channel, the system automatically generates and displays a list of available live broadcast streams. You can share the channel's stream URLs with people on the same local network as Pearl-2 so they can watch a live broadcast of the channel. All you need to do is provide them the channel's stream URL and...
  • Page 368 Pearl-2 User Guide Viewing a channel's live broadcast stream The live broadcast stream URLs for a channel are available from the Channel menu in the Admin panel when you select Status. The audio and video codecs configured for the channel affect which live broadcast formats are listed.

  • Page 369: View The Live Broadcast Url Using A Web Browser

    You can share a channel's live broadcast URL with viewers so they can watch your live stream using their favorite web browser. Your viewers must be on the same network as Pearl-2 to watch a live broadcast using the channel's live broadcast URL.
  • Page 370 To set a viewer password, see Set or change user passwords. If HTTPS is enabled on Pearl-2, replace http with https in the URL of the stream. Share the live broadcast URL with viewers  1. Login to the Admin panel as admin or operator, see Connect to Admin panel.

  • Page 371: View The Streaming Url Using A Media Player

    You can share a channel's streaming URL with viewers so they can watch your live stream using their favorite media player, like VLC. Your viewers must be on the same network as Pearl-2 to watch a channel stream using a stream URL.
  • Page 372 Pearl-2 User Guide View the streaming URL using a media player Share the channel's stream URL with viewers  1. Login to the Admin panel as admin or operator, see Connect to Admin panel.  2. From the Channels menu, select the channel and click Status. You can copy the Live broadcast URL and share that with your viewers.
  • Page 373 Pearl-2 User Guide View the streaming URL using a media player  4. Press Play to watch the stream in the media player window.

  • Page 374: Streaming To Servers, Cdns, And Other Devices

    Streaming to servers, CDNs, and other devices Pearl-2 can stream to CDNs, local media servers, and even to other Pearl-2 devices that are acting as a streaming ingestion point. Pearl-2 supports many streaming protocols, including: SRT (push), HLS (push), MPEG-DASH (push), RTMP/RTMPS, and RTSP. Use the Admin panel to set up individual channels configured on Pearl-2 for streaming.
  • Page 375 Pearl-2 User Guide Set up an RTMP or RTMPS (push) stream Set up an RTMP or RTMPS stream using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. From the Channels menu, select the channel and click Streaming. The Streaming configuration page opens.

  • Page 376: Set Up An Srt Stream Using Rendezvous Mode

    IP address of the other device and both must be configured to use the same port for the SRT stream. In the following example, a Pearl-2 is setup as SRT Source A (192.168.1.10) with port 20000 and another Pearl-2 is setup as SRT Destination B (203.0.113.10) with port 20000.
  • Page 377 Pearl-2 User Guide Set up an SRT stream using rendezvous mode Source A streams through Firewall A and Firewall B to Destination B, which ingests the SRT stream as a video input with embedded audio. All traffic received at Firewall B that's addressed to 168.112.1.1 on port 20000 passes through the firewall directly to Destination B (203.0.113.10) because of the port number.
  • Page 378 Configure SRT Destination B to use the same port value as Source A for the SRT stream (e.g. 20000). If the destination device is another Pearl-2, you do this when adding the SRT stream as a video input source using the Admin panel, see Connect an SRT stream as an input.

  • Page 379: Set Up An Srt Stream Using Caller And Listener Modes

     13. When your ready to start streaming, click Start What's next? If you also need to set up Pearl-2 as an SRT destination and ingest an SRT stream from a remote source, you must add the SRT stream as a input, see Connect an SRT stream as an input.
  • Page 380 SRT sources, then all your SRT source devices must be set as callers. In the following example, a Pearl-2 is setup as SRT Source A (192.168.1.10) and another Pearl-2 is setup as SRT Destination B (203.0.113.10). Source A is streaming through a firewall/NAT to Destination B, which...
  • Page 381 2000 is routed to 203.0.113.10:3000. When you're configuring an SRT stream on Pearl-2, you can also adjust the recovery bandwidth overhead using the Admin panel. This setting defines how much of the stream's total bandwidth is dedicated for the exchange of SRT control and recovery packets between the source and destination.
  • Page 382  ii. (Optional) In the Source port field, enter the port number that this Pearl-2 should use for SRT traffic.  b. If Listener is selected, enter the Port number that this Pearl-2 should use for SRT traffic. See Network ports used by Pearl-2 to determine available ports.

  • Page 383: Adjust Latency And View The Srt Stream Status

     13. When your ready to start streaming, click Start What's next? If you also need to set up Pearl-2 as an SRT destination and ingest an SRT stream from a remote source, you must add the SRT stream as a input, see Connect an SRT stream as an input.
  • Page 384 Pearl-2 User Guide Adjust latency and view the SRT stream status You can add from 80 ms to 8000 ms of latency to the SRT stream. Increasing latency gives more time to buffer packets and resend any that got lost in transit to the destination. If the latency value set for the stream is too low and there is packet loss over the network, retransmission of lost packets will not be possible and the stream quality will suffer.
  • Page 385 Pearl-2 User Guide Adjust latency and view the SRT stream status Table 60 Suggested SRT latency values Minimum Recovery Packet RTT mul- SRT latency bandwidth loss % tiplier (for RTT ≤ 20 overhead % is ≤ 1 % is ≤ 3 % is ≤...

  • Page 386: Set Aes Encryption And A Passphrase For Srt

    Pearl-2 User Guide Set AES encryption and a passphrase for SRT The statistics section only appears while an SRT stream is active.  3. In the Latency field, enter a numerical value from 80 ms to 8000 ms.  4. Click Apply.
  • Page 387 Pearl-2 User Guide Set AES encryption and a passphrase for SRT  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. From the Channels menu, select the channel with the SRT stream to configure and click Streaming.

  • Page 388: Set Up An Hls (Push) Stream

    Pearl-2 User Guide Set up an HLS (push) stream  3. Check Encryption and choose the Key length.  4. In the Passphrase field, enter the passphrase using alphanumeric characters (if required). Special characters are not supported.  5. Click Apply. Set up an HLS (push) stream HTTP Live Streaming (HLS) is an adaptive, HTTP-based streaming protocol that sends video and audio content over the network in small, media segments that get reassembled at the streaming destination.
  • Page 389 IT involvement. Pearl-2 can send a single resolution and bitrate HLS stream as an HTTP POST (or HTTP PUT) to HLS ingestion servers and CDNs such as Akamai and YouTube. The default is HTTP POST. Your channels on Pearl-2 must be configured for H.264 and AAC audio codec to stream using HLS.
  • Page 390  10. (Optional) Under Advanced settings, you can set the following:  a. Master manifest: Enter the URL (including the master playlist file name) of where Pearl-2 will upload the master manifest file. The master playlist also provides the bitrate, resolution, and...

  • Page 391: Set Up An Mpeg-Dash (Push) Stream

    As such, the content can easily traverse firewalls with little to no IT involvement. As an open standard, MPEG-DASH is designed to be codec and resolution agnostic. Pearl-2 can send a single resolution and bitrate MPEG-DASH stream as an HTTP POST (or HTTP PUT) to HLS ingestion servers and CDNs such as Akamai and YouTube.
  • Page 392 User-Agent agent header, use this parameter to configure Pearl-2 with the value to insert in its user-agent header. Use this field to specify the name of the initialization file that Pearl-2 sends to the Initialization template ingestion server.
  • Page 393 Pearl-2 User Guide Set up an MPEG-DASH (push) stream  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. From the Channels menu, select the channel and click Streaming. The Streaming configuration page opens.  3. Click New stream and choose DASH push. The new stream is created using the default name Stream 1.

  • Page 394: Set Up An Rtsp Announce Stream

    Pearl-2 User Guide Set up an RTSP announce stream  6. In the Method field, select POST or PUT. This selection must match the requirements of the ingestion server.  7. In the Segment duration field, enter the length of the media segment in seconds. The default duration is five seconds.
  • Page 395 Pearl-2 User Guide Set up an RTSP announce stream  2. From the Channels menu, select the channel and click Streaming. The Streaming configuration page opens.  3. Click New stream and choose RTSP announce. The new stream is created using the default name Stream 1.

  • Page 396: Set Up A Stream To The Cdn Using An Xml Profile

    Epiphan Live. Set up a stream to the CDN using an XML profile Some CDNs provide an XML file for easy configuration setup. Pearl-2 supports using XML profiles to set a stream. Set up a stream using an XML profile from the CDN  1.

  • Page 397: Start And Stop Streaming To A Cdn

    Pearl-2 User Guide Start and stop streaming to a CDN  5. Click Apply.  6. To start streaming, click Start or click Start all to simultaneously start this stream and any other streams you have configured for this channel.  7. Click Delete this stream at any time to delete the stream.
  • Page 398 Pearl-2 User Guide Start and stop streaming to a CDN Start and stop streaming using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. From the Channels menu, select a channel and click Streaming. The Streaming configuration page opens.
  • Page 399 Start and stop streaming using the touch screen You can tell if your channel is streaming from the touch screen on Pearl-2 when you look at the channel view or the Grid view. The following shows an example Grid view.

  • Page 400: Multicast Streaming

    You can stream to several multicast networks and at the same time, stream to non-multicast CDNs. Pearl-2 supports multicast streaming to an IP TV or a set-top box playlist using SAP when the stream format is MPEG-TS.
  • Page 401 Pearl-2 User Guide MPEG-TS streams using RTP/UDP push  4. Enter the destination multicast IP address where the broadcast can be viewed. A IPv4 multicast address range is an address between 224.0.0.0 to 239.255.255.255. Contact your System Administrator for the specific address to use.

  • Page 402: Mpeg-Ts Streams Using Udp Push

    Pearl-2 User Guide MPEG-TS streams using UDP push When a channel number value is not specified, viewers cannot select a channel from the set-top box or Smart TV .  d. Enter a name for a group of streams in the text box next to Group name. Since media players...
  • Page 403 Pearl-2 User Guide MPEG-TS streams using UDP push  5. Enter the destination multicast IP address where the broadcast can be viewed. A IPv4 multicast address range is an address between 224.0.0.0 to 239.255.255.255. Contact your System Administrator for the specific address to use.

  • Page 404: Multicast Streaming Using Rtp/Udp

    Multicast streaming using RTP/UDP You configure an RTP/UDP (push) stream on Pearl-2 using the Admin panel. If you're streaming to 10/100 Mbps set-top boxes over Gigabit Ethernet and you notice frames are dropping, you can limit the bandwidth of the stream, see Set up traffic shaping.

  • Page 405: Set Up Traffic Shaping

    Pearl-2 User Guide Set up traffic shaping  5. Enter the following:   Destination multicast IP address.   Audio port number through which the audio will stream.   Video port number through which the video will stream. Audio and video use nearby port numbers (<port number>and <port number+2>). The minimum distance between audio and video ports must be 2.
  • Page 406 95 Mbps.   After enabling traffic shaping for a channel using the Admin panel, you can no longer use the Pearl-2 API to clear or configure traffic shaping for that channel. If you currently use the API to configure traffic shaping, see the Technical Notes for your Pearl-2 model for instructions.

  • Page 407: Viewing With Session Announcement Protocol (Sap)

    Pearl-2 User Guide Viewing with Session Announcement Protocol (SAP)  2. From the Channels menu, select the channel and click Streaming. The Streaming configuration page opens.  3. Click New stream and select a multicasting stream as the type: MPEG-TS USP, MPEG-TS RTP/UDP, or RTP/UDP.
  • Page 408 Pearl-2 User Guide Viewing with Session Announcement Protocol (SAP) When browsing from a VLC media player, streams are advertised by their channel identifier and are organized by the group name. When browsing from an XBMC media player, streams are advertised by the stream's metadata title (if configured);...

  • Page 409: Streaming To A Media Player Or Smart Tv

    Streaming to a media player or smart TV Streaming to a media player or smart TV Your Pearl-2 can use UPnP and SAP to stream to set-top boxes, digital signs, smart TVs and other digital media players. The following table gives an overview of each option.

  • Page 410: Enable Upnp

    Enable UPnP For security reasons, UPnP is disabled for Pearl-2 at the device level and for each channel by default. You can enable UPnP to allow digital media players on the network to browse for recorded media files or live streams on your Pearl-2.
  • Page 411 Pearl-2 User Guide Enable UPnP If no live stream is available that meets the criteria for UPnP, a message is displayed in the Play on service start section of the page. Otherwise, the Play on service start section shows a drop-down list of what can be streamed.
  • Page 412 Pearl-2 User Guide Enable UPnP If you have not already enabled UPnP for the device, the message "UPnP live video sharing is not enabled with this device, to fix it, click here" appears. Click to fix it click here. The UPnP service will start when you click Apply.

  • Page 413: Disable Upnp

    Pearl-2 User Guide Disable UPnP If you have not already enabled UPnP for the device, the message "UPnP live video sharing is not enabled with this device, to fix it, click here" appears. Click to fix it click here. The UPnP service will start when you click Apply.
  • Page 414 Pearl-2 User Guide Disable UPnP channel's live stream, recordings, or for the whole system. Disable UPnP for a channel using the Admin panel  1. For the channel's live streams, do the following:  a. From the Channels menu, select the channel and click Streaming. The Streaming configuration page opens.

  • Page 415: Viewing With Upnp

    Remove user passwords to clear the viewer password. When browsing via UPnP your Pearl-2 is displayed by the server name you set, or it's product serial number. For example, when browsing from a Windows computer, you will see a list of media devices that includes...

  • Page 416: Change Upnp Device Name

    UPnP. Change UPnP device name You can configure the UPnP server name that appears for your Pearl-2. By default, if you leave the server name field blank when enabling UPnP, the device's serial number is used as the server name. Change the UPnP server name using the Admin panel  1.

  • Page 417: About Streaming Ndi

    Important considerations   Pearl-2 can unicast up to two 1920×1080 @ 30 fps NDI output streams at the same time. However, NDI allows receivers to request a lower quality stream. If that happens, Pearl-2 will send two streams: one at the original resolution and a second one at the requested resolution. This can impact the CPU...

  • Page 418: Start And Stop An Ndi Stream

    Pearl-2 can ingest up to three multicast or unicast 1920×1080@30 fps NDI video inputs or up to one 4K NDI input to Pearl-2, and supports both NDI and NDI|HX video inputs. For more information about NDI inputs, Connect an NDI source.
  • Page 419 Single Touch streaming and recording control. This is enabled by default.  6. Enter a unique name for Pearl-2 in the Name field. The name you enter appears in parenthesis after the serial number of Pearl-2 and the three-letter prefix. For example: PLTTSG999901 (name)  7.

  • Page 420: Part 4: Record

    PART 4: Record Pearl-2 encodes the video and audio it captures. You can stream your content and record it at the same time. You can even stream your switched program using a lower quality stream (i.e. 1280×720 at 2Mbps) and at the same time, make high quality recordings of each of the video inputs at full frame with a high bitrate for future re-use and post-processing.

  • Page 421: About Recording

    Pearl-2 User Guide About recording About recording You can record a channel on Pearl-2 as AVI, MOV, MPEG-TS, MP4, or MP4-Fragmented. Easily stop and start recording using any of the local user interfaces as well as remotely:   Admin panel  ...

  • Page 422: Record A Channel

    Google Chrome 37+ (works with MOV and MP4 files using H.264 codec) (Windows) Not all media players and editors support all recording formats, such as the more modern MP4- fragmented format. To playback MOV files created by Pearl-2, we recommend using a newer media player. Record a channel Using the Admin panel , you can start and stop recording a channel, as well as configure recording settings for the channel.
  • Page 423 Pearl-2 User Guide Record a channel In the Admin panel, the channel number turns red to indicate it's recording. If the system runs out of storage space, the oldest recorded file is deleted to make room for the new recording.

  • Page 424: Record Using Single Touch Control

    Record using Single Touch control Record using Single Touch control   Pearl-2's Single Touch recording and streaming control allows you to control your recording and streaming across any number of channels and recorders with one touch of the touch screen. Channels and recorders are enabled for one touch recording by default.

  • Page 425: Configure Recording Settings, File Size And Type

    Pearl-2 User Guide Configure recording settings, file size and type Configure recording settings, file size and type Recordings are saved as MP4 files by default. Each channel and recorder also has a file size limit set to 500 MB and the maximum file length set to 30 minutes by default.
  • Page 426 Pearl-2 User Guide Configure recording settings, file size and type Label Description / Options from 50 MB to 64 GB. Specifies the recording file type. Select from AVI, MP4, MP4-Fragmented, MPEG-TS, or MOV. Choose MPEG-TS for UPnP playback.   AVI: Generally used for playback on Windows.
  • Page 427 Pearl-2 User Guide Configure recording settings, file size and type Change the recording configuration using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. Open the Recording page. Do one of the following:  a.

  • Page 428: Restart Recording To A New File

    Pearl-2 User Guide Restart recording to a new file  6. (Optional) Check the check box to exclude this channel or recorder from automatic file uploads, see and automatic file transfers.  7. Click Apply. Restart recording to a new file Recordings are automatically saved to a file and a new recording is started when:  ...

  • Page 429: Recorders

    Each channel has its own built-in recorder which you access from the channel's Recording page. However, if you want to record several channels simultaneously to a multi-track file, you need to add a recorder to Pearl-2 using the Admin panel.

  • Page 430: Select Channels To Record

    Select channels to record When you create a new recorder, it records all the channels configured on Pearl-2 in the single multi-track file by default. If you create new channels, they are automatically added to the recorder. You can choose which channels the recorder includes in the multi-track file using the Admin panel.

  • Page 431: Start And Stop A Recorder

    Pearl-2 User Guide Start and stop a recorder  4. Check the boxes next to the channels you want to include, and click Apply. Channels with no active video source are displayed in italics. You can include these channels in your channel selections for the recorder.

  • Page 432: Rename A Recorder

    Pearl-2 User Guide Rename a recorder Start and stop a recorder using the Admin panel  1. Login to the Admin panel as admin or operator, see Connect to Admin panel.  2. From the Recorders menu, select a recorder. The recorder configuration page opens.

  • Page 433: Duplicate A Recorder

    Pearl-2 User Guide Duplicate a recorder Duplicate a recorder You can duplicate any recorder you've created. All settings in the recorder you duplicate are recreated. Duplicate a recorder using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.
  • Page 434 Pearl-2 User Guide Delete a recorder  3. Click Delete this recorder and click OK when prompted.

  • Page 435: Manage Recorded Files

    Rename recorded files   Delete recorded files For information about automatic file transfers or setting up Pearl-2 as a local FTP server so you can manually or automatically connect to the system and download recordings, see FTP and automatic file transfers.

  • Page 436: Download Recorded Files Manually

    You can manually download recordings using the Admin panel. Files you download are saved to your connected admin computer. This feature is not available using the local console on Pearl-2. Download recordings to your admin computer using the Admin panel  1.

  • Page 437: Join Recorded Files Together

    Join recorded files together After recording files on Pearl-2, you can join two or more files together. This is useful when a recording exceeds the maximum recording time limit and the recording is split into multiple files. You can use the third- party tool called ffmpeg to join the files.

  • Page 438: Extract Tracks From A Recording

    Pearl-2 User Guide Extract tracks from a recording  1. Download the files that you need from Pearl-2 and make sure you have the right paths and file names. For example: C:\Users\JoesComputer\downloads\Program_A_May11_16-24-56.avi  2. Use the command ffmpeg -i to specify the input file. For example: ffmpeg -i C:\Users\JoesComputer\downloads\Program_A_May11_16-24-56.avi...
  • Page 439 Extract tracks from a recording It's good practice to check that there's enough storage space for the extracted files before you start this procedure. To check how much internal storage space is available on Pearl-2, see Storage capacity and maintenance.

  • Page 440: Rename Recorded Files

    Rename recorded files Recordings are named based on the file name prefix specified during configuration. You can change the recording file name using the Admin panel. You can also change the default name that Pearl-2 assigns to recordings, see Configure recording settings, file size and type for information about setting file name prefixes.

  • Page 441: Delete Recorded Files

    Pearl-2 User Guide Delete recorded files  4. Type the new file name and press Enter using your keyboard. The Admin panel keeps track of the filename extension (i.e. .avi) so you do not need to include it when renaming the file.
  • Page 442 Pearl-2 User Guide Delete recorded files  3. All recordings are listed and sorted by date. Do one of the following:  a. To delete a single recording, click the X icon to the right of a recording and click OK when prompted.

  • Page 443: Ftp And Automatic File Transfers

    USB drive. We call this Automatic File Upload or AFU for short. You can schedule automatic file uploads for a time and day that's most convenient for your workflow. You can also configure Pearl-2 to act as an FTP server, allowing you to manually or automatically connect to Pearl-2 and download recordings.
  • Page 444 If recordings are selected for Automatic File Upload (AFU) while AFU is at maximum upload capacity or when AFU is unavailable, the recordings are added to an upload queue. If there is no available space left in the internal storage on Pearl-2, new recordings fail and do not overwrite recordings in the AFU queue.

  • Page 445: Set Channels And Recorders To Include In Afu

    Pearl-2 User Guide Set channels and recorders to include in AFU Set channels and recorders to include in AFU When configuring automatic file upload (AFU), you need to tell the system which channels and recorders you want included in the upload schedule. If no channels or recorders are configured as a part of AFU, the following message appears in the Automatic File Upload configuration page.

  • Page 446: Enable Afu, Schedule, And Set Options

    Pearl-2 User Guide Enable AFU, schedule, and set options  4. Check Automatic file upload and click Apply. What's Next After you've enabled AFU for your channels and recorders, enable AFU and configure the AFU settings for the location type (i.e. FTP, USB, AWS, etc).
  • Page 447 If no remote path is specified, the files are copied to the root folder Remote path of the destination file system. Delete files from local storage on Pearl-2 when the upload Remove after upload completes. Change the color of the file in the recording list to show the files are Mark file as downloaded downloaded.
  • Page 448 Pearl-2 User Guide Enable AFU, schedule, and set options If your screen does not indicate that AFU is enabled for at least one channel or recorder, return to Set channels and recorders to include in AFU  3. Check Enable Automatic File Upload.

  • Page 449: Configure Afu To Ftp Server Parameters

    Pearl-2 User Guide Configure AFU to FTP server parameters  7. Click Apply. If AFU to your server fails, check the server configuration and permissions. What's next? Select the protocol transfer type and configure the protocol settings. Do one of the following:  ...
  • Page 450 Pearl-2 User Guide Configure AFU to FTP server parameters Name Description Password Password for the FTP user. Causes files to be named with .part extension on the server during active upload. When Use temp file the upload completes, the file is renamed to the appropriate extension (.mov, .mp4 or .avi).

  • Page 451: Configure Afu To Sftp Server Parameters

    Pearl-2 User Guide Configure AFU to SFTP server parameters Configure AFU to SFTP server parameters You can automatically upload recordings to a secure FTP (SFTP) server when you select SFTP as the AFU protocol transfer type using the Admin panel.
  • Page 452  6. Select Use temp file to name files with a temporary filename extension (.part) on the server until upload is complete. For secure file transfer, you can upload an SSH identity for your Pearl-2. This key must be trusted by the destination server. Details for generating the key and setting up this trust are beyond the scope of this document.

  • Page 453: Configure Afu To Rsync Server Parameters

    Pearl-2 User Guide Configure AFU to RSync server parameters  a. Click Choose File and navigate to select the private key file from your hard drive, then click Open.  b. Click Upload to upload the file. The system accepts RSA keys for SSH-1; DSA, ECDSA, EC25519 and RSA for SSH-2.
  • Page 454 Pearl-2 User Guide Configure AFU to RSync server parameters Name Description Password Password for the RSync user. Select to enable checksum checking during file transfer. This increases the time taken to Checksum transfer, but also increases reliability of the transfer.

  • Page 455: Configure Afu To Cifs Server Parameters

    Pearl-2 User Guide Configure AFU to CIFS server parameters Configure AFU to CIFS server parameters You can automatically upload recordings to a CIFS server (also known as SMB or samba) when you select CIFS as the AFU protocol transfer type using the Admin panel. Samba version 1 is supported.

  • Page 456: Configure Afu To Scp Client Parameters

    Pearl-2 User Guide Configure AFU to SCP client parameters  2. Specify the target Server address. If your system is configured with DHCP or has a valid DNS configuration (see Configure DHCP), you can use the server’s fully qualified domain name instead of the IP address.
  • Page 457 Pearl-2 User Guide Configure AFU to SCP client parameters Table 69 SCP Automatic Upload Configuration Parameters Name Description Server address The IP address (or fully qualified domain name) of the destination server. Server port The SCP port used by the target server. Standard port is 22.

  • Page 458: Configure Afu To Aws S3 Parameters

    Pearl-2 User Guide Configure AFU to AWS S3 parameters For secure copy you can upload an SSH identity for your Pearl-2. This key must be trusted by the destination server. Details for generating the key and setting up this trust are beyond the scope of this document.
  • Page 459 Pearl-2 User Guide Configure AFU to AWS S3 parameters Table 70 AWS Automatic Upload Configuration Parameters Name Description The geographical region of the AWS server that contains the bucket you want to AWS Region Code upload to, e.g. us-east-2. The id of the data storage container you created in Amazon S3 for the recorded live Bucket streaming files.

  • Page 460: Configure Afu To Webdav Server Parameters

    Pearl-2 User Guide Configure AFU to WebDav server parameters  2. Specify the AWS Region Code and the data storage Bucket where you want to upload the file.  3. Enter your AWS Access Key Id and Secret Access Key to authenticate access to the AWS S3 data storage bucket.

  • Page 461: Afu Or Copy To Usb

    AFU or copy to USB Pearl-2 has USB 3.0 ports that you can use to copy recordings from internal storage to external USB flash drives or hard drives. Use this to conveniently provide speakers with a copy of their presentation before they leave the presentation venue.

  • Page 462: Afu To A Usb Storage Device

        We recommend you only connect one USB device to Pearl-2 at a time. Only one copy or move to USB operation is permitted at a time, even though the UI may appear to let you start a second one. Please wait until the first is complete before starting a new operation.

  • Page 463: Do A One-Time Copy/Move All Recordings To Usb Storage Device

     3. Click Apply. Do a one-time copy/move all recordings to USB storage device When one-time move/copy of files is configured, Pearl-2 automatically starts copying files as soon as you connect a USB storage device to the USB port. Newest recordings are copied first. Files continue copying over until one of the following events occur:  ...
  • Page 464 Prerequisites   A properly formatted USB device not connected to a USB port on Pearl-2. Configure a one-time copy of all recorded files to a USB storage device using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.

  • Page 465: Manually Copy Recordings To A Usb Storage Device

    Manually copy recordings to a USB storage device You can manually copy recordings to a USB storage device that is connected to Pearl-2. This procedure is separate from automatic file upload and does not need any pre-configuration in the automatic file upload page.
  • Page 466 Pearl-2 User Guide Manually copy recordings to a USB storage device Table 74 One-Time Move/Copy File Transfer Options Name Description If checked, the transfer process creates a sub-folder with the system’s create subfolder with serial number on the USB drive. This is useful if you are using the same serial number (<serial>)

  • Page 467: View File Transfer Status And Cancel File Copy To A Usb Device

    Pearl-2 User Guide device  4. Insert your USB storage device into an available USB port on Pearl-2 and do one of the following:  a. To download files for a specific channel, click Recording from the Channels menu.  b. To download files for a recorder, select a recorder from the Recorders menu.

  • Page 468: View Available Usb Storage Space

    Pearl-2 User Guide View available USB storage space  2. View the current file transfer status under the Status section. To cancel the current file transfer, select Cancel and confirm when prompted. The option to cancel only appears while the file transfer is in progress.

  • Page 469: Safely Eject Usb Storage Device

     2. At the bottom of the menus panel, click eject and click OK when prompted. It's now safe to disconnect the USB storage device from Pearl-2. Manage USB file transfer queue You can view USB file transfer information, delete files in the USB file transfer queue, and cancel USB file...

  • Page 470: Add Recordings To An Afu Queue

    Information such as the file name and size, start time, duration, and progress are displayed. A history of file transfers displays until either Pearl-2 is restarted or the list is manually cleared. External USB storage must be configured for the USB file transfer status to display.

  • Page 471: View The Afu Log

    Pearl-2 User Guide View the AFU log  2. Find the recordings by channel or by recorder and select the files you want to add to the AFU queue.  3. Select Add Selected to Automatic file upload. What's next? Add more recorded files to the queue or delete any of the recordings before they are uploaded, see...

  • Page 472: Manage The Afu Queue

    Pearl-2 User Guide Manage the AFU queue  3. Click Show log of automatic file upload. The log page opens. If no logs are present, the page is blank.  4. Click the browser's back button when you are done. Manage the AFU queue The Automatic File Upload (AFU) queue displays a list of recorded files waiting to be uploaded.
  • Page 473 Pearl-2 User Guide Manage the AFU queue  2. From the Configuration menu, click Automatic File Upload. If there are files to be uploaded, they appear in the queue.  3. To remove a file from the AFU queue, click X beside the file you want to remove.

  • Page 474: Local Ftp Server

    Local FTP server Local FTP server Pearl-2 can act as an FTP server, allowing you to manually or automatically connect to the system and download recordings. Depending on configuration of the FTP server, you may also be able to remotely delete files after download, maximizing available system storage.
  • Page 475 Pearl-2 User Guide Local FTP server  3. To enable or disable the FTP server, do one of the following:  a. Check Enable FTP access and select a user from the FTP user name drop down. Then click Apply to enable the FTP server.
  • Page 476 The username and password for your FTP user, see Configure the local FTP server In the following example, the IP address of Pearl-2 is 192.168.1.210, the username is admin, there is no password, and the Windows command line ftp utility is used.
  • Page 477 Pearl-2 User Guide Local FTP server  8. If enabled in the FTP configuration page, delete the file after downloading it by issuing the delete command, or using your tool’s delete mechanism. If the delete command is not enabled, attempting to delete a file will result in an Unknown...

  • Page 478: Part 5: Integration

    PART 5: Integration Pearl-2 is fully integrated with Kaltura and Panopto Content Management Systems (CMSs). Learn to use the Admin panel to set up and manage Pearl-2 with Kaltura and Panopto, as well as how to record and stream. Topics include:  ...

  • Page 479: Kaltura Registration

    MediaSpace and can be selected for scheduled recordings and webcasts, as well as be used for unscheduled ad hoc events that you can create using the Admin panel or from Pearl-2's touch screen. Registering Pearl-2 as a resource with the Kaltura Content Management System (CMS) only needs to be done once.
  • Page 480 Enable CMS and register with Kaltura There are two types of Kaltura application tokens you can use with Pearl-2: an administrative session type and a user session type. With an administrative session token, Pearl-2 uploads event recordings to the respective event owner's account in Kaltura as expected.
  • Page 481 Enable CMS and register with Kaltura   Do not include a creation date for the user session token. A creation date in the token causes Pearl-2 to upload events only to the token creator and restricts login using Pearl-2's touch screen to only the token creator.

  • Page 482: Disable Or Deregister From Kaltura

    Disable or deregister from Kaltura You can disable CMS for a registered Pearl-2 using the Admin panel and still select Pearl-2 as a resource using Kaltura MediaSpace. However, the events schedule won't synchronize on Pearl-2 and any events that are scheduled to start while CMS is disable do not start on Pearl-2.
  • Page 483 Pearl-2 User Guide Disable or deregister from Kaltura   You cannot start ad hoc (manual) Kaltura events when CMS is disabled or when Pearl-2 has been deregistered.   When CMS is disabled or Pearl-2 is deregistered, existing scheduled events that are associated with the device do not record or stream.

  • Page 484: Change The Resource Name Used For Kaltura

    Using the Admin panel, you can change the resource name that's assigned to Pearl-2 while it's registered with Kaltura. Each Pearl-2 is assigned a unique resource name that includes the serial number of the device by default. You can transfer scheduled VOD and scheduled webcasting events from one resource to another by assigning Pearl-2 the same resource name as another resource.

  • Page 485: Reassign A Registered Resource

     3. Change the Resource name and click Apply. Reassign a registered resource Every encoder you register with Kaltura has a unique resource name. To swap out one Pearl-2 encoder with another one, you can simply reassign the existing Pearl-2 resource name to the replacement Pearl-2.
  • Page 486 If you've performed a factory reset that resulted in an orphaned Kaltura resource registration, you can perform this procedure to reregister your Pearl-2 using the same resource name to take over the resource instance that is still registered in Kaltura.
  • Page 487  3. From the Choose CMS drop down, select Kaltura and then click Apply.  4. Enter your Partner ID and Administrator secret that you got from Kaltura.  5. Change the Resource name to the resource name of the Pearl-2 you are replacing and click Register device.

  • Page 488: Kaltura Recording And Webcasting Setup

    Using multiple Pearl-2 channels is how you get multiple views for a Kaltura event. Each channel is treated as a separate video source. Using the Admin panel, Pearl-2 administrators can choose up to five channels on Pearl-...
  • Page 489 For example, if you have a main camera and a presentation laptop that you want to capture as a multiple source recording, you'd create two channels on Pearl-2: one for the main camera and another one for the presentation laptop. To learn how to create a channel or to use the Auto channels, see Channel configuration.
  • Page 490 Pearl-2 User Guide About Kaltura recording and webcasting   Do not schedule recordings that are longer than the capacity of Pearl-2 to store the recording on the local drive.   Scheduled events have priority over ad hoc events. If an ad hoc event is still in progress when it's time to start a scheduled event, the ad hoc event is stopped and the scheduled event starts.

  • Page 491: Select Channels For Kaltura Vod Events

    You can select which Pearl-2 channels are included in scheduled and ad hoc recordings using the Admin panel. Each channel that is configure on Pearl-2 is treated as a separate video source for all VOD events. Using multiple channels is how you record multiple views for a scheduled or ad hoc VOD event.

  • Page 492: Select A Channel And Urls For Kaltura Webcasting Events

    URL. When a webcasting event is scheduled in Kaltura or started from Pearl-2 as an unscheduled ad hoc event, the stream URL and other event settings are sent to Pearl-2. The Kaltura ingestion settings are applied automatically to Pearl-2.

  • Page 493: Set Kaltura Ad Hoc Event Parameters

    Pearl-2 User Guide Set Kaltura ad hoc event parameters  1. Login to the Admin panel as admin, see Connect to Admin panel.  2. From the Configuration menu, click CMS. The Content management system configuration menu opens.  3. Under Live-stream event channel, select the channel you want to stream.
  • Page 494 Admin panel. However, users can modify or add this metadata later using the Kaltura Management Console.   CMS must be enabled and Pearl-2 registered with Kaltura to create ad hoc events. Set default ad hoc event parameters using the Admin panel  1. Login to the Admin panel as admin, see Connect to Admin panel.

  • Page 495: Change The Events Schedule Refresh Interval

    Change the events schedule refresh interval Using the Admin panel, you can change how frequently Pearl-2 polls Kaltura for the latest event information to refresh the events listed on the Events page. The default interval is once every 3600 seconds (1 hour).

  • Page 496: Use Rtmps For A Kaltura Webcasting Event

    Use RTMPS for a Kaltura webcasting event Use RTMPS for a Kaltura webcasting event Pearl-2 sends an RTMP stream to the primary URL associated with the webcasting event, or to both the primary URL and the secondary backup URL if you've enabled the backup stream, see...

  • Page 497: Panopto Registration

    Enable CMS and register with Panopto Use the Admin panel to register Pearl-2 as a remote recorder for scheduled, recurring, and ad hoc recordings and webcasts. When you register Pearl-2, a default name is assigned that includes the serial number of Pearl- 2.
  • Page 498 If you are unable to register Pearl-2, contact your Panopto administrator or Epiphan support.   If you want a different name for this Pearl-2 to appear in Panopto, enter the name into the Device name field before you register Pearl-2. Changes after Pearl-2 is registered do not appear in Panopto.
  • Page 499 Pearl-2 User Guide Enable CMS and register with Panopto Changing Panopto's device name for Pearl-2 does not change the name that is assigned to Pearl-2 in the Device info fields, see Configure device info, name, description, and location...

  • Page 500: Disable Cms And Disconnect From Panopto

    Disable CMS and disconnect from Panopto When you use the Admin panel to disable CMS for a registered Pearl-2, the remote recorder disconnects from Panopto. As long as Pearl-2 is still registered, you can create new scheduled sessions in Panopto for this remote recorder, but the events schedule won't synchronize until CMS is re-enabled.
  • Page 501 Pearl-2 User Guide Disable CMS and disconnect from Panopto  2. From the Configuration menu, click CMS. The Content management system configuration menu opens.  3. To disconnect Pearl-2, select none from the Choose CMS drop down and then click Apply.

  • Page 502: Panopto Recording And Webcasting Setup

    Pearl-2 appears as an available resource as soon as the device is registered with Panopto. Now you must setup authentication for ad hoc events to create ad hoc events from Pearl-2. After that, you're ready to select video sources for multiple source recordings and webcasts. Video sources must be connected to Pearl-2 and assigned to a channel.
  • Page 503 Do not schedule recordings that are longer than the capacity of Pearl-2 to store the recording on the local drive.   You can configure up to up to six channels on Pearl-2 for multiple source recordings and up to four separate channels for webcasts.  ...
  • Page 504 CMS is enabled on Pearl-2.   For ad hoc events, Pearl-2 ignores a user's presets that are set in Panopto. As a result, ad hoc recordings automatically upload to the user's default folder as originally assigned by Panopto.

  • Page 505: Setup Panopto Authentication For Ad Hoc Events

    Setup Panopto authentication for ad hoc events Panopto users can create unscheduled ad hoc events directly from the touch screen on Pearl-2 or using the Admin panel. You can set up Pearl-2 to allow users to authenticate using their local Panopto login credentials, their credentials for a third-party LMS integrated with Panopto (like Canvas), and SAML 2.0 credentials if...
  • Page 506 Create API Client page opens.  b. From the Create API Client page, enter a unique name for the Pearl-2 API client in the Client Name field. If a client already exists in Panopto with that name, choose a different name.
  • Page 507  b. In the Allowed Redirect URLs field, enter http://<device_ip>/admin/events where <device_ip> is the IP address of Pearl-2. If Pearl-2 is configured for https, enter https:// instead of http://.  c. In the URL Type field, select Redirect URL.  d. Click Add URL. The Admin panel URL redirect appears in the Allowed URL list.

  • Page 508: Set Panopto Ad Hoc Event Parameters

    Pearl-2 User Guide Set Panopto ad hoc event parameters  7. In the Unscheduled ad hoc events section, enter the Pearl-2 API client id that was generated earlier, and then click Apply. Set Panopto ad hoc event parameters Using the Admin panel, you can set parameters that are associated with ad hoc events, including:  ...

  • Page 509: Disable Low Disk Space Panopto Alerts

    Disable low disk space Panopto alerts Pearl-2 sends a low disk space alert to Panopto when the amount of internal storage space on the device is low. You can disable the low disk space alerts that Pearl-2 sends to Panopto using the Admin panel and enable it again at any time.
  • Page 510 Pearl-2 User Guide Disable low disk space Panopto alerts  4. To enable this feature again, simply check Low disk space alert and click Apply.  ...

  • Page 511: Cms Recording And Webcasting Control

    Setup a CMS start screen You can use the Admin panel to set Pearl-2 to show the Content Management System (CMS) Events screen on the touch screen at start up. You can also lock the start screen to restrict access to any other screen. Locking the start screen is useful when operating Pearl-2 in public spaces, classrooms, and unmanned kiosks.
  • Page 512 You must enter the PIN to unlock the CMS Events start screen and access the other screens using the touch screen. When you return to the CMS Events start screen, Pearl-2 automatically locks itself and you must re-enter the 4-digit PIN to unlock the touch screen.

  • Page 513: Start/Stop Scheduled Cms Events Using The Admin Panel

    Panopto.   Do not power down Pearl-2 while a scheduled webcast event is in progress. The webcast ends but the RTMP stream that was created automatically on Pearl-2 is not deleted from the channel's Streaming page. Use the Admin panel to manually delete the webcast stream instance from the channel's Streaming page.

  • Page 514: Stop/Start Scheduled Cms Events Using The Touch Screen

    Kaltura CMS system is at the time. Stop/start scheduled CMS events using the touch screen You can use Pearl-2's touch screen to manually start scheduled events up to thirty minutes before the scheduled start time. A calendar icon appears when CMS is setup on Pearl-2.
  • Page 515 Pearl-2 must already be registered with your CMS to appear listed as a remote recorder resource in Kaltura or Panopto. Contact your CMS administrator responsible for setting up hardware encoders for your organization if Pearl-2 isn't listed as a resource or the calendar icon does not appear on the touch screen.

  • Page 516: Create Ad Hoc Events Using The Admin Panel

    Pearl-2. Create ad hoc events using the Admin panel You can create and start an ad hoc recording or webcast using the Admin panel. Pearl-2 must be registered with your CMS to create ad hoc events, see Integration.
  • Page 517 Pearl-2 User Guide Create ad hoc events using the Admin panel Table 77 Kaltura ad hoc event details Item Description Enter a unique name for the ad hoc event. If no name is entered, a default event Session title consisting of the current date and time is applied. For example: 2019-07-04 13:22 Description Enter a description of the event.
  • Page 518 Select the folder in Panopto where you want the recorded file to upload. Your Panopto MyFolder is the default folder. Folder For ad hoc events, Pearl-2 ignores a user's presets that are set in Panopto. As a result, ad hoc recordings automatically upload to the user's default folder as originally assigned by Panopto.

  • Page 519: Create Ad Hoc Events Using The Touch Screen

    Create ad hoc events using the touch screen You can create unscheduled ad hoc recordings and webcasts directly from Pearl-2's touch screen using the Events screen. To manually display the Events screen, just tap the Calendar icon that appears along the...
  • Page 520 If login to the CMS is denied, the account you entered may not exist or may not have access rights to create an ad hoc event using Pearl-2. Contact your CMS administrator for CMS related login and account issues.
  • Page 521 For ad hoc events to work, the user must have an account with their Content Management System (CMS) so they can login using Pearl-2's touch screen. CMS must also be set up on Pearl-2 and Pearl-2 must be registered with the CMS. If you don't see a calendar icon in the Channel view of the touch...

  • Page 522: Logout Of An Ad Hoc Session

    For Panopto, each channel that is configure on Pearl-2 is treated as a separate video source for multi- source ad hoc events.   For Panopto ad hoc events, Pearl-2 ignores a user's presets that are set in Panopto. As a result, ad hoc recordings automatically upload to the user's default folder as originally assigned by Panopto.  ...

  • Page 523: Schedule When Cms Event Recordings Upload

    Schedule when CMS event recordings upload As soon as your Content Management System (CMS) event ends, Pearl-2 uploads the associated recordings to the CMS server if a network connection to the CMS server is available. Using the Admin panel, you can schedule Pearl-2 to upload recordings only during a specific time period.

  • Page 524: Upload The Local Panopto Webcast Recording

    By default, Pearl-2 always records a Panopto webcasting event locally and uploads that recording when the webcast ends. Once uploaded, the Panopto server uses the local recording from Pearl-2 instead of the original webcast. You can disable this feature using the Admin panel. If an upload schedule is set, the webcast...

  • Page 525: Recover Channel Backup Recordings

    CMS, administrators can manually download backup recordings for a channel on Pearl-2. Pearl-2 saves a local backup of recordings automatically in a round-robin fashion. When the record drive is full, new recordings overwrite the oldest ones. Pearl-2 administrators and operators can use the Admin panel to...
  • Page 526 Pearl-2 User Guide Recover channel backup recordings manually download and delete channel recordings. For more details about managing recordings, see Manage recorded files. Download recordings for a channel using the Admin panel  1. Login to the Admin panel as admin or operator, see Connect to Admin panel.
  • Page 527 Pearl-2 User Guide Recover channel backup recordings Delete recordings for a channel using the Admin panel To delete recordings for a channel, do one of the following:   To delete a single recording, click the X icon to the right of a recording and click OK when prompted.
  • Page 528 Pearl-2 User Guide Recover channel backup recordings The list may not update immediately. You can refresh the list by reloading the Recording page (for channels) or the recorder settings page (for recorders).

  • Page 529: Part 6: Maintenance

    PART 6: Maintenance Keep your Pearl-2 running smoothly using the latest firmware updates and maintenance features. Topics include:   Power down and system restart   Backup your Pearl-2 setup   Perform a factory reset   Firmware upgrade   Support  ...

  • Page 530: Power Down And System Restart

    Power off the device using the Admin panel You can use the Admin panel to power off Pearl-2. The power button on Pearl-2 is a toggle switch. If you power off the device using the Admin panel, the power switch remains in the on state. To power back on, you must double press the power button.
  • Page 531 You can manually shut down Pearl-2 using the power button. The power button for Pearl-2 is found on the front. To power off Pearl-2 manually, double-press (two successive fast presses and releases) the power button to initiate a safe power down.

  • Page 532: Backup Your Pearl-2 Setup

    Backup your Pearl-2 setup Backup your Pearl-2 setup Configuration presets are the perfect way to backup your Pearl-2 setup so that you can reapply it later without worrying if someone changes your settings or does a factory reset. You can create a configuration preset from the Configuration menu when you select Maintenance, see Configuration presets.

  • Page 533: Perform A Factory Reset

    Perform a factory reset Perform a factory reset Administrators can use the Admin panel to perform a factory reset and restore the configuration of Pearl-2 to the manufacturer's original default settings. For a list of affected settings, see The Factory default configuration preset and Factory reset.

  • Page 534: Firmware Upgrade

    Maintenance page of the Admin panel. You can also manually check for updates If your Pearl-2 has internet access. Don't miss out on any feature enhancement. Register your Pearl-2 device and be eligible to download firmware updates, see Register your device.
  • Page 535 Update the firmware If your Pearl-2 has internet access, the easiest way to install a firmware update is to use the download link that's provided when you check for new firmware. If you have a Pearl-2 firmware file that was provided to you by Epiphan Video, you can install the new firmware using the web-based Admin panel.
  • Page 536 If the touch screen is enabled, a notice that the firmware update is in progress appears. Do not interrupt power to the system during the firmware upgrade.  5. When the firmware update is complete, a message lets you know that Pearl-2 is going to reboot. Wait for the system to restart.
  • Page 537 Firmware upgrade BIOS update If Pearl-2 requires a BIOS update, a BIOS Upgrade section appears on the Firmware update page in the Admin panel. We recommend performing the BIOS update whenever they become available to ensure optimum performance of your device.
  • Page 538 If the touch screen is enabled, a notice that the BIOS update is in progress appears. Do not interrupt power to the system during the BIOS update.  5. When the BIOS update is complete, a message lets you know that Pearl-2 is going to reboot. Wait for the system to restart.
  • Page 539 Pearl-2 User Guide Firmware upgrade You can also confirm that the latest BIOS is installed on Pearl-2 when the section called BIOS Upgrade no longer appears on the Firmware Upgrade page in the Admin panel.

  • Page 540: Support

    Support Support Your Pearl-2 comes with a one-year complimentary support plan starting one year from the original product shipment date. You can purchase a 2-year extended support plan from Epiphan Video for a total of three years of product support from the original product shipment date:  ...
  • Page 541 Remote support uses ports 22 and 30. Ensure that these ports are opened to allow remote communication. If your Pearl-2 is on a network that is protected from the Internet by a firewall, consult with your network administrator to configure your network to allow remote Internet access through the firewall for those ports...
  • Page 542  4. Check Enable connection to maintenance server to enable outgoing links to the Epiphan maintenance server epiphany.epiphan.com.  5. Click Apply.  6. Test that Pearl-2 can access the maintenance server:  a. From the Configuration menu, select Network.  b. In Network Diagnostics, enter epiphany.epiphan.com and click ping.
  • Page 543  9. Confirm with Epiphan support that they are able to access your Pearl-2 for remote troubleshooting. Disable remote support Remote support is enabled by default. You can turn remote support off for your Pearl-2 using the Admin panel. Disabling remote support removes the ability for Epiphan to reset a lost admin password on your Pearl-2.

  • Page 544: Register Your Device

    Take advantage of exciting new features and important fixes for your Pearl-2. Registering your Pearl-2 is free and only needs to be done once. You have an option to sign up for email notifications whenever a new firmware update is available.
  • Page 545 Pearl-2 User Guide Register your device...

  • Page 546: Storage Capacity And Maintenance

    Perform disk check Check internal storage space You can check how much internal storage space is available on Pearl-2 using Using the Admin panel and from the touch screen.Pearl-2 has a 512 GB SSD. It’s good practice to monitor how much free space is available. If the amount of available storage is low, you...
  • Page 547 Pearl-2 User Guide Storage capacity and maintenance If the system is recording when you start a disk check, it will stop recording and resume after the check is complete. Frames presented during the disk check are not part of any recording.

  • Page 548: Adjust The Fan Speed

    You can adjust the internal fan speed using the Admin panel. The fan speed is set to maximum by default. We recommend leaving the fan speed at the maximum setting. Do not operate Pearl-2 at the reduced fan speed for long periods when device temperature is elevated. Lowering the fan speed could reduce the reliability of the equipment.

  • Page 549: Part 7: Troubleshooting

    Pearl-2 has easy-to-use diagnostic tools to test connectivity status, check upload/download bandwidth, traceroute, and more to help you troubleshoot your Pearl-2. You can also fine tune channel settings such as frame rate, resolution and bitrate to ensure optimal use of resources while streaming a quality video and fine tune the video input sources.
  • Page 550 Pearl-2 User Guide Diagnostic tools   Domain name resolution: Confirm that the domain name of the DNS server configured on Pearl-2 is resolvable.   Probe: Check if a network port is open on the network side. Using the Admin UI, diagnostic tools are accessed from the Configuration menu when you select Network. To...

  • Page 551: Connectivity Status Results

      A captive portal is detected and Pearl-2 can successfully reach the public Internet. Check if Pearl-2 is connected to the Internet by sending a Internet ping to IP address 8.8.8.8 on the Internet. Check if traffic can be sent and received over the network HTTP (port 80) using HTTP port 80.

  • Page 552: Run Diagnostic Tests Using The Admin Panel

    Available diagnostic tools:   Connectivity status: Display the status of critical network connections and features like 802.1x, see Connectivity status results.   Ping: Test if Pearl-2 can reach a specified destination server on the network. Not all networks support ping.
  • Page 553 Supported network protocols are: TCP, HTTP, HTTPS, RTSP, RTMP, and RTMPS. To troubleshoot networking issues yourself, try to ping the IP address of your Pearl-2 or do a traceroute to a server such as 8.8.8.8. If you are unable to resolve your networking issues, contact your network administrator and provide them the IP address and MAC address of your Pearl-2 or contact Epiphan support.

  • Page 554: Run Diagnostic Tests Using The Touchscreen

    Supported network protocols are: TCP, HTTP, HTTPS, RTSP, RTMP, and RTMPS. To troubleshoot networking issues yourself, try to ping the IP address of your Pearl-2 or do a traceroute to a server such as 8.8.8.8. If you are unable to resolve your networking issues, contact your network administrator and provide them the IP address and MAC address of your Pearl-2 or contact Epiphan support.
  • Page 555 Pearl-2 User Guide Run diagnostic tests using the touchscreen  1. Tap the gear icon to open the System settings screen. If the control icons aren't showing, tap anywhere on the touch screen.  2. Tap Network. The Network settings page opens.

  • Page 556: Troubleshooting Quick Reference

    Configure encoding. Check the touchscreen interface for audio monitoring or use No sound is coming from an audio the 3.5 mm headphone jack on the front panel of Pearl-2 to source. verify audio, see About the touch screen.
  • Page 557 Time stamps between Pearl-2 and an stamps. Verify that you are using a local NTP server on your RTSP source are not synchronized. Pearl-2 as a time synchronization server for your RTSP source, Configure a time server. Ensure Pearl-2 is connected to the network and that the...
  • Page 558 Pearl-2 User Guide Troubleshooting Quick Reference Problem Action(s) to Resolve through ffmpeg or a third-party software such as Handbrake to preserve both audio and video output. Some versions of Chrome and Microsoft Edge don't display channel previews from the Dashboard if you're on an HTTPs...
  • Page 559 Manage recorded files. Pearl-2 supports Automatic File Transfer (AFU) to CIFS servers AFU to my CIFS server doesn't work. (also known as SMB or samba) with samba version 1. Reboot the system and try again. If the problem persists, Firmware upgrade fails.
  • Page 560 Ubuntu not recognizing attached does not recognize a monitor being plugged into Pearl-2 unless monitor. the monitor is plugged into Pearl-2 before the system is turned Currently, Pearl-2 requires internet access to activate new add- Feature add-on purchase/activation not ons. If the system has internet access, ensure that there is no working.
  • Page 561 A potential conflict with the internal hard drive could cause unexpected behavior. If you deregister Pearl-2 from Kaltura and then too quickly register again using the same name, you may receive the I can't register my Pearl-2 with Kaltura following error message "Unable to register device: System...

  • Page 562: Remove Black Bars (Matte) From The Video

    Pearl-2 User Guide Remove black bars (matte) from the video Remove black bars (matte) from the video A channel with only one layout and only one source by default uses the aspect ratio of the video input source when the output is streamed. If the input video signal doesn't match the encoded frame aspect ratio of the channel, bars are added to the sides or top and bottom of the encoded stream when the output is streamed and recorded.
  • Page 563 Pearl-2 User Guide Remove black bars (matte) from the video Borders are added to the left and right of the image to preserve the narrower ratio of the input. Match output frame size with aspect ratio of input signal The output frame size is automatically matched only for a layout that has one source. If you have layouts with different frame sizes, switching them while live streaming will cause an interruption and restart of the stream.
  • Page 564 Pearl-2 User Guide Remove black bars (matte) from the video  6. You can either check Use current signal resolution as frame size or you can choose the frame size resolution from the list.  a. If the source resolution appears in the list, you can choose any resolution that's listed on the same line (i.e.

  • Page 565: Use A Specific Edid For The Video Input Port

    2. However, there may be times when a connected video source uses resolutions that you do not want to use. In that case, you can manually upload an EDID and force Pearl-2 to use a specific set of attributes for a specific HDMI input port.
  • Page 566 To get a new EDID, contact Epiphan Support. When you have the new EDID, you can upload that using the Admin panel. This feature is not available using the local console on Pearl-2. Upload a new EDID file using the Admin panel  1.

  • Page 567: Unstretch The Output Video

    Unstretch the output video Pearl-2 preserves the aspect ratio of your input video signal by default when you add the source to a layout using the custom layout editor. If you've changed the default setting, the image is stretched to match the output frame size.

  • Page 568: Remove The Combing Effect On Images

    Pearl-2 User Guide Remove the combing effect on images  4. In the items list below the layout editing area, select the video source. The video source settings appear.  5. Check Keep aspect ratio when scaling and click Save. Remove the combing effect on images When frames are interlaced, artifacts from one frame may appear on the next frame.

  • Page 569: Previous Releases And Features

      Additional HLS (pull) options to configure the segment size and playlist duration   Mutliple multicast publishers support in the same Pearl-2 channel and the ability to start and stop the publishers   Adding pre-existing recordings to an Automatic File Upload (AFU) queue  ...
  • Page 570 Added support for Kaltura's lecture capture plus live event type Release 4.10   Local Admin panel access using a USB keyboard, mouse, and monitor connected directly to Pearl-2 plus a built- in virtual keyboard, multiple keyboard language layouts, and support for touch screen monitors  ...
  • Page 571 Traffic shaping to improve video output quality when streaming over a Gibabit Ethernet network to 10/100 Mbps set-top boxes. If the API is used for traffic shaping, see the Technical Notes for your Pearl-2 model for instructions. They're available from the product resources page on the Epiphan.com...
  • Page 572 Release 4.5.1   Constant volume for layouts with multiple audio sources   Stereo and mono analog audio selection   Assign XLR B/RCA audio sources to an input   Mute audio   Remote login   Channel as a source   Mirror the video output  ...
  • Page 573 Epiphan Live recordings management Release 4.0.1   Launch of Pearl-2 Rackmount models   4K add-on Release 4.0.0   Inaugural release of Pearl-2 with the following features   Capture 6 video sources at once   Epiphan Live   Switch video sources live  ...

  • Page 574: Software License

    Software license ATTENTION: THE SOFTWARE AND DOCUMENTATION PROVIDED UNDER THIS AGREEMENT ARE BEING LICENSED TO YOU BY EPIPHAN SYSTEMS INC. ("LICENSOR") AND ARE NOT BEING SOLD. THIS AGREEMENT CONTAINS LIMITATIONS ON REPRESENTATIONS, WARRANTIES, CONDITIONS, REMEDIES, AND LIABILITIES THAT ARE APPLICABLE TO THE SOFTWARE AND DOCUMENTATION.
  • Page 575 "Your Order" means (i) the web forms provided by Epiphan or its applicable reseller or distributor for ordering Epiphan Hardware Products and related Software licenses, or (ii) written documents executed by Epiphan, or one of its resellers or distributors, and You in respect to Your purchases of Epiphan Hardware Products and/or related Software licenses.
  • Page 576 related information about the Software. You further agree not to disclose, transfer or otherwise provide to any third party any portion of the Software, except as expressly permitted herein. Some Epiphan Hardware Products and Software embed third-party APIs that integrate with third-party party services (“Third-Party Services”) to allow users of such Epiphan Hardware Products and Software to interact with such Third- Party Services for various capabilities offered by such Third-Party Services, such as, and without limitation, authentication, uploading and downloading of video content and other features made available by such Third-Party...
  • Page 577 TOTAL CUMULATIVE LIABILITY OF LICENSOR (INCLUDING ITS AFFILIATES AND ITS AND THEIR LICENSORS, SUPPLIERS, SUBCONTRACTORS, RESELLERS AND DISTRIBUTORS) TO YOU OR ANY OTHER PERSON OR ENTITY FOR ANY DAMAGES ARISING FROM THIS AGREEMENT, RELATING TO THE EPIPHAN HARDWARE PRODUCTS, SOFTWARE, DOCUMENTATION AND/OR RELATING TO ANY SERVICES PROVIDED TO YOU BY LICENSOR (INCLUDING ITS AFFILIATES AND ITS AND THEIR LICENSORS, SUPPLIERS, SUBCONTRACTORS, RESELLERS AND DISTRIBUTORS) IN RELATION TO THE EPIPHAN HARDWARE PRODUCTS, SOFTWARE AND/OR DOCUMENTATION, EXCEED THE LICENSE FEES PAID BY YOU FOR THE SOFTWARE.
  • Page 578 (collectively the “Indemnified Parties”) harmless from and against any damages, losses, liabilities, expenses, costs, claims, demands, actions, suits and/or proceedings incurred by the Indemnified Parties as a result of (i) Your use of the Epiphan Hardware Products, Software and/or Documentation, (ii) any use of the Epiphan Hardware Products, Software and/or Documentation on Your behalf, (iii) the use of the Epiphan Hardware Products, Software and/or Documentation by anyone to whom You give the Epiphan Hardware Products, Software and/or Documentation, and/or (iv) the use of the Epiphan Hardware Products, Software and/or Documentation on behalf of anyone to whom You give...
  • Page 579 Model numbers covered by this document: ESP1442, ESP1474, ESP1556, and ESP1610 Ensure the power cord attached to Pearl-2 is connected to a socket with a ground connection. WARNING: Risk of explosion if the power supply is replaced by an incorrect type.
  • Page 580 Pour placer cet appareil hors tension, débrancher tous les cordons d'alimentation sans exception. FCC Compliance Statement 47 CFR Section 2.1077 Compliance Information Unique identifier: Pearl-2 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference 2.
  • Page 581 CE Compliance Statement Marking by the symbol indicates compliance of this device with the applicable directives of the European Community and meets or exceeds the following technical standards. Directive 2014/30/EU - Electromagnetic Compatibility Directive 2014/35/EU - Low Voltage Directive Directive 2011/65/EU - RoHS, restriction of the use of certain hazardous substances in electrical and electronic equipment Warning: Operation of this equipment is not intended for a residential environment and could cause radio interference.
  • Page 582 All disputes arising out of or relating to these Terms and Conditions shall be finally resolved by arbitration conducted in the English language in Ottawa, Ontario, Canada under the commercial arbitration rules of the Canada. The parties shall appoint as sole arbitrator a retired judge who presided in the province of Ontario. The parties shall bear equally the cost of the arbitration (except that the prevailing party shall be entitled to an award of reasonable attorneys' fees incurred in connection with the arbitration in such an amount as may be determined by the arbitrator).
  • Page 583 © and ™ 2021, Epiphan Systems, Inc...

This manual is also suitable for:

Pearl-2 rackmountPearl-2 rackmount twin

Table of Contents
