Technical Specifications - Bosch EX72C7V0409-N Specifications

Technical Specifications

Color Cameras
CCD MX4 CCD Mechanical
Filter
Image Sensor 1/3 in CCD
Resolution 540 TVL color/ 540 TVL
mono
Effective Pixels 768 (H) x 494 (V)
(NTSC)
Effective Pixels 752 (H) x 582 (V)
(PAL)
Sensitivity 0.02 lux at F1.4
S/N Ratio Greater than 48 dB
Output Signal 0.45
Gamma On / Off selectable
Gain Control AGC
Electronics Iris 1/60 to 1/100,000
(NTSC)
Lens Varifocal 4 to 9 mm or 9 to 22 mm auto-iris lens
Voltage 12 VDC or 24 VAC
Power consumption 3.9 W (max.)
Cabling holes Two 3/4-inch NPT conduit entries
Operation Tempera- -50 ºC to +40 ºC (-58 ºF to 104 ºF)
ture Range
Weight 1.4 kg (3.1 lbs)
Dimensions 117 x 117 x 99 mm (4.6 x 4.6 x 3.9 in)
Note To order a CSA/ UL certified product use
product codes without the AT suffix. To order
an ATEX certified product use product codes
with the AT suffix.
Ordering Information
EX72C7V0409‑N Explosion-protected
Camera
1/3 in color CCD, 500 TVL, varifocal 4 to
9 mm lens, NTSC, CSA/UL Certified
EX72C7V0409‑P Explosion-protected
Camera
1/3 in color CCD, 500 TVL, varifocal 4 to
9 mm lens, PAL, CSA/UL Certified
EX72C7V0922‑N Explosion-protected
Camera
1/3 in color CCD, 500 TVL, varifocal 9 to
22 mm lens, NTSC, CSA/UL Certified
EX72C7V0922‑P Explosion-protected
Camera
1/3 in color CCD, 500 TVL, varifocal 9 to
22 mm lens, PAL, CSA/UL Certified
C7 High Resolution Col-
or
1/3 in Interline Super-
HAD
500 TVL
768 (H) x 494 (V)
768 (H) x 582 (V)
2.7 lux at F1.4
Greater than 48 dB
1/50 to 1/100,000
(PAL)
EX72C7V0409-N
EX72C7V0409-P
EX72C7V0922-N
EX72C7V0922-P
EX72 Explosion‑protected Camera | 3
Ordering Information
EX72MX4V0409‑N Explosion-protected
Camera
Day/Night 1/3 in CCD, 540/540 TVL, mech
filter, varifocal 4 to 9 mm lens, NTSC, CSA/
UL Certified
EX72MX4V0409‑P Explosion-protected
Camera
Day/Night 1/3 in CCD, 540/540 TVL, mech
filter, varifocal 4 to 9 mm lens, PAL, CSA/UL
Certified
EX72MX4V0922‑N Explosion-protected
Camera
Day/Night 1/3 in CCD, 540/540 TVL, mech
filter, varifocal 9 to 22 mm lens, NTSC, CSA/
UL Certified
EX72MX4V0922‑P Explosion-protected
Camera
Day/Night 1/3 in CCD, 540/540 TVL, mech
filter, varifocal 9 to 22 mm lens, PAL, CSA/UL
Certified
EX72C7V0409AT-P Explosion-protected
Camera
1/3 in color CCD, 500 TVL, varifocal 4 to
9 mm lens, PAL, ATEX Certified
EX72MX4V0409AT-P Explosion-protected
Camera
Day/Night 1/3 in CCD, 540/540 TVL, mech.
filter, varifocal 4 to 9 mm lens, PAL, ATEX
Certified
Accessories
EXMB.028B Cable Managed Wall Bracket
Cable-managed arm bracket, black
EXMB.072B Adapter Bracket
EXMB72 Adapter Bracket, Black
EXMB.015B Pole Mount Adapter Bracket
Pole Mount Adapter, black
EXMB.017B Wall Mount Adapter Bracket
Wall Mount Adapter, Black
EXMB.004B Ceiling and Pedestal Bracket
Mounting Bracket, HD, Pan/Tilt Adjust - Ceil-
ing Mount for EX52, EX62, black
UPA-2430-60 Power Supply
120 VAC, 60 Hz, 24 VAC, 30 VA Out
UPA-2420-50 Power Supply
220 VAC, 50 Hz, 24 VAC, 20 VA Out
EX72MX4V0409-N
EX72MX4V0409-P
EX72MX4V0922-N
EX72MX4V0922-P
EX72C7V0409AT-P
EX72MX4V0409AT-
P
EXMB.028B
EXMB.072B
EXMB.015B
EXMB.017B
EXMB.004B
UPA-2430-60
UPA-2420-50
