Horus AQUA 14.0 Operating, Installation And Maintenance Manual

Table of Contents
  • Italiano

    • Table of Contents
    • Informazioni Generali
    • Simbologia Utilizzata
    • Scopo E Contenuto del Manuale
    • Destinazione D'uso
    • Generalita
    • Normative DI Riferimento
    • Garanzia
    • Responsabilita' del Costruttore
    • Consegna E Controllo Della Stufa
    • Prescrizioni Per L' Installatore
    • Avviso Per L' Utilizzatore
    • Descrizione Della Stufa
    • Caratteristiche Tecniche
    • Tipi E Dimensioni DI Combustibili Raccomandati
    • Verifica Visiva Della Stufa
    • Installazione
    • Che Cosa E' Richiesto Per L'installazione Della Stufa
    • Posizionamento Della Stufa
    • Avvertenze DI Sicurezza Per L'allacciamento/Attivazione Della Stufa
    • Presa D'aria Esterna E Collegamento Alla Canna Fumaria
    • Collegamento Ad un Condotto con Tubo Isolato O Doppia Parete
    • Raccordo a Canna Fumaria
    • Collegamento a Canna Fumaria
    • Nozioni Utili Per la Canna Fumaria
    • Messa in Funzione
    • Carica Combustibile
    • Distanza Minima da Materiale Infiammabile
    • Accensione
    • Manutenzione Ordinaria
    • Console
    • A Cosa Servono I Pulsanti
    • Il Menu
    • Menu Utente
    • Menu 01 - Set Orologio
    • Menu 02 - Set Crono
    • Sottomenu 02-01 Abilita Crono
    • Sottomenu 02-02 Programmazione Giornaliera
    • Sottomenu 02-03 Programmazione Settimanale
    • Sottomenu 02-04 Programmazione Week-End
    • Menu 03 Scegli Lingua
    • Menu 04 Modo Stand-By
    • Menu 05 Modo Cicalino
    • Menu 06 Carico Iniziale
    • Menu 07 Stato Stufa
    • Menu 08 Tarature Tecnico
    • Modalita' Operativa
    • Accensione Della Stufa
    • Fase DI Avvio
    • Mancata Accensione
    • Stufa in Lavoro
    • Modifica Dell'impostazione Della Temperatura Ambiente E del Set Potenza
    • Impiego del Termostato/Cronotermostato Esterno
    • Modifica Dell'impostazione Della Temperatura Acqua
    • La Temperatura Ambiente Raggiunge la Temperatura Impostata
    • Riavvio Dopo lo Spegnimento Per Raggiunto Set Temperatura Ambiente E/O Acqua
    • Pulizia Braciere
    • Spegnimento Della Stufa
    • Stufa Spenta
    • Riaccensione Della Stufa
    • Che Cosa Succede Se
    • Il Pellet Non si Accende
    • Manca L'energia Elettrica
    • Allarmi
    • Allarme Sonda Temperatura Fumi
    • Allarme Sovra Temperatura Fumi
    • Allarme Per Mancata Accensione
    • Allarme Spegnimento Durante la Fase DI Lavoro
    • Allarme Pressostato DI Sicurezza
    • Allarme Termostato Generale
    • Avvertenze Fondamentali
    • Manutenzione a Cura del Cat (Centro Assistenza Autorizzato)
    • Operazioni da Eseguire Ogni Stagione Prima Dell'accensione a Cura del Cat
    • Per L'installatore
    • Condizioni DI Garanzia E Richiesta Intervento
    • Certificato DI Garanzia Fontana Forni Srl
  • Français

    • But Et Contenu du Manuel
    • Données Générales
    • Informations Générales
    • Normes de Référence
    • Symboles Utilisés
    • Utilisations
    • Avertissement Pour L'utilisateur
    • Garantie
    • Livraison Et Contrôle du Poêle
    • Remarques Pour L'installateur
    • Responsabilité du Constructeur
    • Descrtiption du Poêle
    • Caractéristiques Techniques
    • Ce Qui Est Nécessaire Pour L'installation du Poêle
    • Emplacement du Poêle
    • Installation
    • Types Et Dimensions de Combustibles Recommandés
    • Vérification Visuelle du Poêle
    • Consignes de Sécurité Pour Le Branchement/Mise en Service du Poêle
    • Prise D'air Extérieure Et Branchement Au Conduit de Fumée
    • Informations Utiles Pour Le Conduit de Fumée
    • Jonction Au Conduit de Fumée
    • Raccordement Au Conduit de Fumée
    • Allumage
    • Chargement du Combustible
    • Distance Minimale de Matériaux Inflammables
    • Mise en Service
    • Entretien Ordinaire
    • Le Menu
    • Menu 01 - Set Horloge
    • Menu 02 - Set Chrono Sous-Menu 02-01 Habilite Chrono
    • Tableau de Commande
    • Sous-Menu 02-02 Programmation Quotidienne
    • Sous-Menu 02-03 Programmation Hebdomadaire
    • Menu 03 Sélection Langue
    • Menu 04 Mode Stand-By
    • Menu 05 Mode Avertisseur Sonore
    • Menu 06 Chargement Initial
    • Menu 07 État Poêle
    • Modalité Opérationnelle
    • Sous-Menu 02-04 Programmation Weekend
    • Allumage du Poêle
    • Défaut D'allumage
    • Modification de la Température Ambiante Et du Réglage Puissance
    • Nettoyage Creuset
    • Phase de Démarrage
    • Poêle en Fonction
    • Prévue
    • Redémarrage Après Extinction Pour Avoir Atteint la Température
    • Température Ambiante Atteint la Température Introduite
    • Utilisation du Thermostat/Chrono Thermostat Externe
    • Alerte Avarie Ventilateur D'extraction des Fumées
    • Alerte Extinction Pendant Le Fonctionnement
    • Alerte Pressostat de Sécurité
    • Alerte Température Fumées Trop Haute
    • Alerte Thermostat Général
    • Alerte Échec Allumage
    • Allarme Pressostato DI Sicurezza
    • Il N'y a Pas D'électricité
    • Toute Situation D'alerte Cause L'IMMédiate Extinction du Poêle
    • Entretient Par Le Sav (Service Après-Vente Autorisé)
    • Instructions Fondamentales
    • OPÉRATIONS ANNUELLES AVANT ALLUMAGE PAR LE SAV (Service Après-Vente Autorisé)
    • Pour L'installateur
    • Conditions de Garantie Et Demande D'intervention
    • Certificat de Garantie Fontana Forni Srl
  • Dutch

    • Algemeen
    • Algemene Informatie
    • Bedoeld Gebruik
    • Doel en Inhoud Van Deze Handleiding
    • Garantie
    • Gebruikte Symbolen
    • Referentievoorschriften
    • Levering en Controle Van de Kachel
    • Opmerking Voor de Gebruiker
    • Verantwoordelijkheid Van de Fabrikant
    • Voorschriften Voor de Installateur
    • Beschrijving Van de Kachel
    • Installatie
    • Soorten en Afmetingen Van Aanbevolen Brandstof
    • Technische Gegevens
    • Visuele Controle Van de Kachel
    • Wat Vereist Is Voor Het Installeren Van de Kachel
    • Plaatsing Van de Kachel
    • Waarschuwingen Betreffende Veiligheid Voor Aansluiting/Inschakeling Van de Kachel88
    • Externe Luchtinlaat en Aansluiting Op de Rookgasafvoer
    • Aansluiting Aan Rookgasafvoer
    • Aansluiting Op Een Leiding Met Geisoleerde Buis of Dubbele Wand
    • De Externe Buis Moet Minimale Binnenafmetingen Hebben Van 10 X 10 CM of 10 CM Diameter en Maximale Van 20 X 20 CM of 20 CM Diameter
    • Verbinding Aan Rookgasafvoer
    • Inbedrijfstelling
    • Laden Van Brandstof
    • Minimale Afstand Van Brandbare Materiaal
    • Nuttige Opmerkingen Voor de Rookgasafvoer
    • Inwerkingstelling
    • Routine Onderhoud
    • Console
    • Het Menu
    • Menu 01 - Instellen Klok
    • Menu 02 - Instellen Chrono Sub-Menu 02-01 Chrono Inschakelen
    • Bedrijfsmodus
    • Fase Van Opstarten
    • Gemiste Inschakeling
    • Inschakelen Van de Kachel
    • Kachel in Werking
    • Menu 03 Kies Taal
    • Menu 04 Stand-By Modus
    • Menu 05 Zoemer Modus
    • Menu 06 Initiële Lading
    • Menu 07 Status Kachel
    • Alarm Oververhitting Rookgassen
    • Alarm Sensor Rookgastemperatuur
    • Alarm Voor Mislukte Inschakeling
    • Elke Alarmvoorwaarde Veroorzaakt Het Onmiddellijk Uitzetten Van de Kachel
    • Gebrek Electriciteit
    • Heropstarten Na Het Uitschakelen Omdat de Ingestelde Kamer Temperatuur Bereikt Is
    • Opnieuw Inschakelen Van de Kachel
    • Reiniging Vuurpot
    • Uitzetten Van de Kachel
    • Wat Gebeurt er als
    • Alarm Algemene Thermostaat
    • Alarm Drukbeveiliging
    • Alarm Ventilator Afzuiging Rookgassen Defect
    • Belangrijke Waarschuwingen
    • Handelingen die Ieder Seizoen Door de Technische Bijstandsdienst Moeten Worden Uitgevoerd Vooraleer in te Schakelen
    • Onderhoud Door de Technische Bijstandsdienst
    • Garantievoorwaarden en Interventie-Aanvraag
    • Voor de Installateur
    • Garantiecertificaat Fontana Forni Srl

Advertisement

Available languages

Available languages

Quick Links

STUFA A PELLET
AQUA-PURO
MANUALE DI INSTALLAZIONE USO E MANUTENZIONE
MOD. AQUA 14.0 – 18.5
MOD. PURO 14.0 – 18.5
(IT)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUA 14.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Horus AQUA 14.0

  • Page 1 STUFA A PELLET AQUA-PURO MANUALE DI INSTALLAZIONE USO E MANUTENZIONE MOD. AQUA 14.0 – 18.5 MOD. PURO 14.0 – 18.5 (IT)
