Bogen UDMS16BP Specifications

UHF Wireless
Microphone Systems
UDMS16BP, UDMS16HH
These UHF Wireless Microphone Systems offer users the
freedom to move around while speaking. System choices
consist of a 16-channel PLL-synthesized UHF Receiver with
either a handheld microphone or lavaliere microphone and
body-pack transmitter. Headset microphone also available.
UBP16
Body-Pack w/Lavaliere Microphone
• Audio mute switch allows convenient audio muting while
leaving the transmitter "ON"
• LED indicator: Unit "ON", and "Low Battery Alert"
• Locking 3.5mm mini-jack provides secure connection for
removable microphone
• Convenient, economical operation with AAA alkaline
or NiMH batteries (2x)
• 2-1/4" W x 3-3/8" H x 1-1/8" D; 3 oz.
UHT16
Handheld Microphone
• Sleek metal housing with internal antenna
for optimum aesthetics and durable long life
•Uni-directional neodymium dynamic cartridge
for optimum sound, maximum feedback rejection,
and minimal handling noise
• Audio mute switch allows convenient audio muting while
leaving the transmitter "ON"
• LED indicator: Unit "ON", and "Low Battery Alert"
• Convenient, economical operation with AA alkaline
or NiMH batteries (2x)
• 2" dia. x 9-1/8" long; 10 oz.
UDR16
16-Channel
PLL-Synthesized UHF Receiver
• Offers 16 user-selectable frequencies in UHF 470-510 MHz band;
120 dB dynamic range; operation up to 500 feet line-of-sight
• DigiTRU Diversity™ for maximum range and dropout protection,
full LED indicators, 1/4" unbalanced and XLR balanced outputs,
Tone Squelch™ for locking out potential interference, noiseless
transmitter ON/OFF switching, & level control for unbalanced output
• Half-rack receiver design with front panel dual antennas,
powered by wall power adapter
• 8-1/8" W x 1-7/8" H x 5-1/2" D; 1 lb.
(UBP16 Body-Pack
A C C E S S O R I E S
BCHM
Headset
Microphone
Microphone
required)
UDR16
UDR16
MC28
RPK89
Clip
Rack Mount
(for UHT16)
(Single Unit)
UBP16
UDMS16BP
includes:
• UBP16 Body-Pack
& Lavaliere Mic
• UDR16 UHF Receiver
UDMS16HH
includes:
• UHT16 Handheld Mic
• UDR16 UHF Receiver
UHT16
RPK90
Rack Mount
(Double Unit)
