- Page 1 Bogen Enhancer Instruction Manual © 2005 Bogen Communications, Inc. All Rights Reserved. 54-2141-01B 0608...
-
Page 2: Table Of Contents
Contents Introduction ..................................3 Using This Manual ................................3 Enhancer System Contents ............................3 System Features ................................4 BCWR Receiver ................................5 BCIRS Infrared (IR) Sensors ............................6 BCWBT Body-Pack Transmitter ........................... 7 BCHM Headset Microphone ............................8 BCWHT Handheld Microphone Transmitter ......................9 Specifications .................................. -
Page 3: Introduction
Please read the instructions pertaining to your system completely before operating. This manual first lists the features of the Enhancer and then shows you how to operate the system. After reading the receiver instructions, turn to the section that covers the type of transmitter and microphone you are using with the system. -
Page 4: System Features
System Features BCWR Dual-Channel Wireless Microphone Receiver • Dual Receiver, Simultaneous 2-Channel Operation for 2 Transmitters (Ch. A, Ch. B) • Infrared (IR) Signal Reception LED Indicators • Channel A/B Mixed Audio Output RCA-type Connector • Separate Channel A and Channel B Volume Controls •... -
Page 5: Bcwr Receiver
BCWR Receiver Front 16V AC POWER INPUT Rear Powering the Receiver Using the AC Power Adapter, connect the AC Power Input (6) to an AC outlet (110-120V AC).Turn ON the BCWR Receiver using the Power Switch (1).The IR Reception LED Indicators (2) will now light either green or red, depending on whether the corresponding transmitters are ON or OFF. -
Page 6: Bcirs Infrared (Ir) Sensors
Note:The IR sensors will need to be positioned differently for each environment. During installation, power up the Bogen Enhancer System and have one person walk around the desired location, with the transmitters on, while another person positions the IR Sensors for greatest range of mobility. -
Page 7: Bcwbt Body-Pack Transmitter
BCWBT Body-Pack Transmitter Transmitter Setup Slide down the Battery Compartment Cover (1), as shown, exposing the battery compartment. Insert 2 fresh AA alkaline batteries or the optional BCBRBP Battery Pack NiMH rechargeable batteries while observing the correct polarity as marked. Set the Channel Selector Switch (2) to the desired channel of operation and slide the cover back into position on the unit. -
Page 8: Bchm Headset Microphone
BCHM Headset Microphone Operation a.The BCHM is provided with a 3.5mm Locking Connector (1) for connecting the headest to the BCWBT Transmitter. After disconnecting the Lavaliere Microphone from the BCWBT Transmitter, plug in the Headset’s connector.To secure the connection, turn the metal slip ring on the connector clockwise to thread it on the jack.To unplug, reverse the process. -
Page 9: Bcwht Handheld Microphone Transmitter
BCWHT Handheld Microphone Transmitter Transmitter Setup Unscrew and remove the Battery Compartment Cover (1) by sliding it down off the microphone to expose the battery holder. Insert 2 fresh AA alkaline batteries or the optional BCHRBP Battery Pack NiMH rechargeable batteries, while observing the correct polarity as marked, and screw the cover back on the battery compartment. -
Page 10: Specifications
Specifications BCWR Receiver: Mode Infrared Frequency Modulated Receiving channels Dual-Channels A & B Carrier frequency Ch. A: 2.0 MHz; Ch. B: 2.6 MHz Audio frequency response 60 Hz-12 kHz S/N ratio > 90 dB Audio Mix Output 400 mV Range (line-of-sight) Up to 30 ft. -
Page 11: Warranty
(including, but not limited to, loss of profits, loss of data or loss of use damages) arising out of the manufac- ture, sale or supplying of products, even if Bogen has been advised of the possibility of such damages or loss- es. - Page 12 50 Spring St. Ramsey, N J 07446 Tel: 201-934-8500, Fax: 201-934-9832 www.bogen.com...
