CDR6221
DVD Multimedia Receiver with Bluetooth
featuring a 6.2" Touch-Screen Display
INSTALLATION &
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDR6221 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Jensen CDR6221

  • Page 1 CDR6221 DVD Multimedia Receiver with Bluetooth featuring a 6.2" Touch-Screen Display INSTALLATION & OWNER’S MANUAL...
  • Page 2: Fcc Compliance

    FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3: Safety Notice

    Park and the parking brake is engaged. It is illegal in most jurisdictions for the driver to view video while the vehicle is in motion. It is highly recommended that your JENSEN CDR6221 is installed by a professional installer or an authorized dealer.
  • Page 4: Installation

    CDR6221 INSTALLATION Preparation Please read and understand entire manual before installation. Consult a qualified technician for detailed instructions or installation assistance. Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
  • Page 5 CDR6221 INSTALLATION Wiring Diagram - Inputs/Outputs FR OUT FL OUT V OUT SUB OUT RR OUT RL OUT CAM IN SUB OUT EXTERNAL MIC INPUT VIOLET/WHITE (Compatible with most SWC Interfaces) BLUE/WHITE ORANGE Note: When replacing a fuse, make sure to use the correct type and amperage. Using an incorrect fuse could cause damage.
  • Page 6: Control Locations

    CDR6221 OPERATION Control Locations Tune/Track Up Microphone Power/Volume/Mute microSD Card Slot Tune/Track Down Eject USB Port Reset Auxiliary Input Voice Activation Button...
  • Page 7 CDR6221 OPERATION General Operation Momentarily press to turn the unit on. Press and hold to turn the Power On/Off unit off. Rotate the volume knob to increase or decrease the volume level. Volume Momentarily press MUTE to silence the audio. Momentarily press Mute MUTE again to return to the previously selected volume.
  • Page 8: General Operation

    OPERATION CDR6221 General Operation From the Main Menu screen, select Settings to access the Setup menu Settings Menu and select from categories displayed on the left side of the screen: General, Clock, Audio, Bluetooth, Display and About. Use the touch screen to navigate and adjust individual options within each category.
  • Page 9: Am/Fm Tuner Operation

    CDR6221 OPERATION AM/FM Tuner Operation AM/FM Tuner Operation 10 11 12 Select the Radio icon from the Main Menu screen. Radio Operation Mode / Main Menu Displays current mode of operation. Press to return to Main Menu. Preset Stations Press and hold to set the current station in that preset spot. Press momentarily to recall the desired preset and begin playback.
  • Page 10: Usb/Microsd Card Operation

    CDR6221 OPERATION USB/microSD Card Operation To play audio files from a USB device or microSD card, insert USB/microSD Operation device and playback will begin automatically. To return to USB or microSD card playback from another mode of operation, select the corresponding icon from the Main Menu.
  • Page 11 CDR6221 OPERATION Media Compatibility - USB/microSD Card File Type FAT 12 File System FAT 16/FAT 32  .mp3/.MP3/.Mp3/.mP3  File Extension .rmp/.m4a MPEG 1  MPEG MPEG 2  Format MPEG 2.5  MPEG 1 32/44.1/48kHz Sampling MPEG 2 12/16/22.05/24kHz Frequency MPEG 2.5...
  • Page 12 CDR6221 OPERATION Media Compatibility - CD/DVD File Type Level 1, Level 2  ISO9660 Level 3 Playback  ISO9660 JOLIET File System Extension Filename 32 bytes Playback ROMEO Other Filename Extensions Apple ISO .mp3/.MP3/.Mp3/.mP3  File Extension .rmp/.m4a MPEG 1 ...
  • Page 13: Media Compatibility

    CDR6221 OPERATION Media Compatibility Media Compatibility The following types of files are not compatible: • MP3 PRO format, MP3 playlists • RMP format • WAV format • WMV format • AAC, protected AAC, M4A format Playback Order MP3 playback sequence begins in the root folder of the USB flash drive or microSD card.
  • Page 14: Dvd Operation

    OPERATION CDR6221 DVD Operation Inserting a Disc Insert disc into the slot, and playback will begin automatically. Sub-menus may have to be pressed to access the DVD content. Read the directions of your specific DVD disc for other features. Ejecting the Disc Press to eject the disc.
  • Page 15 CDR6221 OPERATION DVD Operation Direct Entry Enter a chapter number directly to begin playback. Audio Press to access and adjust audio settings. Repeat Press to repeat current chapter. Random Press to enable or disable random playback. Next Page Press to display the next page of options.
  • Page 16: Bluetooth Operation

    The unit broadcasts the pairing signal constantly when no devices are currently connected. Complete the pairing sequence from your Bluetooth device. Refer to the owner's manual for your device for more details. The device name is "CDR6221". The Bluetooth passcode is "0000".
  • Page 17 CDR6221 OPERATION Bluetooth Operation Keypad Press to display the telephone keypad. Contacts Press to display a list of stored contacts. Recents Press to view a list of recently calls. Device Press to view and select available devices. Previous File/Track Press to return to the previous file/track.
  • Page 18: Swc Input Operation

    OPERATION CDR6221 SWC Input Operation The built-in SWC Interface is compatible with PAC steering wheel control modules. The PAC SWI-RC is recommended. A third-party adapter must be used in order for the XDVD600 to be compatible with any steering wheel controls. The following controls are available for most vehicles.
  • Page 19: Voice Assistant

    CDR6221 OPERATION Voice Assistant Your receiver is designed with an easy access voice activation button to use Siri® or the Google Assistant™ via your car’s Bluetooth. Interact with your smartphone assis- tant while you drive with only the push of a button! Bluetooth should be paired between your smartphone and the receiver.
  • Page 20 OPERATION CDR6221 Rear Camera Operation - (Optional) Connect an optional rear camera to the Camera Input (Black RCA connector). Refer to the wiring diagram for details. Manual selection - Touch CAMERA icon from the Main Menu or from any operational mode (when enabled) to select camera mode.
  • Page 21 JENSEN dealer and used in the U.S.A. • Call us toll-free at (888) 921-4088 • E-mail us at cs@jensenmobile.com...
  • Page 22: Specifications

    CDR6221 OPERATION Specifications Disc Frequency response: 20Hz-20kHz Channel separation @ 1kHz: >80dB D/A converter: 24 Bit FM Tuner Tuning range: 87.5MHz-107.9MHz Usable sensitivity: 10dBf 50dB quieting sensitivity: 20dBf Stereo separation @ 1kHz: 38dB Frequency response: 30Hz-13kHz AM Tuner Tuning range:...
  • Page 23: Troubleshooting

    Please keep your original sales receipt and be prepared to provide this receipt in the event you require service, as your original receipt is considered the best proof of purchase and indicates the date you purchased your JENSEN product. Dealer Name...
  • Page 24 CDR6221 INSTALLATION & OWNER’S MANUAL Customer Support 1-888-921-4088 (Monday-Friday, 9AM-5PM EST) Visit https://www.jensenmobile.com Designed and Engineered in USA All rights reserved. No part of this publication may be reproduced, distributed, or transmitted in any form or by any means, including photocopying, recording, or other electronic or mechanical methods, without the prior written permission of NAMSUNG AMERICA INC.
