SIMATIC ET 200S distributed I/O 2AO U HF analog electronic module (6ES7135-4LB02-0AB0)
SIMATIC
ET 200S distributed I/O
2AO U HF analog electronic module
(6ES7135-4LB02-0AB0)
Manual
04/2007
A5E01076940-01
Preface
______________
Properties
______________
Parameters
______________
Diagnostics
______________
Analog value representation
______________
Connecting
1
2
3
4
5

Advertisement

Table of Contents
loading

Related Manuals for Siemens 2AO U HF

Summary of Contents for Siemens 2AO U HF

  • Page 1 Preface SIMATIC ET 200S distributed I/O 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) ______________ Properties ______________ Parameters SIMATIC ______________ Diagnostics ET 200S distributed I/O 2AO U HF analog electronic module ______________ Analog value representation (6ES7135-4LB02-0AB0) ______________ Connecting Manual 04/2007 A5E01076940-01...
  • Page 2 Trademarks All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

  • Page 3: Preface

    Additional support If you have any questions relating to the products described in these operating instructions, and do not find the answers in this document, please contact your local Siemens representative. http://www.siemens.com/automation/partner...
  • Page 4 ● The bulletin board, a worldwide knowledge exchange for users and experts. ● Your local contact for Automation & Drives in our contact database. ● Information about on-site services, repairs, spare parts. Lots more can be found on our "Services" pages. 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...

  • Page 5: Table Of Contents

    Effect on analog value representation ..................17 4.4.1 Effect of the supply voltage and the operating state on analog output values ......17 4.4.2 Effect of the value range on the 2AO U HF analog output ............18 Connecting .............................. 19 Connecting analog outputs ......................19 Index................................ 21...
  • Page 6 Table of contents 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...

  • Page 7: Properties

    Properties 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Properties ● 2 outputs for voltage output ● Output range: – ±5 V, resolution 15 bits + sign – ± 10 V, resolution 15 bits + sign – 1 V to 5 V, resolution 15 bits ●...
  • Page 8 Properties 1.1 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Usable terminal modules Usable terminal modules for 2AO U HF (6ES7135-4LB02-0AB0) TM-E15C26-A1 TM-E15C24-01 Spring terminal (6ES7193-4CA50- (6ES7193-4CB30- 0AA0) 0AA0) TM-E15S26-A1 TM-E15S24-01 Screw-type terminal (6ES7193-4CA40- (6ES7193-4CB20- 0AA0) 0AA0) TM-E15N26-A1 TM-E15N24-01 (6ES7193-4CA80- (6ES7193-4CB70-...
  • Page 9 Properties 1.1 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) 2AO U HF technical specifications (6ES7135-4LB02-0AB0) Dimensions and weight Width (mm) Weight Approx. 40 g Module-specific data Supports isochronous operation Supports I&M functions Number of outputs Cable length Shielded • Max. 200 m Max.
  • Page 10 Properties 1.1 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Suppression of interference, limits of error Crosstalk between the outputs Min. -60 dB Operational limit ± 0,1 % Intrinsic error limit ± 0,05 % Temperature error (with reference to the output ±0.003%/K...

  • Page 11: Parameters

    Substitute values must be within the nominal range. You can assign values from -27,648 to +27,648 as parameters (when assigning parameters using the GSD file). 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...
  • Page 12 Parameters 2.1 Parameters 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...

  • Page 13: Diagnostics

    Event (LED) Cause Remedy No configuration or incorrect Check the parameter module plugged in. No load assignment. Check the load voltage.present There is a voltage. Evaluate the diagnostic message. diagnostics. 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...

  • Page 14: Error Types

    Internal module error has Replace the module. occurred (diagnostic message on channel 0 applies to the entire module). 00001: Short circuit Short circuit of the final Correct the process wiring. controlling element supply. 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...

  • Page 15: Analog Value Representation

    Analog value Bit number Significance of the bits Sign The sign (S) of the analog value is always in bit number 15: ● "0" → + ● "1" → – 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...

  • Page 16: Output Ranges

    20736 5100 Nominal range -3,7500 - 7,5000 -20736 AF00 -5,0000 - 10,0000 -27648 9400 -5,0002 - 10,0004 -27649 93FF Underrange -5,8800 - 11,7589 -32512 8100 < -32512 < 8100 Underflow 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...

  • Page 17: Effect On Analog Value Representation

    • "CPU/master STOP" L+ missing POWER ON STOP L+ present Dependent on the parameter "CPU/master STOP" L+ missing POWER OF L+ present Dependent on the parameter "CPU/master STOP" L+ missing 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...

  • Page 18: Effect Of The Value Range On The 2Ao U Hf Analog Output

    4.4 Effect on analog value representation 4.4.2 Effect of the value range on the 2AO U HF analog output The way electronic modules respond to analog outputs depends on where the output values fall within the value range. This is illustrated by the table below.

  • Page 19: Connecting

    Analog output modules In the case of the analog output modules there is generally galvanic isolation ● Between logic and backplane bus. ● Between the load voltage and M ANA. 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...
  • Page 20 Connecting 5.1 Connecting analog outputs 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...

  • Page 21: Index

    During operation, 17 When faults occur, 17 Cables for analog signals, 19 Scope Disposal, 3 Manual, 3 Service & Support, 4 Internet Service & Support, 4 Technical Support, 4 Training center, 4 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...
  • Page 22 Index 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) Manual, 04/2007, A5E01076940-01...

This manual is also suitable for:
