Chapter 2: Description
Overview
This chapter describes external and internal components of the M2A Transmitter.
External Description
This section describes the junction box and all external components of the M2A transmitter.
Junction Box Cover
8
3/4 NPT Conduit Hub, Plugged
Mounting Slot (2x)
Window
3/4 NPT
Conduit Hub
Detector
Figure 1: M2A External Components
Magnetic
Wand
M2A Transmitter Operator's Manual
