MANUALE ERPICI PIEGHEVOLI DJ-DP-DK-DMAX
The ballast to add is calculated with the formula:
Gv min. = (Mb tot x (C + Lb tot)) – (Tv x B) + (0,2 x Te x B)
-----------------------------------------------------------------
- The distance from the center of gravity of the combi machine to the lower hitch of the tractor is calculated with the formula:
Lb tot = (Lb1 x Mb1) + (Lb2 x Mb2) + (Lb3 x Mb3) + (Lb4 x Mb4) + (Lb....x Mb....)
------------------------------------------------------------------------------------------------------
Mb1+Mb2+Mb3+Mb4+Mb....
- The overall weight of the entire combi machine is calculated with the formula:
Mb tot = Mb1+Mb2+Mb3+Mb4+Mb.....
On the front bridge of the tractor it must, in any
case, burden at least 20% of the total mass
tractor-tool in march order. It is however to hold
present that, beyond to the appropriated one
chosen the connection tractor-tool, the
application of ballasts in front position, the limits
and with the modalities indicated from the
constructor of the tractor, can improve of the
stability. Moreover, with firm tractor it must be
made to come down to earth the tool avoiding
therefore possible involuntary reductions,
improving at the same time, the stability.
Copyright ©2009 della Alpego spa® - All rights are reserved. Reprinting or unauthorized use of this manual is strictly forbidden without written permission by Alpego spa
A+B
Tractor wheelbase
Distance of the front axle
from the front ballast:
Tractor weight
Ballast weight:
Load on the tractor's axle
when empty:
Implement weight:
Tot center of gravity length:
Old Cod.D03214
Q00A00017 R.23
B =............ m
A =............ m
Te =...............Kg
Gv =...............Kg
Tv =......... Kg
Mb tot =......... Kg
Lb tot =................m
INSTALLATION
