Summary of Contents for Sauber SF-100
- Page 1 SF-100...
- Page 2 Accessories...
-
Page 3: Specifications
SF-100 Pro Pets Bagless Vacuum Congratulations on the purchase of your new Sauber vacuum cleaner. There are many useful features built into your cleaner. We recommend that you carefully read this instruction manual for the best results. Handle Air Outlet... -
Page 4: Before You Begin
Before You Begin This cleaner must be operated in accordance with these instructions and used only for domestic household cleaning to remove DRY dirt and dust from household carpets, flooring, walls and fabrics. This cleaner is not fit to be used as an industrial cleaner and will void the manufacturer’s warranty if used inappropriately. - Page 5 IMPORTANT! Always switch off the cleaner and remove the power plug from the electricity power supply before cleaning your appliance, when not in use or attempting any maintenance task. The cleaner must only be connected to an AC power supply at the voltage shown on the rating label.
- Page 6 15. Ensure the appliance is disconnected from the the electrical parts, especially the electrical mains power supply before connecting the hose connections, with water or liquid cleaners. to the unit. 26. Never attempt to make any modifications 16. Do not operate or use the appliance without the electrically to the vacuum cleaner.
- Page 7 Assembly IMPORTANT! Always remove the power plug from the power supply before fitting or removing accessories! LIVE PARTS within the hose, rod and Powerhead. Connecting Flexible Hose Fitting: Insert the flexible hose into the hose inlet of the vacuum. Press until it clicks into position.
-
Page 8: Dusting Brush
Accessories Powerhead Deep-cleaning Powerhead easily removes embedded pet hair, dirt and dust. Note: not recommended for use on hard floors. WARNING! Seek advice from carpet manufacturers before using the motorised Powerhead on woollen or delicate carpets. Combination Floor Tool Perfect for hard floors or carpeted surfaces. Carpet Hard Floors Crevice Tool... -
Page 9: Upholstery Tool
Upholstery Tool Designed to remove dust from sofas, chairs, mattresses and cushions. Mini Hand Turbo Tool Makes light work of removing pet hair from your furniture, car and upholstery. Safety Precautions: Keep hair, hands and feet away from rotating brush while the motorised brush is running. - Page 10 Instructions For Use IMPORTANT! Always remove the power plug from the power supply before fitting or removing accessories. Turning On/Off the Cleaner Unwind a sufficient length of cable. The yellow mark on the power cable shows the ideal cable length. DO NOT extend the cable beyond the red mark.
-
Page 11: Maintenance
Maintenance IMPORTANT! Always remove the power plug from the power socket before performing any maintenance. Vacuum Cleaner Storage When not in use, ensure that the cleaner is disconnected from the power supply and that the cable is fully retracted. The combination floor tool can be stored in the floor park clip. The Powerhead must be stored separately. -
Page 12: Blockage Indicator
Cleaning and Replacing the Pre-Motor Filter IMPORTANT! Always remove the power plug from the power supply before fitting or removing accessories. Caution: To avoid damaging the dust container, remove the dust container from the cleaner before cleaning or replacing the filter. Press the dust bin lid release button to access the Pre-Motor filter. - Page 13 Cleaning and Replacing the Rear Motor HEPA Filter Remove the exhaust grille. The Rear Motor HEPA Filter is installed behind the exhaust grille. When dust or dirt is visible on the surface of the HEPA filter, the filter should be replaced to maintain efficient suction. Note: It is recommended to replace the HEPA filter every 6 months or when it becomes visibly dirty.
- Page 14 Cleaning the Mini Hand Turbo Tool WARNING! Ensure that the Mini Hand Turbo Tool is disconnected from the cleaner when performing any maintenance. To remove the clear cover, the collar must be unlocked by twisting anticlockwise as shown. To unlock the rotating bristles, push the lock button on the side of the turbo brush to the downward position.
- Page 15 Cleaning the Rotating Brush WARNING! Ensure that the cleaner is disconnected from the power supply and the Powerhead is disconnected from the rod before performing any maintenance. Note: The Rotating Brush must be free of debris for effective cleaning and for maximum suction. Disconnect the motorised Powerhead from the vacuum rod and turn it over to inspect the Rotating Brush.
- Page 16 Turn the Powerhead upside down and remove the small screw from the centre of the Powerhead. DO NOT OPEN Release the 4 clips from the underside, allowing you to remove the bottom plate. To remove the rotating brush, lift the right side of the brush first from the Powerhead, followed by the left side, where the belt loops around the end cap.
-
Page 17: Troubleshooting
Troubleshooting Problems and Solutions If you come across a problem, please use the checklist of troubleshooting tips before ringing Sauber Customer Service Australia on 1800 728 237 or New Zealand on 0800 282 288. Fault Solutions Check that the power cable is inserted securely; remove from the power The cleaner will not turn on. -
Page 18: Spare Parts
Spare Parts Part Part Number Dust Bin 33156372 Exhaust & Inlet Filter Set 32201752 31300822 Hose 31220964 Powerhead Brush Roller 33788159... - Page 19 Notes...
- Page 20 2 Years Warranty PRO PETS BAGLESS VACUUM Your cleaner, in the case of domestic use, has a two year (AUS) or 0800 282 288 (NZ), Monday-Friday 9am-5pm parts and labour warranty against product defects and EST. The decision to repair or replace the cleaner is at failures when the product is used in accordance with the the sole discretion of Electrical Home-Aids Pty.
