Bogen Power Vector V100 Specifications

Power Vector
Modular
Amplifiers
Models V35,V60,
V100,V150, and V250
Bogen's Power Vector modular amplifiers offer a wide range of power from which to choose from, with five
models ranging from 35W to 250W. The amplifiers are designed to work with both high- (70/25V) and low-
(4/8-ohm) impedance speaker systems.
Description
Each model includes eight module bays for plug-in input modules and allows up to four levels of priority
between modules. Two module bays are capable of accepting signal processing plug-in output modules. Each
module is controlled by an independent volume control with an associated signal/clip LED for signal status. An
11-segment LED output meter monitors output signal level.
Each model includes a motorized master volume control that can be controlled using a remote volume control
panel (RVCP, sold separately).
• 5 models ranging from 35W to 250W with a large
power reserve
Features
• Capable of handling 70V, 25V, 8-ohm, and 4-ohm
speaker loads
• 8 module bays
• Wide selection of advanced plug-in modules
• 2 module bays capable of handling signal processing
plug-in output modules
• 4 levels of priority between modules
• 11-segment LED output level meter monitors the
output level of the power amplifier with Peak and
Average meter switch
• Motorized master volume control that can be
remotely operated
• Bass and treble controls
• Two-color LED for each channel indicates input
active/clipping
• Lockable switch permits user to select either trans-
former-coupled outputs or a direct low-impedance
output
• 5-position barrier strip, with clamping washers, pro-
vides connections for speaker loads
• Master mute function overrides all audio from the
mixer section of the amplifier
• Screw terminal for master mute and remote volume
control functions
• Each of the 8 module bays has an associated inde-
pendent volume control
• Bass and treble control bypass switch (located in
module bay 6)
• 125 Hz Lo-cut feature (switch located in module
bay 6)
• Signal processing insert jacks allow external equip-
ment to be inserted between the pre-amp output
and the power amp input
• Pre-EQ unbalanced buffer output signal "post" all
unit controls, but "pre" any external signal process-
ing equipment connected
• Grounded, unswitched AC convenience receptacle
with a 500W maximum capacity provided for exter-
nal equipment
• Remote volume control panel (RVCP) (sold sepa-
rately)
• Security cover to protect volume, bass, and treble
controls (PVSC) (sold separately)
• Rack mountable (rack mounting kit RPK87 sold sep-
arately)
• 2 rack spaces high (3-1/2")
Specifications subject to change without notice.
© 2002 Bogen Communications, Inc.
Part No. 54-8013-01R2 elec Printed in U.S.A. 0210
