INSTRUCTIONS MANUAL
Advanced digital multimeter
C-LOGIC 5100
Code: 301000052
ENGLISH
The meter is a portable, hand-held yet professional meter that features an LCD, overload
protection and low battery indicator. This meter are easy to use with one hand, suitable for
professional users or amateurs, and ideal for school or home use.
The functions included are the measuring of AC/DC voltage, AC/DC current, resistance,
frequency, capacitance, temperature, continuity and diode test.
The meter is designed and manufactured according to safety requirements of EN/UL/CSA
61010-1, 61010-2-030, 61010-2-033 on electronic measuring instrument and hand held
digital multipurpose meter. The product meets with the requirements of 600V CAT III and
pollution degree 2.
All safety guidelines outlined should be followed. If the equipment is used in a manner not
specified by the manufacturer, the protection provided by the equipment may be impaired.
Advertencia
The special attention should be paid when using the meter because the improper usage
may cause electric shock and damage the meter .The safety measures in common safety
regulations and operating instruction should be complied with when using. In order to
make fully use of its functions and ensure safe operations please comply with the usage
in this section carefully.
INFORMACIÓN DE SEGURIDAD
• When using this meter, the user should comply with the following standard safety
procedures:
1) The safety procedures to prevent electric shock
2) The safety procedures to prevent wrong use
• To ensure your safety, please use the test probe provided with the meter.
• Before use, please check and make sure that it is intact.
SAFE WORKING HABITS
• If the meter is used near a source of significant electromagnetic interference, meter
readings will become unstable and have large errors.
• Don't use the meter or probe when it is broken.
• If you do not use the meter in accordance with the instructions, safety functions provided
by the meter may become invalid.
• Do not use the meter near explosive gas, vapor or dust.
• Measure known voltage with meter to verify that the meter is working properly. If the
meter is working abnormally, do not use. Protective equipment may be damaged. If there
is doubt, the meter should be sent to repair.
• The meter should be used with correct input, function and measuring range.
• When you can't determine the size range of signal to be tested, please switch the
measuring range to the maximum position.
• Input value can't exceed the input limit specified in each measuring range to prevent
damage to the meter.
• When the meter is connected to the circuit being measured, do not touch the unused
input end.
• When the voltage to be tested exceeds 60Vdc or 30Vac effective value, please operate
carefully to prevent electric shock.
• When use the test probe to measure, you should place your fingers at the back of
retaining ring.
• Before changing the measuring range, you must ensure that the test probe is not
connected to circuit to be tested.
• Before testing resistance, diode, capacitance measurement or on-off states, you should
first cut off power to the circuit being tested, and discharge all high voltage capacitors.
• Don't measure resistance or make on-off tests on a live circuit.
MAINTENANCE
• To open the meter shell or remove the battery cover, you should first pull out the test probe.
• Before opening the meter, you should be aware that there may be dangerous voltages
remaining in some capacitances in the meter even after powering off.
• If you find any abnormal phenomena on the meter, the meter should be immediately turned
off and repaired. Ensure that it can not be used before passing inspection.
• When the meter is not used for a long time, please remove the battery and avoid storing it
in a high temperature and humidity environment.
GENERAL MAINTENANCE
REPLACE BATTERY AND FUSE
Warning
To avoid electrical shock or personal injury, before opening the battery cover to replace
battery, you should turn the meter off and make sure that the test probe is disconnected
from the measurement circuit.
To avoid wrong readings, electric shock or personal injury, when
display, replace the battery immediately.
Use only a fuse with specified amperage, fusing rated value, voltage rated value and fusing
speed (F1:FF 400mA H 600V, F2:FF 10A H 600V)
Please follow below steps to replace battery or fuse:
• Turn off the power supply of the meter.
EN
• Pull out all test probes from the input socket.
• Loosen two screws on the fixed battery cover with screwdriver.
• Remove the battery cover.
• Remove the old battery or damaged fuse.
• Replace with a new battery with 9V (6F22) or a new fuse.
• Replace the battery cover and tighten the screws.
REPLACING TEST LEADS
If insulation on leads is damaged, replace it.
Advertencia
Use meet EN61010-031 standard, rated CAT.III 600V,10A or better test leads.
ACCESSORIES
• Test leads
• Short manual
• Battery 9V
• Multi-function socket
• K-type thermocouple
FULL MANUAL DOWNLOAD
appears on the meter
1 pair
1 pc
1 pc
1 pc
1 pc
You can download the complete
manual at the URL
http://www.c-logic.es/manuales
MANUFACTURER:
MGL EUMAN S.L.
Parque Empresarial de Argame,
C/ Picu Castiellu, Parcelas i-1 a i-4
E-33163 Argame, Morcin
Asturias, España (Spain)
