Gewiss Chorus Programming Manual

Thermo ice wi-fi (surface-mounting)
Hide thumbs Also See for Chorus:
Table of Contents

Advertisement

Quick Links

THERMO ICE WI-FI (SURFACE-MOUNTING)
GW16970CB
GW16970CN
GW16979CT
Programming manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Chorus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gewiss Chorus

Summary of Contents for Gewiss Chorus

  • Page 1 THERMO ICE WI-FI (SURFACE-MOUNTING) GW16970CB GW16970CN GW16979CT Programming manual...

  • Page 2: Table Of Contents

    Contents CONTENTS ..............................2 AIM OF THIS MANUAL ..........................5 TECHNICAL DATASHEET ..........................6 INSTALLATION REQUISITES: CORRECT POSITIONING ................ 7 COMMONLY USED TERMS .......................... 8 INSTALLING THE APP ON A MOBILE DEVICE ..................10 INSTALLING THE APP ON AN ANDROID DEVICE ....................10 INSTALLING THE APP ON AN IOS DEVICE ......................12 THE THERMOSTAT ............................14 CREATING AN ACCOUNT AND ASSOCIATING THE THERMO ICE WI-FI ...........17...
  • Page 3 ENABLING ACCESS TO BASIC AND ADVANCED PARAMETERS VIA THE APP ..........138 ............................139 21.1 ASIC PARAMETERS 21.2 ..........................140 DVANCED PARAMETERS ....................140 21.2.1 NDEX OF THE ADVANCED PARAMETERS 21.2.2 P1 ......................... 141 DVANCED PARAMETER CHORUS | T | page 3 HERMO...
  • Page 4 P2 ......................... 141 21.2.3 DVANCED PARAMETER 21.2.4 P3 ......................... 141 DVANCED PARAMETER P4 ......................... 141 21.2.5 DVANCED PARAMETER 21.2.6 P5 ......................... 142 DVANCED PARAMETER P6 ......................... 142 21.2.7 DVANCED PARAMETER 21.2.8 P7 ......................... 142 DVANCED PARAMETER P8 ......................... 142 21.2.9 DVANCED PARAMETER 21.2.10 P10 ......................

  • Page 5: Aim Of This Manual

    All the information concerning the technical data of the product, the connection diagrams, the descriptions of the commands and the instructions for correct assembly is contained in the installation manual supplied with the product and which can also be downloaded from the website www.gewiss.com. CHORUS | T...

  • Page 6: Technical Datasheet

    Technical datasheet Power supply: 110V AC ÷ 230V AC, 50/60 Hz Power supply absorption: < 3W (in standby < 1W) Command elements: 3 touch commands, 1 circular touch slider Inputs: 1 input for an external temperature sensor (type NTC 10K, e.g. GW 10 800) 2 relays with NO potential-free contact.

  • Page 7: Installation Requisites: Correct Positioning

    If necessary, the temperature measurement can be corrected using the advanced parameter P2 (with a range of ±5°C). The parameter can be regulated both via the app and locally, as explained in 20.2.3. CHORUS | T | page 7 HERMO...

  • Page 8: Commonly Used Terms

    Commonly used terms A user with limited access to the app functions. The limits are set by the Administrator Base User: user, via the app itself HVAC: Heating / Ventilation / Air-Conditioning MAC address: Media Access Control address: a unique network identification address Local: An action implemented directly on the thermostat Remote:...
  • Page 9 NSTALLING THE APP CHORUS | T | page 9 HERMO...

  • Page 10: Installing The App On A Mobile Device

    Installing the app on a mobile device The GW16970CB/CN/CT device is a thermostat for managing the temperature and, if necessary, the humidity, in the room where it is installed. The GW16970CB/CN/CT - THERMO ICE Wi-Fi (surface-mounting) completes the range of touch temperature adjustment for traditional, non-KNX systems; it acts directly on the relays in the device, without interacting with the other devices installed in the system.
  • Page 11  Click on the “Thermo Ice 2.0” icon  Click on the “Install” button CHORUS | T | page 11 HERMO...

  • Page 12: Installing The App On An Ios Device

    INSTALLING THE APP ON AN IOS DEVICE  Find the “App Store” application on the chosen mobile device  Open App Store and enter “Thermo ICE 2.0” in the internal search engine  When you have found the app, install it page 12 | T | PROGRAMMING MANUAL HERMO...
  • Page 13 HE THERMOSTAT CHORUS | T | page 13 HERMO...

  • Page 14: The Thermostat

    The thermostat The device is made up of two main elements: a base, fixed to the wall or to a 3-gang rectangular box, and a front part coupled with the base and attached to it by means of a screw. It is a LED backlit touch device.
  • Page 15 1. Pre-comfort mode active Operating 1. Comfort mode active mode 1. Automatic (hourly profile) mode active  Manual mode active  Temporary setpoint forcing active Type of 1. Heating operation Type of 1. Cooling operation CHORUS | T | page 15 HERMO...
  • Page 16 REATING A NEW ACCOUNT AND ASSOCIATING THE THERMOSTAT WITH THE APP page 16 | T | PROGRAMMING MANUAL HERMO...

  • Page 17: Creating An Account And Associating The Thermo Ice Wi-Fi

    Creating a new account on the app After wiring the thermostat and fixing it to the wall, as explained in the installation manual supplied with the device (also available at www.gewiss.com), access the app (Thermo ICE 2.0) that enables the remote control of the thermostat.
  • Page 18  Scroll down the page, giving consent where necessary, then click on the tick  Open the e-mail address you indicated during the registration phase  Check the incoming post. There should be an e-mail confirming the registration (if there isn't, check the “Spam”...

  • Page 19: Associating The Thermo Ice Wi-Fi

     1  2  3 P 21 UMMARY OF VALUES FOR PARAMETER No configuration Configuration via Wi-Fi Configuration via ESP Touch Configuration via WPS Select the value corresponding to the required configuration mode. CHORUS | T | page 19 HERMO...

  • Page 20: Wi-Fi Configuration

    WI-FI CONFIGURATION ANDROID PROCEDURE: 1. Open the Thermo Ice app 2. Click on the “+” button 3. The “Thermo ICE search” page will open. Click on “Configure new Thermo ICE” 4. A drop-down menu allows you to choose one of the three possible configuration modes. Select “Wi-Fi configuration”...
  • Page 21 Wi-Fi network generated by the thermostat (“25” in the example below) 13. The “Wi-Fi. New Thermo ICE configuration” page will open on the app 14. Select the Wi-Fi network that the thermostat must connect to CHORUS | T | page 21 HERMO...
  • Page 22 15. You will now see a new page, that needs to be filled in 16. Enter the password to access the selected Wi-Fi network 17. The default code is WPA/WPA2 18. Now click on the tick NAME OF THE WI-FI NETWORK SELECTED PASSWORD OF THE...
  • Page 23 Internet connection or repeat the configuration 25. The app returns to the “Thermo ICE search” page, showing the newly configured thermostat CHORUS | T | page 23 HERMO...
  • Page 24 26. Click on the name of the newly configured thermostat. A new page will open 27. This page shows the systems available. Click on the name of the system that you want to associate the thermostat with. If no system has yet been created, click on “Create new system”;...
  • Page 25 15 seconds. The key will turn green 8. The screen will show “P 1”, which stands for “Advanced parameter 1”. This is the procedure for accessing the advanced thermostat parameters CHORUS | T | page 25 HERMO...
  • Page 26 button key, or the circular slider, to find parameter “P 21” 9. Use the Next 10. Use the Mode button key to access the parameter P21 menu 11. Select the value 1 using the Next button key or the circular slider. Confirm with the Mode button key 12.
  • Page 27 (identified by the name “GWTHERMOICEX_YYXX) 20. Quit the “Settings” page and return to the app 21. An info message will appear, telling you that the configuration has been successfully completed. Click on “OK” CHORUS | T | page 27 HERMO...
  • Page 28 22. Once the association has been completed, the thermostat display will show the word “donE” 23. The thermostat display quits the advanced parameters area and returns to the initial page 24. The app returns to the “Thermo ICE search” page, showing the newly configured thermostat 25.

  • Page 29: Esp Touch Configuration

    4. The “Thermo ICE search” page will open. Click on “Configure new Thermo ICE” 5. A drop-down menu allows you to choose one of the three possible configuration modes. Select “ESP Touch configuration” CHORUS | T | page 29 HERMO...
  • Page 30 6. An info message will appear on the screen. Click on OK 7. You will now see a page showing the name of the Wi-Fi network that Thermo ICE will connect to (the same one that your smartphone is already connected to); enter the network access password in the relative field page 30 | T | PROGRAMMING MANUAL...
  • Page 31 17. When the procedure has ended, the word “donE” will appear on the thermostat display. The thermostat quits the advanced parameters area 18. A message will appear on the app to tell you that the configuration has been successfully completed CHORUS | T | page 31 HERMO...
  • Page 32 19. The app returns to the “Thermo ICE search” page, showing the newly configured thermostat 20. Click on the thermostat to assign it a name. A new page will open. Enter the name you want to give the thermostat in the relative field page 32 | T | PROGRAMMING MANUAL HERMO...
  • Page 33 1. Connect your smartphone to the domestic Wi-Fi network that Thermo ICE must connect to 2. Open the Thermo Ice app 3. Click on the “+” button 4. The “Thermo ICE search” page will open. Click on “Configure new Thermo ICE” CHORUS | T | page 33 HERMO...
  • Page 34 5. A drop-down menu allows you to choose one of the three possible configuration modes. Select “ESP Touch configuration” 6. An info message will appear on the screen. Click on OK page 34 | T | PROGRAMMING MANUAL HERMO...
  • Page 35 15. The message “ESPt” will appear on the screen, and the connection power symbol will begin flashing 16. On the app, press the tick to launch the configuration. Wait for the configuration procedure to terminate CHORUS | T | page 35 HERMO...
  • Page 36 17. When the procedure has ended, the word “donE” will appear on the thermostat display. The thermostat display quits the advanced parameters area and returns to the initial page 18. The app returns to the “Thermo ICE search” page, where you can see the newly configured thermostat 19.

  • Page 37: Wps Configuration

    2. Click on the “+” button 3. The “Thermo ICE search” page will open. Click on “Configure new Thermo ICE” 4. A drop-down menu allows you to choose one of the three possible configuration modes. Select “WPS configuration” CHORUS | T | page 37 HERMO...
  • Page 38 5. An info message will appear on the screen. Click on OK 12. Activate the thermostat 13. Keep the Set button key pressed for at least 15 seconds. The key will turn green 14. The screen will show “P 1”, which stands for “Advanced parameter 1”. This is the procedure for accessing the advanced thermostat parameters button key, or the circular slider, to find parameter “P 21”...
  • Page 39 25. Select the system that you want to associate the newly configured thermostat with 26. The app returns to the “Thermo ICE search” page, showing the name of the new thermostat 27. The configuration procedure is now complete CHORUS | T | page 39 HERMO...

  • Page 40: Main Page Of The App, And Standard Remote Commands

    Main page of the app, and standard remote commands Once the app has been installed and associated with the thermostat, this is the homepage that the user sees when the app is opened: UNCTION Indicator of the room temperature measured Indicator of the setpoint defined Indicator of the humidity percentage measured by the thermostat Indicator of the type of operation selected: Heating/Cooling...
  • Page 41 ASIC GUIDE TO USING THE THERMOSTAT AND THE APP CHORUS | T | page 41 HERMO...

  • Page 42: Basic Guide

    10 Basic guide Once the app has been installed and associated with the thermostat, you can command the thermostat itself both locally and from a distance. 10.1 Thermostat operating mode The thermostat has six different operating modes: OMFORT Pre-defined setpoint; the OMFORT setpoint can be temporarily CONOMY...

  • Page 43: Manual Temperature Regulation: Temporary Forcing

    Stand-Alone control offers unlimited access to the thermostat and the advanced parameters, whereas with Slave type control the commands are only local and there is no access to the advanced parameters. More specifically: CHORUS | T | page 43 HERMO...

  • Page 44: Switching From Heating To Cooling And Vice Versa

    LOCAL COMMAND (THERMOSTAT) TAND LONE LAVE The possibility to select all six thermostat The choice of operating mode is limited to the operating modes (Comfort/Pre- predefined one, or OFF Comfort/Economy/Auto/Manual/OFF) Unlimited access to the advanced parameters (if No access to the parameters consent has been given via the app) Unlimited temporary forcing of the temperature Limited temporary forcing of the temperature...
  • Page 45  Open the app on your mobile device  Use the button key  A drop-down menu will appear. The first item is the alternative mode to the one active in that moment  Click on “Switch to [heating/cooling]” CHORUS | T | page 45 HERMO...
  • Page 46  Open the app on your mobile device  Click on . The “Settings” page will open. AUTOMATIC  Scroll down the page until you find the item “Advanced settings”. Click on “Advanced settings”  A new page will open. Click on “Temperature control” page 46 | T | PROGRAMMING MANUAL HERMO...
  • Page 47 The item on the left contains the days of the month, whereas the one on the right shows the months of the year. Select the required days/months to define when Heating or Cooling operation will be active CHORUS | T | page 47 HERMO...
  • Page 48 For a more detailed explanation of the various commands and functions, read the following chapters. page 48 | T | PROGRAMMING MANUAL HERMO...
  • Page 49 TRUCTURE ORGANISATION AND LOGIC CHORUS | T | page 49 HERMO...

  • Page 50: Structure And Operation

    11 Structure and operation When using and setting the thermostat, it's necessary to choose a series of operating types and modes, along with the role of the various users who can access it. The settings defined will affect how the user interacts with the thermostat, and the functions made available to him/her.

  • Page 51: Type Of Control

     The device can receive commands via the app access the parameter modification section. from both Administrators and Base Users, but whereas the former have no limits, the latter have same limits local implementation (only thermostat switch-off limited setpoint regulation). CHORUS | T | page 51 HERMO...

  • Page 52: Where To Set The "Type Of Control " In The App

     Only Administrators can alter the parameters.  Access to the temperature adjustment profiles is permitted for Administrators in read/write mode, but is not permitted for Base Users.  Limit-free humidity management is available to Administrators, whereas Base Users cannot access the parameter modification section.
  • Page 53  You will now see a page where you can choose whether to set the thermostat in “Standalone” or “Slave” mode CHORUS | T | page 53 HERMO...

  • Page 54: Type Of User

    11.2 Type of user Two different types of user can be set:  Administrator  Base User Each type has a different command scope and functions. In general, the Administrator has full access to all the thermostat functions and regulations via the app. In addition, he/she has the power to register new users and define which role to assign to them (new Administrator or new Base User).
  • Page 55  In the menu that appears, select “Invite a new user”. The “Invite a new user” page will open. Enter the e-mail address of the user you are inviting in the relative space CHORUS | T | page 55 HERMO...
  • Page 56  After entering the e-mail, you can decide whether to make this user a Base User or an Administrator  The user will receive an e-mail at the address indicated, as notice of the procedure; if he/she is not already registered, this must be done before accessing the app ...

  • Page 57: Type Of Operation

    1. Open the app on your mobile device command. The “Settings” page will open. Scroll down the page until 2. Click on the you find the item “Advanced settings” 3. Click on “Advanced settings”. The “Advanced settings” page will open CHORUS | T | page 57 HERMO...

  • Page 58: Where To Set The Temperature Adjustment Control Logic Locally

    4. Find the “Temperature control logic” item; click on it to open a drop-down menu containing four items:  Heating only  Cooling only  2 pipes on relay 1  4 pipes on relays 1 and 2 The thermostat must be set on one of the last two items: WHERE TO SET THE TEMPERATURE ADJUSTMENT CONTROL LOGIC LOCALLY (In order to set the control logic locally, advanced parameter access must be enabled via the app and the thermostat must be set as Stand-Alone.)

  • Page 59: In The App

    A drop-down menu will appear. The first item is the alternative mode to the one active in that moment  Click on “Switch to cooling” / “Switch to heating” if you want to change the type of thermostat operation CHORUS | T | page 59 HERMO...
  • Page 60 page 60 | T | PROGRAMMING MANUAL HERMO...

  • Page 61: Set The Dates For Automatic Heating /Cooling Switchover Via The App

    . The “Settings” page will open Click on  Scroll down the page until you find the item “Advanced settings”. Click on “Advanced settings”  A new page will open. Click on “Temperature control” CHORUS | T | page 61 HERMO...
  • Page 62  On the page that opens, make sure the “Automatic switch” option is activated (the button key must be in the “ON” position). You can now set the dates for switching from type of operation to the other  Click on “Start Heating” and “Start Cooling” to open a drop-down window with a calendar. The item on the left contains the days of the month, whereas the one on the right shows the months of the year.
  • Page 63 CHORUS | T | page 63 HERMO...

  • Page 64: Operating Modes

    11.4 Operating modes The thermostat has six different operating modes: OMFORT Pre-defined setpoint; the OMFORT setpoint can be temporarily CONOMY forced UTOMATIC The setpoint cannot be forced Free setpoint ANUAL Each mode has different operating parameters and functions. mode is used when there are people in the room where the thermostat is installed. It is OMFORT therefore the one that offers the most comfortable temperature levels possible: in Heating, the highest temperature of all those envisaged in the five operating modes with a predefined setpoint, and in Cooling...
  • Page 65  After choosing the required operating mode, click on the tick . A drop- down menu will appear, where you can set the time interval within which the chosen mode will be used CHORUS | T | page 65 HERMO...
  • Page 66  This tool allows you to enter up to 8 different intervals for each day of the week  Use the pencil to alter or remove an unwanted interval Days of the week  To copy the hourly programming of one day of the week onto another day, select icon in the lower bar and then the Copy day item;...
  • Page 67 (required temperature) as he/she prefers. This regulation can be made either locally (using the circular slider) or via the app (using the relative command on the homepage). In M mode, the setpoint can only be regulated within a precise temperature range: ANUAL CHORUS | T | page 67 HERMO...

  • Page 68: Setting The Operating Modes Locally

    Operating mode: Manual 10°C ≤ ≤ 35°C manual HEATING/ COOLING and it must respect these rules: Operating mode: M ANUAL ≤ T building protection operation HEATING ≤ T operation building protection COOLING In heating mode, the setpoint cannot be lowered as far as the setpoint defined to protect the building from low temperatures (T ).

  • Page 69: Where To Select The Operating Mode In The App

     Open the app on your mobile device  The homepage contains a list of the operating modes that can be selected  Click on the icon corresponding to the required operating mode CHORUS | T | page 69 HERMO...
  • Page 70 UTOMATIC MODE ANUAL MODE OMFORT MODE page 70 | T | PROGRAMMING MANUAL HERMO...
  • Page 71 COMFORT MODE CONOMY MODE MODE CHORUS | T | page 71 HERMO...

  • Page 72: How To Change The Setpoint Regulation Interval For Manual , Economy , Pre -Comfort And Comfort Modes With Slave Control

    11.4.3 H OW TO CHANGE THE SETPOINT REGULATION INTERVAL FOR ANUAL CONOMY OMFORT AND OMFORT MODES WITH LAVE CONTROL The Administrator can use the app to alter the setpoint regulation interval for the ECONOMY (temporary setpoint forcing) and operating modes when the thermostat is COMFORT COMFORT MANUAL...

  • Page 73: Regulation Of The Hvac Mode Setpoints Via App

    MODE SETPOINTS VIA APP A different setpoint is associated with the and OFF operating modes. COMFORT COMFORT ECONOMY The Administrator can regulate them as he/she prefers, but respecting some general rules that govern these regulations CHORUS | T | page 73 HERMO...
  • Page 74 In particular: Operating mode: Comfort/Pre-comfort/Economy/OFF ≤ T ≤ T ≤ T HEATING anti-freeze economy pre-comfort comfort ≤ T ≤ T ≤ T comfort pre-comfort economy high temperature COOLING protection Operating mode: Comfort/Pre-comfort/Economy ≤ T ≤ T ≤ T ≤ 10°C 35°C HEATING economy...
  • Page 75 (within the permitted interval) the setpoint for each operating mode and protection threshold. EATING FREEZE EATING CONOMY EATING OMFORT EATING OMFORT OOLING CONOMY OOLING OMFORT CHORUS | T | page 75 HERMO...

  • Page 76: Ocal Regulation Of The Omfort Re Omfort And Conomy Mode Setpoints

    OOLING OMFORT OOLING IGH TEMPERATURE PROTECTION Note that an interval is associated with each setpoint (e.g. ). This indicates the temperature range within which the setpoint can be regulated. The interval start and end points are determined by the need to respect the hierarchical order mentioned previously. 11.4.5 L OCAL REGULATION OF THE OMFORT...

  • Page 77: Local Regulation Of The Building Protection Setpoints

    Cooling 35°C << 40°C 95°F << 104°F  After defining the required value for the setpoint, confirm by pressing the Mode button key  Click on Set to quit the advanced parameters area CHORUS | T | page 77 HERMO...

  • Page 78: Control Algorithms

    11.5 Control algorithms The thermostat can regulate its own operation (and, consequently, system management) on the basis of two different control algorithms stored inside it. These algorithms are:  2 points ON-OFF  Proportional-integral with PWM control CONTROL ALGORITHM SUMMARY OF THE CHARACTERISTICS This type of control involves the turning on and off of the temperature adjustment system following a hysteresis cycle.

  • Page 79: Where To Set The Control Algorithm On The App

    The “Temperature control” page will open. In the “Temperature control algorithms” section, for each operating type (Heating or Cooling) you can choose which of the two algorithms should be used (Two points ON-OFF or Proportional integral PWM) CHORUS | T | page 79 HERMO...
  • Page 80 page 80 | T | PROGRAMMING MANUAL HERMO...
  • Page 81 EOFENCING CHORUS | T | page 81 HERMO...

  • Page 82: Automatic Presence Detection - Geofencing

    12 Automatic presence detection - Geofencing The app allows the user to activate the geofencing function. This function influences the behaviour of the thermostat on the basis of the user's position, programming automatic actions when he/she enters or leaves the home. A perimeter is defined around the home, and used by the device to understand when the user is at home or in the immediate vicinity, and when he/she is "outside";...

  • Page 83: Enabling Geofencing Via The App

    Open the app on your mobile device  Select the button key  The “Settings” page will open. Scroll down the page until you find the item “Advanced settings”  Select “Advanced settings”. The “Advanced settings” page will open CHORUS | T | page 83 HERMO...
  • Page 84  Scroll down the “Advanced settings” page until you find the item “Geofencing”  Select “Geofencing settings”. The “Geofencing” page will open  Under the item “Activation”, you can choose from three different options:  Disabled  Administrators only (Administrator) ...

  • Page 85: Activating Geofencing On Your Account

    Open the app on your mobile device  Select the button key  The “Settings” page will open. Scroll down the page until you find the item “Advanced settings”  Select “Advanced settings”. The “Advanced settings” page will open CHORUS | T | page 85 HERMO...
  • Page 86  Scroll down the “Advanced settings” page until you find the item “Geofencing settings”  Select “Geofencing settings”. The “Geofencing” page will open page 86 | T | PROGRAMMING MANUAL HERMO...

  • Page 87: Setting The Actions For Entering And Leaving The Geofencing Area

    To set the action when the user enters or leaves the geofencing area, proceed as follows:  Open the app on your mobile device  Click on  The “Settings” page will open. Scroll down the page until you find the item “Advanced settings”. Select this item CHORUS | T | page 87 HERMO...
  • Page 88  Scroll down the “Advanced settings” page until you find the item “Geofencing settings”  Select “Geofencing settings”. The “Geofencing” page will open  Under the item “Activation”, you will find two different commands:  “Action on arriving at home” ...

  • Page 89: Setting The Geofencing Area Radius

    In the same way, if the geofencing area is wider, the operating mode set for when entering the area will be activated much CHORUS | T | page 89...
  • Page 90 sooner than the physical entry of the user in the home; if the area is narrower, the operating mode will be activated later. The geofencing area can be altered within an interval from min. 100 metres to max. 3000 metres. To set the extension of the geofencing area, proceed as follows: ...
  • Page 91  After defining the required extension of the geofencing area, click on the tick CHORUS | T | page 91 HERMO...
  • Page 92 UMIDITY page 92 | T | PROGRAMMING MANUAL HERMO...

  • Page 93: Humidity

    SET THE "TEMPERATURE ADJUSTMENT CONTROL LOGIC" VIA THE APP  Open the app on your mobile device  Click on  The “Settings” page will open. Scroll down the page until you find the item “Advanced settings”. Select this item CHORUS | T | page 93 HERMO...
  • Page 94  The “Advanced settings” page will open  Under the item “Temperature control logic”, you can choose which configuration to use the relays in. There are four possibilities:  Heating only  Cooling only  2 pipes on relay 1 ...

  • Page 95: Setting Humidity Control Via The App

    The “Settings” page will open. Scroll down the page until you find the item “Advanced settings”. Select this item  The “Advanced settings” page will open  Under the item “Controls”, select “Humidity control” CHORUS | T | page 95 HERMO...
  • Page 96  The “Humidity control” page will open. Under the item “Humidity control” there are three items:  Off  Humidity increase  Humidity reduction Select one of the last two items to gain access to the advanced humidity parameters This advanced parameter can only be accessed if the thermostat is set as Stand-Alone and the advanced parameters have been enabled via the app Advanced parameter P11 offers three different values, as shown below: UMMARY OF VALUES FOR PARAMETER...

  • Page 97: How To Regulate The Advanced Humidity Parameters Locally

    13.2 Regulating the “Correction factor for the internal humidity sensor” via the app  Open the app on your mobile device  Click on  The “Settings” page will open. Scroll down the page until you find the item “Advanced settings”. Select this item CHORUS | T | page 97 HERMO...
  • Page 98  The “Advanced settings” page will open  Under the item “Controls”, select “Humidity control”  Under the item “Other”, you will find “Humidity sensor – Correction factor”. Select this item to see a drop-down menu showing the possible correction values. The interval ranges from -10% to +10% page 98 | T | PROGRAMMING MANUAL...

  • Page 99: Local Activation/Deactivation Of Humidification/Dehumidification

    Select value 1 or value 2 to make the basic parameters “Humidity threshold” and “Humidity threshold hysteresis” accessible  Select the required value, then confirm your choice with Mode  Click on Set to quit the advanced parameters area CHORUS | T | page 99 HERMO...

  • Page 100: Activating/Deactivating Humidification/Dehumidification Via The App

    13.4 Activating/deactivating humidification/dehumidification via the app See “Setting humidity control via the app”. 13.5 Local regulation of the humidity threshold If advanced parameter P11 has been set with a value of 1 or 2, the user can access the basic parameters “Humidity threshold”...
  • Page 101 Under the item “Controls”, select “Humidity control”  The “Humidity control” page will open. Under the item “Humidity control” you will find the option “Humidity threshold”, with the currently set value on the right CHORUS | T | page 101 HERMO...

  • Page 102: Local Regulation Of The Humidity Threshold Hysteresis

     Select the pencil on the right-hand side of the option to open a drop-down menu where you can regulate the humidity threshold. You can enter a value within an interval from 20% to 80%. The scale is in 5% steps (i.e. not continuous) 13.7 Local regulation of the humidity threshold hysteresis If advanced parameter P11 has been set with a value of 1 or 2, the user can access the basic parameters “Humidity threshold”...

  • Page 103: Regulating The Humidity Hysteresis Via The App

    “Humidity threshold” and “Humidity threshold hysteresis”.  Open the app on your mobile device  Click on  The “Settings” page will open. Scroll down the page until you find the item “Advanced settings”. Select this item CHORUS | T | page 103 HERMO...
  • Page 104  The “Advanced settings” page will open  Under the item “Controls”, select “Humidity control”  The “Humidity control” page will open. Under the item “Humidity control” you will find the option “Humidity threshold hysteresis”  On the right-hand side of this item, you can see the hysteresis value currently active. Next to it, there is a pencil .
  • Page 105 UXILIARY TEMPERATURE SENSOR CHORUS | T | page 105 HERMO...

  • Page 106: External Temperature Sensor

    14 External temperature sensor The device is fitted with an input contact for connecting an NTC external temperature sensor. Parameter P18: Enabling of auxiliary input for temperature sensor is used to configure the input of the auxiliary sensor so that a wired NTC temperature sensor (GW10800) or a flush-mounting one (GW1x900) can be connected to measure the room temperature or the floor-level temperature.

  • Page 107: Enabling The Auxiliary Input Via The App

    . The “Settings” page will open. Scroll down the page until you find the item Click on “Advanced settings”  Click on “Advanced settings”. The “Advanced settings” page will open  Scroll down the “Advanced settings” page until you find the item “Temperature control” CHORUS | T | page 107 HERMO...
  • Page 108  Click on “Temperature control” to open the relative page  Under the item “Auxiliary input” you will find a window showing the current setting for the auxiliary input. Click on it to open a drop-down menu showing the four possible configurations: UXILIARY INPUT Disabled Room temperature measurement with GW1x900...

  • Page 109: Local Regulation Of The Incidence Of The Auxiliary Sensor (P19)

    Open the app on your mobile device  . The “Settings” page will open. Scroll down the page until you find the item Click on “Advanced settings”  Click on “Advanced settings”. The “Advanced settings” page will open CHORUS | T | page 109 HERMO...
  • Page 110  Scroll down the “Advanced settings” page until you find the item “Temperature control”  Click on “Temperature control” to open the relative page  Under the item “Auxiliary input”, if the Room temperature GW1x900” or “Room temperature GW10800” option is selected, beneath the relative window you will find the item: “Incidence of the external temperature sensor in the measured temperature calculation”, with the corresponding value shown on the right page 110 | T...

  • Page 111: Local Regulation Of The Floor Temperature Alarm Threshold (P20)

    In addition, advanced parameter P18 must be set on “Measure floor temperature with GW10800” – see ch. 14.1 and 14.2 Used to modify (using the CIRCULAR slider) the max. temperature value beyond which the floor temperature alarm is triggered. CHORUS | T | page 111 HERMO...

  • Page 112: Regulating The Floor Temperature Alarm Threshold Via The App

    Proceed as follows:  Activate the backlighting of the thermostat  Use the Next button key to select the page showing the temperature  Press and hold the Set button key until the code P1 appears on the screen  Use the circular slider or the Next button key to find advanced parameter P20 ...
  • Page 113 Under the item “Auxiliary input”, if the “Floor temperature measurement with GW10800” option is selected, underneath you will find the item: “Floor alarm threshold temperature”, with the corresponding value shown on the right CHORUS | T | page 113 HERMO...
  • Page 114  Click on the pencil to see a drop-down menu where you can regulate the floor temperature alarm threshold. The value can be selected within an interval from 15°C to 100°C  When you quit the settings area, you will be asked whether you want to save the changes made. Click on “Yes”...
  • Page 115 ISPLAY REGULATION  Lighting intensity  Proximity sensor activation/deactivation  Standby activation/deactivation  Audio activation/deactivation  Time regulation  Day regulation CHORUS | T | page 115 HERMO...

  • Page 116: Backlighting, Proximity Sensor, Standby

    15 Backlighting, proximity sensor, standby The thermostat screen is backlit, and the colour of the commands and circular slider can change according to the type of operation (Heating/Cooling), type of control (Stand-Alone/Slave) and type of function (single or long touch on the command). OLOURS OF THE COMMAND BUTTON KEYS Single touch Long touch –...
  • Page 117  Apart from the item “Measurement unit”, there is also:  Display  Standby  Audio CHORUS | T | page 117 HERMO...

  • Page 118: Regulating The Lighting Intensity Of The Screen

    15.2 Regulating the lighting intensity of the screen  Under the item “Display”, you will find “backlighting intensity %”  Press on this item to open a drop-down menu where you can regulate the intensity of the backlighting (interval permitted: 30 – 100%) 15.2.1 P ROXIMITY SENSOR ACTIVATION DEACTIVATION...

  • Page 119: Standby Activation / Deactivation

    On the “Display and audio settings” page, underneath the “Audio” item, there is a command for activating and deactivating the audio signal associated with pressing of the commands on the thermostat screen  Press “ON” to activate the audio signal, or “OFF” to deactivate it CHORUS | T | page 119 HERMO...

  • Page 120: Setting The Thermostat Display Locally

    15.3 Setting the thermostat display locally You can regulate the lighting intensity, and activate/deactivate the proximity sensor, standby and audio signal locally if the thermostat status is Stand-Alone and access to the advanced parameters has been enabled via the app by the Administrator. 15.3.1 R EGULATING THE LIGHTING INTENSITY OF THE SCREEN ...

  • Page 121: Tandby Activation Deactivation

    Press a point on the left-hand side of the circular slider and hold it for 3 seconds  The word “ON” or “OFF” will appear on the screen, depending on whether standby was already enabled or not CHORUS | T | page 121 HERMO...

  • Page 122: Udio Activation Deactivation

    15.3.4 A UDIO ACTIVATION DEACTIVATION  Activate the backlighting of the thermostat  Select the thermostat page showing the temperature  Press and hold the Set button key until the code P1 appears on the screen  Using the circular slider or the Next button key , scroll through the advanced parameters until you find parameter P16 ...

  • Page 123: Regulating The Time Shown On The Thermostat

    When you have reached the “Day” page, this word will appear on the screen  Press Mode to access the menu where you can change the day of the week CHORUS | T | page 123 HERMO...
  • Page 124  There are seven possible values, each representing a day of the week: UMMARY OF THE VALUES REPRESENTING THE DAYS OF THE WEEK Sunday Monday Tuesday Wednesday Thursday Friday Saturday  Use the circular slider or the Next button key to select the value corresponding to the current day ...
  • Page 125 SAGE STATISTICS CHORUS | T | page 125 HERMO...

  • Page 126: Usage Statistics

    16 Usage statistics The Thermo Ice WiFi app allows you to graphically view the temperature and humidity levels and the percentage of system activation in heating/cooling over time, as registered on the cloud. This function offers you immediate visual feedback about the behaviour of the thermostat. To view the usage statistics, carry out the following steps: 1.
  • Page 127 The values on each of these axes use the same colour as the curve that they refer to. Below the x-axis, you can select the type of time period you want to see. The possible options are:  Yearly  Monthly  Weekly  Daily CHORUS | T | page 127 HERMO...
  • Page 128 On the line at the bottom of the page, you can choose the day, week, month or year that you want to see. Use the two arrows on the right and left to move to the day, week, month or year before/after the one shown in that moment.
  • Page 129 Press and hold on a certain point of the chart to see the exact values registered in that point. CHORUS | T | page 129 HERMO...
  • Page 130 AINTENANCE page 130 | T | PROGRAMMING MANUAL HERMO...

  • Page 131: Maintenance

    A 30-second countdown will begin on the screen. The user can clean the plate within this time without accidentally activating the commands.  Disabling: At the end of the countdown, the thermostat will return to its normal operation with the commands once again enabled. CHORUS | T | page 131 HERMO...
  • Page 132 ELETING A SYSTEM EMOVING USERS page 132 | T | PROGRAMMING MANUAL HERMO...

  • Page 133: Deleting A System

    If the selected user is an Administrators, there will be two possible options:  Remove Administrator privileges  Delete “User name” Selecting the second option, the user will be removed from the list CHORUS | T | page 133 HERMO...
  • Page 134 page 134 | T | PROGRAMMING MANUAL HERMO...
  • Page 135 ESETTING THE FACTORY CONDITIONS CHORUS | T | page 135 HERMO...

  • Page 136: Resetting The Factory Conditions

    20 Resetting the factory conditions If you need to reset the thermostat with its original factory conditions, proceed as follows:  Press the Next button key for 10 seconds  The screen will show a numerical value indicating the firmware version installed on the thermostat ...
  • Page 137 ARAMETERS BASIC AND ADVANCED CHORUS | T | page 137 HERMO...

  • Page 138: Parameters: Basic And Advanced

    21 Parameters: basic and advanced Thermostat operation is governed by a series of parameters that can be activated/deactivated and regulated by the user. Depending on the settings defined via the app, these parameters may be enabled or disabled, enabled for Administrators only, accessible or not accessible locally. Local access to the basic and advanced parameters must be enabled by an Administrator via the app.

  • Page 139: Basic Parameters

    The basic parameters can be sub-divided as follows: HERMOSTAT PAGE TEMPERATURE ASIC PARAMETERS SETPOINT TYPE OF OPERATION Heating Cooling OMFORT OMFORT (Heat mode) (Cool mode) CONOMY CHORUS | T | page 139 HERMO...

  • Page 140: Advanced Parameters

    HERMOSTAT PAGE HUMIDITY ASIC PARAMETERS Humidity threshold Hysteresis HERMOSTAT PAGE CLOCK ASIC PARAMETERS Hour Minutes From the temperature page, you can therefore define the setpoints for the C OMFORT OMFORT operating modes. You can also decide whether the thermostat should be used in Heating or CONOMY Cooling mode (see 11.1.4.5.).

  • Page 141: Advanced Parameter P1

    This parameter is used to define which algorithm must be used by the thermostat for the type of operation currently active. Depending on the algorithm chosen, advanced parameters P5, P6, P7 and P8 will be enabled (see below). UMMARY OF VALUES FOR PARAMETER 2 points ON-OFF PWM proportional-integral CHORUS | T | page 141 HERMO...

  • Page 142: Advanced Parameter P5

    UMMARY OF VALUES FOR PARAMETER 2 points ON-OFF PWM proportional-integral 21.2.6 A DVANCED PARAMETER This parameter is used to alter the value of the regulation differential for the 2-point control algorithm of the type of operation active (H or C). It is visible if the current value of advanced parameter P4 is “2 points ON-OFF”...

  • Page 143: Dvanced Parameter P10

    This parameter is used to alter the activation of the alternated visualisation of the thermostat, humidity and clock pages on the display when the device is in standby. It's visible if the value of advanced parameter P14 is “ON”. UMMARY OF VALUES FOR PARAMETER Deactivated Activated CHORUS | T | page 143 HERMO...

  • Page 144: Advanced Parameter P16

    21.2.16 A DVANCED PARAMETER This parameter is used to enable or disable the audio signal that accompanies the pressing of button keys. UMMARY OF VALUES FOR PARAMETER Disabled Enabled 21.2.17 A DVANCED PARAMETER This parameter is used to enable the proximity sensor on the device. If enabled, the backlighting comes on when the sensor detects that someone is near the device;...

  • Page 145: Advanced Parameter P22

    21.2.22 A DVANCED PARAMETER This parameter is used to activate or deactivate the radio module (Wi-Fi). UMMARY OF VALUES FOR PARAMETER Disabled Enabled CHORUS | T | page 145 HERMO...
  • Page 146 page 146 | T | PROGRAMMING MANUAL HERMO...

This manual is also suitable for:

Gw16970cbGw16970cnGw16979ct

Table of Contents
