GW Instek GRA-440 Assembly Manual

Rack adapter panel

Rack Adapter Panel

GRA-440

Assembly Manual

GW INSTEK PART NO. 82RA-44000M01

This assembly manual contains proprietary information, which is protected by copyrights. All rights are

reserved. No part of this manual may be photocopied, reproduced or translated to another language

without prior written consent of Good Will company.

The information in this manual was correct at the time of printing. However, Good Will continues to

improve products and reserves the rights to change specification, equipment, and maintenance

procedures at any time without notice.

Good Will Instrument Co., Ltd.

No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.

ISO-9001 CERTIFIED MANUFACTURER

Table of Contents

Need help?

Do you have a question about the GRA-440 and is the answer not in the manual?

Page 1 Rack Adapter Panel GRA-440 Assembly Manual GW INSTEK PART NO. 82RA-44000M01 This assembly manual contains proprietary information, which is protected by copyrights. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company.
Page 2 GRA-440 Assembly Manual GRA-440 The GRA-440 rack mount is suited for the GPT-12000 / 15000. The GRA-440 supports the EIA standards for use with standard-sized rack units. The GRA-440 holds one GPT unit and fits in a standard 19” 4U rack.
Page 3 GRA-440 Assembly Manual 2. Attach the L-type bracket to the unit followed by fixing the 594B-W3008NS1 screws to the unit. 3. Attach the front plate and handles to the bottom plate with fastening the screws.
Page 4 GRA-440 Assembly Manual 4. Attach the unit with the L-bracket and the 594B-W4010NS1 screws to the bottom plate. Make sure the front panel clicks into the front plate of the rack. 5. Fasten the 2 screws into the L-bracket and the bottom plate...
