3.6 Playback

3.6.1 RUNNING IN SOUND-MODE

Action :
1) Press the MUSIC BANK COPY button until the MUSIC LED turns on.
2) Select the program BANK to run in soundactive mode using the BANK UP/DOWN buttons.
3) Alternatively you can press a single CHASE button(1~6) or several CHASE buttons in sequence and all
selected
chases will loop in the order selected.
4) You can adjust the duration time using the FADE TIME fader.

3.6.2 RUNNING IN AUTO-MODE

Action :
1) Press the AUTO DEL button until the AUTO LED turns on.
2) If a CHASE button is not pressed the controller will automatically run a BANK program.
3) Change BANK programs by using BANK UP/DOWN buttons.
4) Alternatively you can press a single CHASE button(1~6) or several CHASE buttons in sequence and all
selected chases will loop in the order selected.
5) You can adjust the time between steps by moving the SPEED fader and the duration of the step by
moving the FADE TIME fader.
3.6.3 RUN MULTIPLE CHASES CYCLE
Action :
1) Press and hold AUTO DEL button.
2) While holding down AUTO DEL, in success press and release each CHASE you would like to run cycle
Notes :. IMPORTANT! To avoid conflict between scenes running simultaneously that control the same
fixture attributes consider creating individual color and gobo chases.

3.6.4 BLACKOUT

The Blackout button brings all lighting output to 0 or off

3.7 MIDI OPERATION

The controller will only respond to MIDI commands on the MIDI channel which it is set to full stop. All MIDI
control is performed using Note on commands. All other MIDI instructions are ignored. To stop a chase,
send the blackout on note
Action :
1)Press and hold the MIDI/ADD button for about 3 seconds.
2) Select the MIDI control channel (1~16) via the BANK UP/DOWN buttons to set.
3) Press and hold the MIDI/ADD button for 3 seconds to save settings.
4) To release MIDI control, press any other button except the BANK buttons during step 2.
