User manual
Scanners Default DMX
Starting adress
1
2
3
4
5
6
7
8
9
10
11
12
Please refer to your individual fixture's manual for DMX addressing instructions.
The table above refers to a standard 9 dipswitch binary configurable device

3.1.3 Wheel assignement

Because not all intelligent lighting fixtures are alike or share the same control attributes, the Controller
allows the user to assign the wheel the correct pan and tilt channel for every individual fixture including 16
bit channel assignments. It also allows the user to re-assign physical faders to fixture DMX channels so that
the user can combine or unify control of similar or the same attributes across different types of fixtures.
Action :
1) press and hold the PROGRAM button until the led blinks
2) Press and hold FINE & MODE buttons together (2) times to access the channel assignment mode. the
assign led will light.the wheel can be reassigned to output on a different dmx channel.
3) press a SCANNER button that represents the fixture you would like to set the pan&tilt
4) Use the BANKUP/DOWN buttons to select you want to set
5) Press the TAP/DISPLAY button to switch pages to choose channels
6) press and hold MODE button, then press the SCENES buttons to select the DMXchannel.All LEDs
will blink and LCD display will show Pan/Tilt setted channel
7) Press and hold FINE & MODE buttons together to exit
Binary
Dipswitch ON
1 1
17 1 , 5
33 1 , 6
49 1 , 5 , 6
65 1 , 7
81 1 , 5 , 7
97 1 , 6 , 7
113 1, 5 , 6 , 7
129 1 , 8
145 1 , 5 , 8
161 1 , 6 , 8
177 1 , 5 , 6 , 8
Scanners Default DMX
Starting adress
13 193
14 209
15 225
16 241
17 257
18 273
19 289
20 305
21 321
22 337
23 353
24 369
C 512 M
Binary
Dipswitch ON
1 , 7 , 8
1 , 5 , 7 , 8
1 , 6 , 7 , 8
1 , 5 , 6 , 7 , 8
1 , 9
1 , 5 , 9
1 , 6 , 9
1 , 5 , 6 , 9
1 , 7 , 9
1 , 5 , 7 , 9
1 , 6 , 7 , 9
1 , 5 , 6 , 7 , 9
28
