FACSIMILE RECEIVER FAX-30
The purpose of this Operator's Guide is to provide basic operating procedures for this
equipment. For more detailed information see the Operator's Manual.
<For NavNet>
8
9
ABC DEF GHI
1 2 3
JKL MNO PQR
4 5 6
STU VWX YZ&
7 8 9
EBL
_'#
GAIN
VRM
0
Accessing the FAX Mode
1. Press the DISP key to show the display
selection window.
RADAR PLOTTER SOUNDER
NAV DATA OVERLAY
HOTPAGE 1 HOTPAGE 2 HOTPAGE 3 HOTPAGE 4
· TURN KNOB TO SELECT MODE
AND PUSH KNOB TO ENTER.
· PUSH ANY SOFTKEY TO
SELECT IMAGE SOURCE.
Operator's Guide
1
2
3
4
5
6
7
Fax mode icon
EXT VIDEO WXFAX
HOTPAGE 5 HOTPAGE 6
Key Name
1 Trackball
2 ALARM
3 CLEAR
4 MENU
5 ENTER knob
6 Alphanumeric keys
7 POWER/BRILL
8 DISP
9 Soft keys
2. Rotate the ENTER knob to choose the
WX FAX icon.
3. Push the ENTER knob to show the fax
stand-by display.
Functions
Chooses menu items.
Displays alarm message.
Clears data.
Opens FAX-30 menu;
returns to standby.
Push: Registers setting.
Rotate: Selects menu
items and options. May
also be used to enter
alphanumeric data.
Enter alphanumeric data.
Long press: Turns power
off.
Momentary press: Turns
the power on; opens the
display for adjustment of
brilliance.
Displays the mode
selection window.
Execute the appropriate
function.
