2 - 2 Product Description
Lucent Technologies DC-DC Converter and Shelf Assembly
Table 2-A: Specific Characteristics and Ratings,
Product
List 1A Converter
List 2 Converter
Shelf Assembly
List 3 Mounting
Bracket
List 4 Blank Panel
List 5 Cable
Extended Assembly
List 7 Converter
Shelf Assembly
List 8 Sloped Heat
Deflector Baffle
List 9 Converter
Shelf Assembly
Lists 1A - 9
Characteristics
6.9" H x 8.4" W x 10.0" D
Weight: 8 lbs
UL Listed
7.0" H x 23" or 26" W x 16.0" D
Weight: 12 lbs
Allow at least 3.5" for air circulation above
List 2
UL Listed
Used to mount shelf assembly in 23" or 26"
frames
6.88" H x 8.35" W x 9.9" D x 0.125" T
Weight: 8 oz
18" L
Weight: 8 oz
7.0" H x 23" or 26" W x 16.0" D
Weight: 28 lbs
4.05" H (including 0.555" mounting flange) x
14.3" D x 17.15" W
Weight: 2 lbs
Replaces top grill work of List 2 Converter
Shelf Assembly
Allow at least 3.5" for air circulation above
List 2
7.0" H x 23" or 26" W x 16.0" D
Weight: 20 lbs
