  • Page 1 CIB 2866 Auxiliary Power Unit CIB 2866 Comcode 103-974-606 Issue 3...
  • Page 2 CIB 2866 Auxiliary Power Unit When the number of voice terminals and voice terminal accessories (including hands-free units and headset adapters) is greater than your MERLIN® Communications System’s capacity, connect an Auxiliary Power Unit (Figure 1) to supply your MERLIN system with additional power.
  • Page 3 Installing the Auxiliary Power Unit Refer to the table below to select an appropriate installation method for your Auxiliary Power Unit, depending on the model of your MERLIN sys- tem. Separate installation instructions follow the table for each method. Use one of these installation methods: If your system is a: MERLIN Model...
  • Page 4 Unpack the hardware kit and follow the instructions below for the type of mounting surface you have selected. For plywood walls or walls with a sturdy support structure (wood studs or crossmembers): A Use a 1/16” drill bit to drill pilot holes at both of the marked mounting screw locations.
  • Page 5 Wall mount R e d Mounting Mounting Plate Studs Keyholes FIGURE 2 Installing the Auxiliary Power Unit On a Hollow Wall For concrete, brick, and cinder block surfaces: A Install #6 masonry bolts (not provided) according to the manufacturer’s instructions at each of the previously marked mounting screw locations.
  • Page 6 Connect to the Power Module’s auxiliary power jack Auxiliary power cord Auxiliary Power Unit AC outlet AC line cord Control unit Power cord from the Power Module FIGURE 3 Connecting the Auxiliary Power Unit to a Model 1030 If you mounted the Auxiliary Power Unit on back of the control unit or expansion unit, thread the auxiliary power cord through the top rail of the unit (Figure 3).
  • Page 7 MERLIN II 1 Remove the front cover. 2 Turn off the power switch(es) on the Power Module(s). If your sys- tem has an expansion carrier, first turn the power off at the basic carrier’s power module. Then turn the power off at the expansion carrier’s power module.
  • Page 8 7 Plug the other end of the line cord into an ac outlet that is not switch- controlled (Figure 4). 8 Turn On the power switch. If your system has an expansion car- rier, first turn the power on at the expansion unit’s Power Module. Then turn the power on at the basic carrier’s Power Module.
