Page 1 ® Lineage 2000 100-Ampere, 60-Hertz Ferroresonant Rectifier J85503A-1 Product Manual Select Code 169-790-119 Comcode 107021818 Issue 6 October 1998 © 1998 Lucent Technologies...
Page 3 100-Ampere, 60-Hertz Ferroresonant Rectifier Notice: Every effort was made to ensure that the information in this document was complete and accurate at the time of printing. However, information is subject to change. ©1998 Lucent Technologies All Rights Reserved Printed in U.S.A.
Page 5: Table Of Contents
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table of Contents 1 Introduction General Information Customer Training Customer Service Technical Support Product Repair and Return Warranty Service 2 Product Description Overview Ferroresonant Technology Standard Features Additional Features Circuit Modules...
Page 6 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Heat Dissipation AC Input Power DC Output Power Installation Tools Unpacking Installing or Adding a Rectifier 5-10 Install AC Power Cables 5-10 Install DC Power Cables 5-11 Install Plant Control Cable Assembly for a...
Page 7 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Phase Failure Test (On Line) 6-17 Backup High Voltage Shutdown (HVSD) Test (On Line) 6-17 Meter Calibration Test (On Line) 6-18 Adjust Rectifiers to Float Voltage 6-19 Adjust Rectifiers Individually 6-19...
Page 8 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 DC Inductors (L3 or L4) 8 - 15 DC Capacitors (C1, C2, or C3/C4) 8 - 16 Main Transformers (T1 or T2) 8 - 17 Rectifier Diode Test and/or Replacement 8 - 17...
Page 9 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 List of Figures Figure 2-1: Location of Circuit Modules Figure 2-2: CM1 Option Board Showing White Test Clip Connection and Removable Straps K and M Figure 2-3: CM2 Control Board Showing Test Clip...
Page 11 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 List of Tables Table 2-A: Digital Meter Accuracy 2-11 Table 2-B: Physical and Thermal Specifications of the J85503A-1 Rectifier 2-13 Table 2-C: Input Specifications for the J85503A-1 Rectifier 2-14 Table 2-D: Output Specifications for the J85503A-1...
Page 12 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table 8-D: Torque and Minimum Yield Strength for Mechanical Connections (Using Hex Head Cap Screws) 8 - 10 Table 8-E: Minimum Torque for all Electrical Connections 8 - 11 2 - List of Tables...
Page 13: Introduction
® The J85503A-1 rectifier can be used with a Lineage 2000 battery plant, older vintage Lucent Technologies battery plants, or any commercial battery plant. With certain options, it can also operate off battery. Customer Lucent Technologies offers customer training on many Power Systems products.
Page 14: Technical Support
For other customers worldwide, contact your local field support center or your sales representative to discuss your specific needs. Product Repair Repair and return service is provided for Lucent Technologies customers around the world. For customers in the United States, and Return...
Page 15: Product Description
This transition needs no switching because of the parallel connection of the rectifiers and batteries. Ferroresonant The J85503A-1 rectifier is a member of the Lucent Technologies ® family of Lineage 2000 rectifiers. Like all the rectifiers in the...
Page 16: Standard Features
• All components in the rectifier meet Lucent Technologies's strict specifications and reliability standards. The rectifier uses an extremely efficient free-convection cooling system that keeps components operating at temperatures well below the recommended maximum, resulting in high reliability.
Page 17 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 the starting surge on the customer's power source and is especially important with a more limited power source, such as an emergency generator set. • External selective high voltage shutdown: If the battery voltage goes too high, the controller signals all of the connected rectifiers.
Page 18: Additional Features
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 • Fuse alarm circuit: The low-power control functions shut down the rectifier if a fuse alarm (FA) occurs. One fuse alarm protects each of the regulation leads. When any fuse alarm occurs, a Rectifier Failure Alarm (RFA) LED lights on the front panel and an RFA signal is generated.
Page 19: Circuit Modules
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 the rectifier meets all specified operating characteristics when subjected to electric fields up to 10 volts per meter over a frequency range of 20 to 1000 MHz. Circuit Modules The rectifier's signal processing and control circuitry are located on replaceable circuit modules or packs.
Page 20: Figure 2-1: Location Of Circuit Modules
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 battery voltage depending on the three-position selector switch (see “Front Panel Controls and Indicators”). • The CA1 circuit module (ED83162-30 Group 1) contains a triac/thyristor snubber network. Refer to schematic drawing SD-82605-01 for further information.
Page 21: Figure 2-2: Cm1 Option Board Showing White Test
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Figure 2-2: CM1 Option Board Showing White Test Clip Connection and Removable Straps K and M Issue 6 October 1998 Product Description 2 - 7...
Page 22: Figure 2-3: Cm2 Control Board Showing Test Clip
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Figure 2-3: CM2 Control Board Showing Test Clip Connections and Other Component Details 2 - 8 Product Description Issue 6 October 1998...
Page 23: Figure 2-4: Partial Sketch Of Cm3 Digital Meter Board
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Figure 2-4: Partial Sketch of CM3 Digital Meter Board Issue 6 October 1998 Product Description 2 - 9...
Page 24: Front Panel Controls And Indicators
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Front Panel Figure 2-5 shows the front control panel of the J85503A-1, 100-ampere rectifier. Controls and Indicators Figure 2-5: Control Panel on the J85503A-1 Rectifier The following list describes the controls and indicators on the rectifier control panel.
Page 25: Table 2-A: Digital Meter Accuracy
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table 2-A: Digital Meter Accuracy Meter Accuracy Position ±0.5 volt for Series 1 or 2 CM3 digital meter boards Rect V ±0.02 volt for Series 3 CM3 digital meter boards* Batt V ±0.02 volt for any CM3 digital meter board...
Page 26: Alarm And Control Flow
2000 controller product manuals for a description of rectifier signal processing and resultant action. Figure 2-6 shows the typical signal flow between a rectifier and a Lucent Technologies controller. The control signals and alarms enter and leave the rectifier via the control circuit module ®...
Page 27: Physical, Thermal, And Electrical Specifications
* Plant Control Cable Assembly is manufactured by Lucent Technologies and must be ordered separately. ® See Lineage 2000 Battery Plant documentation for details. Figure 2-6: Signal Flow between Rectifier and Lucent Technologies Controller Physical, Table 2-B, Table 2-C, and Table 2-D give the physical, thermal, ®...
Page 28: Table 2-C: Input Specifications For The J85503A-1
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table 2-B: Physical and Thermal Specifications of the J85503A-1 Rectifier Output DC Output DC ±24V –48V Audible Noise at 5 ft. above floor and Less than 65 dBA 2 ft. in front of...
Page 29: Ordering Information
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Ordering Information Options Table 3-A gives the equipment lists that are available for the ® Lineage 2000 J85503A-1, 100-ampere rectifier.Lists 1-6 are always required depending on the choice of input ac and output dc voltages.
Page 30: Table 3-A: Equipment Lists For The J85503A-1
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table 3-A: Equipment Lists for the J85503A-1 Rectifier List Number Input AC (volts) Output DC (volts) ±24 –48 ±24 –48 ±24 –48 Always Required Provides List Number Digital meter Additional output filtering on 24V rectifiers...
Page 31: Safety
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Safety Please read this section carefully before installing, maintaining, or repairing the J85503A-1 rectifier. Admonishments Always take precautions to protect personal safety as well as the equipment when working on power systems. Throughout this manual, admonishments relating to personal safety are labeled DANGER or Warning.
Page 32: Precautions
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 and/or local codes. The size of the overcurrent protector used must not exceed 50A. Refer to the equipment ratings to assure rating of equipment will not exceed 80% of the value of the protector chosen.
Page 33 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 – Hazardous DC energy (from batteries and rectifier output) and voltages up to 600 volts are present in the unit. Use a voltmeter to insure no voltage, or the expected voltage, is present before contacting any uninsulated conductor surface.
Page 34: Warning Statements And Safety Symbols
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 possible to prevent accidental turn on. – Be aware of potential hazards in the area you are working before entering the equipment. – Identify exposed hazardous electrical potentials on connectors, wiring, etc. (note the condition of these circuits, especially any wiring).
Page 35 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 One of the above two symbols (or equivalent) may be used to identify the presence of rectifier and battery voltages. The symbol may sometimes be accompanied by some type of statement - for example: “Battery voltage present. Risk of injury due to high current.
Page 37: Installation
Lucent Technologies offers “turn-key” engineering and installation services for the products described in this product manual. Consult your Lucent Technologies representative for details.
Page 38: Bay Mounting
Rectifiers ordered as individual units are shipped in individual containers. The rectifiers mount in Lucent Technologies 26-inch wide bays, with 24-5/16 inch mounting centers. The bays have drilled holes on 1-inch centers, in the vertical plane, to accommodate #12-24 threads per inch self-tapping screws.
Page 39: Table 5-A: Ac Input Requirements
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table 5-A: AC Input Requirements Armored Cable Conduit Input Terminal Number Trade Max. Knockout, Line Fuse Circuit of Input Size Input & Conduit List Volts Amps Type, Breaker Supplied Wires, (inches)
Page 40: Dc Output Power
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 DC Output Power The majority of dc power plants for telecommunication applications are designed to use single conductor cables (in parallel for current capacity or to limit voltage drop) supported on ladder racks. Experience has shown that the use of flexible cables (welding type cables) makes installation of this type wiring much simpler.
Page 41: Unpacking
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 • Common mechanic's hand tools, including flat blade screwdriver (0.30 inch blade width), socket and torque wrench for 3/8 inch bolts, channel lock pliers for ac conduit tightening, hammer, and crowbar for uncrating •...
Page 42: Figure 5-1: Four Views Of The J85503A-1 Rectifier
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 provided in “Converting AC Voltage” in Section 5. The procedure for placing the DC Output circuit breaker (CBA1) in the opposite output bus is described in “Converting DC Output Polarity”. Figure 5-1: Four Views of the J85503A-1 Rectifier...
Page 43: Figure 5-2: Front View Of J85503A-1 Rectifier With Door
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Figure 5-2: Front View of J85503A-1 Rectifier with Door Open Issue 6 October 1998 Installation 5 - 7...
Page 44: Figure 5-3: Ac Input Components Mounted On The
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Figure 5-3: AC Input Components Mounted on the Upper Left Side of the J85503A-1 Rectifier Behind the Protective Shield 5 - 8 Installation Issue 6 October 1998...
Page 45: Figure 5-4: Output Polarity Conversion And
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Figure 5-4: Output Polarity Conversion and Component Detail on Bus Bar Assembly Issue 6 October 1998 Installation 5 - 9...
Page 46: Installing Or Adding A Rectifier
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Installing or Before beginning this procedure, read the section above on “Preparing for Installation” in its entirety. This procedure is Adding a appropriate for installing a rectifier in a new plant or adding a Rectifier rectifier to an existing plant to increase capacity.
Page 47: Install Dc Power Cables
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 2. Disconnect ac power from ac distribution service panel that supplies power to the rectifier. 3. Install fuse holders or circuit breaker for the rectifier in the ac distribution service panel. Leave circuit breaker in off position or remove fuses.
Page 48 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 4. Tape or otherwise insulate the connectors on the end of each cable that does not terminate in the rectifier. 5. Place dc return cable in cable rack. 6. Thread end of cable through right side of rectifier and terminate connector at the appropriate ground bus bar in the rectifier.
Page 49 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 closed without putting stress on the cable. After securing the cable, disconnect the cable from P2A. 3. Determine the number to be assigned the rectifier in the rectifier lineup, that is, 1, 2, 3, etc.
Page 50: Converting Ac Voltage
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 The rectifier is now installed. The last three sections in this chapter are optional procedures that may be needed at installation. If not, proceed to Section 6, Testing. Converting AC Converting the ac input voltage to a rectifier is necessary only if...
Page 51: Converting Dc Output Polarity
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 240). The second is to rewire the auxiliary transformer (T3) input by reconnecting jumpers on the fast-on terminal strip mounted on T3. Connecting the Three Alternate AC Leads: 1. Remove the relay shield to expose the K1 contactor and the T3 terminal strip.
Page 52: Output (Positive Ground)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Output (Negative Ground)” to convert to a positive output (negative ground) system, and use the section “Positive Output (Negative Ground) to Negative Output (Positive Ground)” to convert to a negative output (positive ground) system.
Page 53: Initial Battery Charging (Optional)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 In Figure 5-4 rectifier wiring appears as in the lower drawing before the work is started, and appears as in the upper drawing upon completion of the work. Save the washers and nuts that are removed for later use.
Page 54: Table 5-D: Rectifier Control Settings
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table 5-D: Rectifier Control Settings for Initial Battery Charge Controls Position/Status Rectifier Power Switch Off (down) Rectifier DC Output circuit Off (down) breaker Output Volts Adj potentiometer Fully counterclockwise Plant control connector J2A on...
Page 55 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 6. Turn the DC Output circuit breaker on (up). Caution In the following step, DO NOT set the rectifier output voltage to exceed 62 volts (48-volt rectifier) or 31 volts (24-volt rectifier) or damage to the unit may result.
Page 57: Testing
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Testing Introduction This section gives test procedures for newly installed and/or operating rectifiers. If the plant in which a rectifier is being installed has never been operational, the plant and controller tests must be performed before the rectifier tests.
Page 58: Tools And Test Equipment
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Warning Do not turn the DC Output circuit breaker ON, close an external charge circuit breaker, or install an external charge fuse until told to do so. Tools and Test The following items are needed for testing the rectifier.
Page 59: Battery Plant Simulator Test Set
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Caution Support the CM2 control board when disconnecting the cable leads or damage to the control board may result. Do NOT disconnect plant control cable connector J2A from control board CM2 by pulling the cable.
Page 60: Initial Conditions For Testing Off Line
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Initial The following steps establish initial conditions for the equipment before testing. Conditions for Testing Off 1. Verify that the ac supply and rectifier controls are as Line shown in Table 6-A.
Page 61 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Note On J2A, pins 1, 5, 10, 15, and 20 are marked on the connector. Pin 21 is in the row across from pin 1. Pin 40 is across from pin 20.
Page 62: Testing Off Line
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table 6-B: Test Set Connections Test Figure Connection Voltage Clip Positive side of capacitor C4 on CM2 (208A or B) board Negative side of capacitor Black C4 on CM2 (208A or B)
Page 63: Rectifier Failure Alarm/Fuse Alarm Test (Off Line)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 same as on the rectifier control panel when the door is closed (see Figure 2-5). 4. Adjust the test load so that when the rectifier is turned on, it will deliver 5-20A, 5 to 20 percent of full load.
Page 64: Phase Failure Test (Off Line)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Note is the voltage reading between the rectifier output terminal and return, see Figure 5-4. 2. Strap a short across capacitor C27 on CM2, see Figure 2-3. At I = 100-102A, 100 to 101 percent of rated output...
Page 65: Backup High Voltage Shutdown (Hvsd) Test
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 3. Verify that no ac voltage is present on the input leads of the ac contactor K1 (see Figure 5-3). 4. Disconnect one input lead, L1, L2, or L3 on K1, or at the ac service panel, whichever is more convenient.
Page 66: (Off Line)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 3. Reduce the test load to zero. 4. Press the HV switch on the test set. The rectifier should continue to operate. Selective High 1. Adjust the test load so that the rectifier delivers 10-15A, 10 Voltage to 15 percent of its rated amperage.
Page 67: Bringing Rectifier On Line
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 2. Adjust the Output Volts Adj potentiometer to between 52.02 and 52.13 (or 26.01 and 26.06) volts read on the Output meter, or to float voltage as determined by “Adjust Rectifiers to Float Voltage” later in this section.
Page 68: Table 6-C: Rectifier Control Settings Prior To
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table 6-C: Rectifier Control Settings Prior to Testing On Line Controls Position/Status Associated ac circuit breaker Off or fuses removed and or fuses at the ac service holders tagged “Out of distribution panel Service”...
Page 69: Testing On Line
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 b. Hold the meter selector switch in the Rect V position, and use a small screwdriver to turn the Output Volts Adj potentiometer clockwise until the digital meter reads approximately battery voltage, typically 26 volts for 24-volt plants or 52 volts for 48-volt plants.
Page 70: Rectifier Failure Alarm/Fuse Alarm Test (On Line)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 2. Observe the amperes reading on the Output meter. Hold the Rect Test switch in the NL position. The output amperes should decrease. 3. Repeat from Step 1 and in Step 2 hold the Rect Test switch in the FL position.
Page 71: Current Limit Test (On Line)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Current Limit Test (On Line) Notes Adjust the current limit only after verifying that a current limit circuit problem exists. There must be two or more rectifiers with a plant load of at least 25 percent higher than the capacity of the largest rectifier.
Page 72 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 must be performed while connected to an MCS or Galaxy controller and a battery. Refer to Figure 2-3 for components on the CM2 control board. Plant control cable connector J2A MUST be connected to P2A on CM2 for this procedure.
Page 73: Phase Failure Test (On Line)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Phase Failure 1. Turn the DC Output circuit breaker off (down). Test (On Line) 2. With the Power switch still On, turn off the ac service and note that the rectifier shuts down.
Page 74: (On Line)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Meter Check calibration of the digital meter annually as preventive Calibration Test maintenance. (On Line) 1. Adjust the load so that the rectifier delivers approximately 50 amperes, 50% of its rated current capacity.
Page 75: Adjust Rectifiers To Float Voltage
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Adjust Float voltage is the optimum voltage level at which a battery string gives maximum life and full capacity. This voltage Rectifiers to depends on the type and number of batteries in a plant:...
Page 76: Adjust Rectifiers As A Group
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 3. Turn the rectifier off and repeat this procedure for each rectifier in the group. 4. Turn all rectifiers on after the last rectifier is adjusted. Adjust Rectifiers If the load requirement is always greater than the capacity of...
Page 77 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 percent rated load until they carry less than 95 percent rated load. d. Repeat from Step 2 (battery voltage check and adjustment) until all rectifiers are carrying between 5 and 95 percent rated load and the battery voltage is within the required tolerance of the desired float voltage.
Page 79: Troubleshooting And Adjustments
For tools and test equipment required for certain adjustments, refer to “Tools and Test Equipment” in Section 6, Testing. For technical assistance at any time, call Lucent Technologies at 1-800-CAL-RTAC (1-800-225-7822). Remove In general, adjustments should be made to a rectifier while it is removed from service.
Page 80: Diagnostics And Troubleshooting
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 6. At the rectifier, loosen the locking screws and open the door. 7. Locate the CM2 control board. Caution The REG fuse associated with the rectifier in the plant controller must be removed before cable connector J2A is disconnected or damage to rectifier circuit pack may result.
Page 81: Table 7-A: Troubleshooting
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table 7-A: Troubleshooting (Sheet 1 of 3) Probable Corrective Problem Probable Cause Action 1. Check for ac input voltage to rectifier. 2. Check for ac voltage on secondary of T3. See SD.
Page 82 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table 7-A: Troubleshooting (Sheet 2 of 3) Probable Corrective Problem Probable Cause Action 1. Turn potentiometer counterclockwise. 1. Output Volts Adj 2. Replace CM2 as potentiometer is set too described under “Replace high.
Page 83: Adjustments
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table 7-A: Troubleshooting (Sheet 3 of 3) Probable Corrective Problem Probable Cause Action 1. Replace CM2 as described under “Replace CM2 Control Board” in 8. Rectifier output voltage Section 8. Verify that 1.
Page 84: Calibrate Cm3 Digital Meter
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 b. If the rectifier Output Volts Adj potentiometer can adjust the voltage to the correct level, then the RFA problem has been cleared. Otherwise, continue this procedure. 8. If the rectifier output voltage is less than the plant voltage and/or all rectifiers shut down, then use the following procedures.
Page 85 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Caution For Series 1 or 2 CM3 boards, use extreme care when removing the board from the support standoffs (see notes below). Note A Series 3 CM3 board can be calibrated without removing the board from the support standoffs.
Page 86 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 8. Observe the DMM and record the rectifier’s shunt voltage. The shunt is rated 125A/50mV = 2.5A/mV, which means that each millivolt of voltage drop across the shunt indicates 2.5A of output current.
Page 87 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 current, adjust the Output Volts Adj potentiometer counterclockwise until the meter reads zero amperes. 2. Connect a DMM (set on the dc millivolt scale) across the rectifier's shunt. The digital meter should read zero millivolts.
Page 88: Restore Rectifier To Service
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Adjust Current Off Line Adjustment: Use the “Current Limit Test (Off Line)” Limit in Section 6, Testing, to verify that the current limit circuit needs adjustment, before continuing with this procedure.
Page 89 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 4. To bring the rectifier into service: a. Turn the rectifier Power switch On. The green Power LED must light. Wait 10 seconds. Note If the rectifier continues to operate, proceed to Step b. If the rectifier shuts down due to initial high voltage, monitor the Rect V voltage.
Page 91: Spare Parts And Replacement Procedures
2000 100A Ferroresonant Rectifier J85503A-1 Spare Parts and Replacement Procedures Ordering Lucent Technologies combines into spare parts kits CM1, CM2, CM3, and CA1 circuit boards, described in Section 2, Product Circuit Modules Description. Kit number H569-358 L8 contains these replaceable boards for the J85503A-1 rectifier. Table 8-A shows the contents of this kit along with the part numbers.
Page 92: Electrostatic Discharge
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Electrostatic Discharge Caution Grounded antistatic wrist straps must be worn for all circuit pack handling. The alligator clip connector of the wrist strap must be connected to a bare metal frame ground. The wrist strap must contact the skin and is not to be worn over clothing.
Page 93: Table 8-B: Modifications For The Cm1 Board
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 circuit packs in antistatic packaging. Shielding is not required unless specified. • Keep all static-generating materials away from circuit packs. These materials include common plastics such as food wrappers, clear plastic bags, styrofoam containers, packing material, drinking cups, notebooks, and nonconducting plastic solder suckers.
Page 94: Spare Fuses
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Spare Fuses Table 8-C provides spare fuse information for the J85503A-1 rectifier. A commercial equivalent fuse and the appropriate SD sheets are referenced. Table 8-C: Spare Fuse Information Fuse Lucent Part...
Page 95 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 4. At the plant controller, remove the REG fuse associated with the rectifier. Disconnect control cable connector J2A from the control board CM2. 5. At the rectifier, loosen the locking screws and open the rectifier door.
Page 96 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 1. Turn the rectifier Power switch Off. 2. Turn the rectifier DC Output circuit breaker off (down). 3. At the ac service panel supplying power to the rectifier, remove the input fuse assigned to the rectifier, or turn the circuit breaker Off.
Page 97 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 14. If the rectifier is to be restored to service, refer to “Restore Rectifier to Service” in Section 7, Troubleshooting and Adjustments. Replace CM3 Follow instructions under “Handling Circuit Modules” earlier in...
Page 98: General Considerations For Replacing Components
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 10. Plug in the cable connector that leads to the control board. 11. Check calibration of rectifier meter as described in “Meter Calibration Test (Off Line)” in Section 6, Testing. 12. If the rectifier is to be restored to service, refer to “Restore Rectifier to Service”...
Page 99 Some capacitor blowholes cannot be viewed directly until removed, or almost removed, from the rectifier. A dental-type mirror aids in viewing these capacitors' blowholes before disassembly. Lucent Technologies recommends that all dc capacitors in a rectifier be replaced whenever any one of them blows.
Page 100 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 • All removal and replacement procedures are easier to perform on bay-mounted rectifiers that have been removed from the bay. • Most component removals are straightforward and obvious. Therefore, these procedures can be used as a guide by qualified service personnel, rather than as step-by-step procedures.
Page 101 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Table 8-E: Minimum Torque for all Electrical Connections Torques in In-Lb or (Ft-Lb) Wire Connections Hand Tightened Nut Tightened Slotted Screw Size Hex or Hex or Slotted Slotted Machine Socket Socket...
Page 102: Replacing Components
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Replacing Components DANGER The following disassembly or reinstallation procedures MUST be performed only on a rectifier completely disconnected from the plant battery buses, AND with no input from the ac service panel connected to the rectifier. The plant control cable J2A should also be disconnected from the CM2 board.
Page 103: Transformer (T3)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 2. Remove the three nuts that secure the shield to the side of the rectifier frame, and remove shield. 3. The following components should be exposed: T3, L1, L2, K1, K2, K3, and T2.
Page 104: Ca1 Board (Snubber Network)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 rectifier). Remove T3 from the frame of the rectifier per Steps 2 and 3 of Procedure D in this part. 2. For L2 removal, it is necessary to remove all three relays;...
Page 105: Diode Heat Sink Assembly
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 4. During reinstallation, before attaching the clamp to the frame, make sure that the bottom of the clamp is flush with the bottom of the capacitor. Diode Heat Sink It is possible to remove individual rectifier diodes from the heat Assembly sink while the heat sink assembly is still mounted in the rectifier.
Page 106: Dc Capacitors (C1, C2, Or C3/C4)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 in this section. Move the assembly out of the way to the left. 2. Disconnect the lead from the inner tab of L4. 3. Remove the other (outer tab) lead (coming from L4) from its connection point on the bus bar assembly.
Page 107: Main Transformers (T1 Or T2)
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Main This procedure assumes that the rectifier has been removed from Transformers the bay. (T1 or T2) 1. Disconnect the transformer primary leads from the K1 contactor relay (two for T1 or one for T2).
Page 108 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 2. The diode is now electrically isolated for test purposes. 3. If this procedure is being performed to test a diode, skip to Step 8. To replace a diode that is known to be defective, continue with Step 4.
Page 109: Disconnecting A Rectifier
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 9. If the diode checked bad, proceed to Step 4 of this procedure to remove and replace it. If the diode checked good, proceed to Step 7 of this procedure to reinstall.
Page 110 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 6. One at a time, disconnect the battery plant end of the dc output and output return conductors from the battery plant charge and charge ground bus bars. Insulate the connector ends and label the conductors for easy identification when reconnecting.
Page 111: Product Warranty
® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Product Warranty A. Seller warrants to Customer only, that: 1. As of the date title to Products passes, Seller will have the right to sell, transfer, and assign such Products and the title conveyed by Seller shall be good;...
Page 112 ® Lucent Technologies Lineage 2000 100A Ferroresonant Rectifier J85503A-1 Warranty Period Product Type New Product Repaired Product or Part* Central Office Power Equipment 24 Months 6 Months The Warranty Period for a repaired Product or part thereof is as listed...
Page 113 FOR A PARTICULAR PURPOSE. CUSTOMER'S SOLE AND EXCLUSIVE REMEDY SHALL BE SELLER'S OBLIGATION TO REPAIR, REPLACE, CREDIT, OR REFUND AS SET FORTH ABOVE IN THIS WARRANTY. Copyright 1998 Lucent Technologies All Rights Reserved Printed in U.S.A. Issue 6 October 1998...
