Optimal 1700 Manual page 38

TREE SPADE OPTIMAL 1700
HYDRAULIC SYSTEM
Item Quantity
1 4
2 2
3 1
4 1
5 3
6 12
7 2
8 1
9 1
10 4
11 2
12 2
13 4
14 16
15 4
16 23
17 8
18 1
19 12
20 12
21 4
- SPARE PARTS
Description
spade cylinder
gate cylinder
gate lock cylinder
control block
control valve NG06
socket head screw M 5 x 50 DIN 912
pressure relief valve
flow control valve
fixing plate
hex bolt M 8 x 16 DIN 7991
control block, LH
control block, RH
control valve NG10
socket head screw M6 x 40 DIN 912
check valve
plug VSTI ¼"
plug VSTI ½"
plug VSTI ¾"
union
union
elbow, male
Part Number
3010117001
301021600
3010300120
5471410010
547001
50105050912
547VSPC150
547OD21356
3151410020
501080167991
5471410030
5471410020
547010
50106040912
547VUCN12A
515VSTI1/4
515VSTI1/2
515VSTI3/4
515020231221
515020231621
515070511221
