Optimal 1700 Manual page 29

TREE SPADE OPTIMAL 1700
GATE LOCK
Item Quantity
1 1
2 1
3 1
4 1
5 1
6 2
7 2
8 8
9 2
10 1
11 2
12 1
13 2
14 1
15 2
16 2
17 1
18 1
19 2
20 4
21 4
22 1
- SPARE PARTS
Description
gate lock cylinder
lock pin, top
lock pin, bottom
transvers plate, top
transvers plate, bottom
socket head screw M 10 x 80
butt plate
hex head screw M 10 x 30
socket head screw M 12 x 120
spacer
union
plate for sensor
countersunk M 6 x 20
fixing plate
washer 6,4 DIN 125
socket head screw M 6 x 20
Inductive sensor
pipe clamp
socket head screw M 6 x 35
socket head screw M 5 x 12
washer 5,4 DIN 125
protection for sensor
Part Number
3010300120
3071700170
3071700180
3181700110
3181700120
50110080912
3181700130
50110030933
50112120912
3181700140
515GE6LANG
3181800090
501060207991
3981700013
506906
50106020912
5990040228
510RAPR-218
50106035912
50105012912
506905
5971701550
