Optimal 1700 Manual page 24

TREE SPADE OPTIMAL 1700
MAIN FRAME
Item Quantity
1
2 8
3 32
4 32
5 8
6 80
7 4
8 4
9 64
10 64
11 2
12 2
13 2
14 2
15 4
16 4
17 2
18 2
19 4
20 2
21 4
- SPARE PARTS
Description
digging head frame
cylinder suspension pin
screw M 12 x 30, DIN 933
spring washer DIN 127
guide
screw M 24 x 50, DIN 933
tensioner, RH
tensioner, LH
nut M 20, DIN 934
washer 20 – DIN125
grease nipple
additional hinge pin
bush
castellated nut M 33x1.5
screw M 20 x 80, DIN 931
bush 14138
gate cylinder
hinge pin
bush
castellated nut M 42x1.5
screw M 20 x 120, DIN 933
Part Number
17001
30716022
50112030933
50612
30617024
50124050933
309160811, RE
309160811, LI
502200934
506920
59908H1M6
3071900010
31114155
50233150985
50120080931
31114138
301021600
30716025
544505550
50242150985
50120120933
