Blodgett SBF-3E Specifications

SBF-E
Electric Boiler Free
Connectionless Steamer
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Voltage options
380 VAC, 3 phase, 50/60 hz
415 VAC, 3 phase, 50/60 hz
480, 3 phase, 50/60 hz
600 VAC, 3 phase, 50/60 hz (SBF-3E only)
28" (711 mm) high stainless steel stand
Correctional package
Project
Item No.
Quantity
All data is shown is per section, unless otherwise indicated.
EXTERIOR CONSTRUCTION
INTERIOR CONSTRUCTION
OPERATION
CAPACITY
SBF-3E
SBF-5E
STANDARD FEATURES
*
BLODGETT OVEN COMPANY
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: (800) 331-5842 • Phone: (802) 860-3700 • Fax: (802) 864-0183
Model SBF-3E (3 pan electric convection steamer)
Model SBF-5E (5 pan electric convection steamer)
304 stainless steel
Heavy gauge stainless steel door with full perimeter door gasket
Positive lock and seal mechanism with spring release on door
Stainless steel control housing
One piece welded 316 stainless steel cooking chamber
Coved corners
Removable stainless steel pan supports
Selectable timed or continuous steam mode
Connectionless / no plumbing required
Full access removable control panel
Illuminated on/off/constant steam power switch
Ready indicator light
Cooking indicator light
Add water indicator light with audible alarm
60 minute electromechanical timer with end of cycle audible alarm
Steam flow to the cooking chamber is cut off when the door is opened
during the cooking cycle and reactivated when the door is closed
Removable steam diffuser plate, also helps keep large food products
from going into water
Pan Depth
Model
1" 2.5"
6 3
10 5
Electromechanical controls
4" (102mm) stainless steel legs
Standard voltages please select:
208 VAC, 1 or 3 phase, 50/60 hz*
220 VAC, 1 or 3 phase, 50/60 hz*
240 VAC, 1 or 3 phase, 50/60 hz*
380/220 VAC, 3 phase, 50/60 hz, 4 wire
415/420 VAC, 3 phase, 50/60 hz, 4 wire
* Unit shall be field convertable to single phase
One year parts and labor steamer warranty*
Five year limited steamer door warranty*
For all international markets, contact your local distributor.
4" 6"
2 1
3 2
