Blodgett CB36E-6-6K Specifications

CB36E-6-6K
Two Direct Steam Kettles
on a 36" Electric Boiler Base
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Voltage Options
220 VAC, 3 phase, 60 Hz
380 VAC, 3 phase, 60 Hz
415 VAC, 3 phase, 60 Hz
480 VAC, 3 phase, 60 Hz
415/240 VAC, 3 phase, 4 wire
380/220 VAC, 3 phase, 4 wire
600 VAC, 3 phase, 60 Hz
Increased Rating Options
36 kW
42 kW
48 kW (N/A in 208 or 220 VAC)
Etched kettle markings
Gallon markings
Litre markings
Correctional package
Stainless steel back panel
Steam take off kit
Water in "Y" strainer
Pour lip strainer
One piece stainless steel lift off cover
Lift out perforated basket
Graduated measuring strip
One year extended warranty
Project
Item No.
Quantity
Model CB36E-6-6K (Two 6 gallon direct steam kettles on a 36" electric
boiler base)
KETTLES
Water resistant, 304 stainless steel construction
316 stainless steel interior cooking surface for corrosion resistance
2/3 jacketed, hemispherical design on bottom for superior heat circulation
Tilt mechanism permits kettle to tilt forward past 90° to empty
Tubular stainless steel legs containing steam control valve and conden-
sate return pipes
Reversible operating handle with heat proof knob
ELECTRIC BOILER BASE
24 kW electric boiler base
Full perimeter painted angle iron frame
Reinforced counter and boiler mountings
Stainless steel exterior
Hinged door(s) with magnetic latch
6" (152 mm) stainless steel legs with adjustable bullet feet on front and
adjustable flanged feet on rear
All piping is confined within cabinet
Automatic water level control
Automatic boiler blowdown
Pressure gauge
Water gauge glass
Pressure control with pressure safety control
Safety relief valve
Cathodic protector
Steam trap
On/Off switch with indicator light
Split water lines
CSD-1 secondary low water cut off
STANDARD FEATURES
Deck mount hot and cold faucet with riser
3"(76mm) deep sinks with splash guard and grates
Standard voltage options
208 VAC, 3 phase, 60 Hz
208 VAC, 1 phase, 60 Hz (24kW only)
240 VAC, 3 phase, 60 Hz
240 VAC, 1 phase, 60 Hz (24kW only)
Startup inspection service by factory autorized service agent
One year parts and labor warranty*
* For all international markets, contact your local distributor
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: (800) 331-5842 • Phone: (802) 860-3700 • Fax: (802) 864-0183
BLODGETT
www.blodgett.com
