OWner'S MAnuAl
Industrial
Please write model number here for future reference:
7205635
SAA-Industrial-Australia-WH18
net Weight:
5.7 KGS
240V~50Hz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7205635 and is the answer not in the manual?

Questions and answers

Related Manuals for Westinghouse 7205635

Summary of Contents for Westinghouse 7205635

  • Page 1 SAA-Industrial-Australia-WH18 OWner'S MAnuAl Industrial Please write model number here for future reference: 7205635 net Weight: 5.7 KGS 240V~50Hz...

  • Page 2: Safety Tips

    SAA-Industrial-Australia-WH18 SAfETy TIpS READ AND SAVE THESE INSTRUCTIONS WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: 1. Proceed with caution. Read all instructions before beginning the installation. 2. Only an authorized electrician should execute the installation. 3.

  • Page 3: Installation

    SAA-Industrial-Australia-WH18 Features DOWNROD VAULTED CEILING INSTALLATION INSTALLATION For normal ceilings May require a longer downrod (sold separately)

  • Page 4: Preparing For Installation

    SAA-Industrial-Australia-WH18 PrePArInG fOr InStAllAtIOn Use metal outlet box suitable for fan support (must support 35 lbs). Before attaching fan to outlet box, ensure the outlet box is securely fastened by at least two points to a structural ceiling member (a loose Unpack and inspect fan carefully to be certain all contents are included.

  • Page 5: Mounting Bracket Installation

    SAA-Industrial-Australia-WH18 WIrInG OPtIOnS MOuntInG brACKet InStAllAtIOn Wiring: TERMINAL BLOCK From House: Connector: Fan Live (L) Neutral (N) Ground Follow diagram above to make wiring connections to the terminal block on the mounting bracket. Remove the screws (1) from the bracket as shown above. Loosen (do not remove) the screws (2) from the bracket as shown above.
  • Page 6 SAA-Industrial-Australia-WH18 MOuntInG Carefully lift fan assembly onto mounting bracket. Rotate fan until notch With bracket holding fan assembly, attach the male/female plug connection (1) from on downrod ball (1) engages the ridge on the mounting bracket (2). This will allow for hands free wiring. the fan to the terminal block.
  • Page 7 SAA-Industrial-Australia-WH18 SeCure tO CeIlInG For downrod fans, slide the canopy up to the mounting bracket. The canopy has two mating slots (1) and two mating holes (2). Position both slots on canopy directly under and in line with two screws in the mounting bracket (3). Lift the canopy, allowing the two screws to slide into the mating slots.

  • Page 8: Blade Installation

    SAA-Industrial-Australia-WH18 blAde InStAllAtIOn Install blades to top of motor using screws and washers. See above drawing for reference.

  • Page 9: Wall Control Installation

    SAA-Industrial-Australia-WH18 WAll COntrOl InStAllAtIOn Remove the front cover of the wall control by unsnapping the cover (1) from the control unit (2).
  • Page 10 SAA-Industrial-Australia-WH18 WIrInG tO tHe WAll COntrOl Connect the fan control wire from the fan to the terminal block on the wire marked “For fan-L”, as line art shown on “1”; Connect the 240V hot house wire to the terminal block on the wire marked “TO AC-L240V/50HZ”, as line art shown on “2”.
  • Page 11 SAA-Industrial-Australia-WH18 OPerAtIOn WAll COntrOl InStAll WAll COntrOl tO Outlet bOx Operation: Fan Rotary Control OFF - Fan Speed OFF 3 - Fan Speed HIGH 2 - Fan Speed MEDIUM 1 - Fan Speed LOW When wiring is complete, make sure no bare wires are exposed from the terminal connections on the back of the fan control unit.
  • Page 12 SAA-Industrial-Australia-WH18 InStAll WAll COntrOl tO Outlet bOx Replace the front cover of the wall control unit by snapping the cover (1) onto the control unit (2).

  • Page 13: Operation And Maintenance

    SAA-Industrial-Australia-WH18 OPerAtIOn And MAIntenAnCe Operation Turn on the power and check operation of fan. The wall control controls the fan speeds as follows: 1 - fan speed low; 2 - fan speed medium; 3 - fan speed high; OFF - fan speed off. Speed settings for warm or cool weather depend on factors such as room size, ceiling height, number of fans and so on.

  • Page 14: Troubleshooting Guide

    SAA-Industrial-Australia-WH18 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these trOubleSHOOtInG GuIde installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, please consult with a qualified electrician and do not attempt any electrical repairs yourself.

  • Page 15: Parts List

    SAA-Industrial-Australia-WH18 PArtS lISt description 1 ..... . Mounting Bracket 2 ..... . Blade 3 .
  • Page 16 SAA-Industrial-Australia-WH18 Westinghouse Lighting, Philadelphia, PA 1029-19154, U.S.A. www.westinghouselighting.com , WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF are trademarks of Westinghouse Electric Corporation. Used under license by Westinghouse Lighting All rights reserved. AS/NZS Approval No. SAA-181731-EA Made in China...
