- Page 1 ETL-ES-Carolina LED-WH21 OWNER'S MANUAL MANUAL DEL USUARIO Carolina LED Please write model number here for future reference: / Por favor, incluya el número del modelo aquí para futura referencia: Net Weight: 17.05 LBS Peso Neto: 7.75 KGS...
-
Page 2: Safety Tips
ETL-ES-Carolina LED-WH21 SAFETY TIPS OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY, MOUNT TO OUTLET BOX MARKED 'ACCEPTABLE FOR FAN SUPPORT OF 35 LBS (15.9 KG) OR LESS' AND USE MOUNTING SCREWS PROVIDED WITH THE OUTLET BOX AND/OR SUPPORT DIRECTLY FROM BUILDING STRUCTURE. -
Page 3: Consejos De Seguridad
ETL-ES-Carolina LED-WH21 CONSEJOS DE SEGURIDAD HAGA LO SIGUIENTE: LEA Y GUARDE ESTAS INSTRUCCIONES ADVERTENCIA: PARA REDUCIR EL RIESGO DE INCENDIO, DESCARGA ELÉCTRICA O HERIDAS GRAVES PERSONALES, MONTE EN UNA CAJA DE EMBUTIR ROTULADA “ADECUADA PARA VENTILADORES DE 35 LB (15,9 KG) O MENOS”... - Page 4 ETL-ES-Carolina LED-WH21 FEATURES CARACTERÍSTICAS COMBO-BLADE Combo-Blades feature two high quality finishes on one blade. Select the one that best complements your decor, or change the style with just a flip of the blade. NOTE: Combo-Blade finishes vary, depending upon model. ALETAS DE DOBLE CARA Las aleta del rotor de doble cara presentan dos superficies con un acabado de alta calidad.
- Page 5 ETL-ES-Carolina LED-WH21 PREPARING FOR INSTALLATION ANTES DE LA INSTALACIÓN Use metal outlet box suitable for fan support (must support 35 lbs). Before attaching fan to outlet box, ensure the outlet box is securely fastened by at least two points to a structural ceiling member (a loose box will cause the fan to wobble).
- Page 6 ETL-ES-Carolina LED-WH21 MOUNTING BRACKET INSTALLATION INSTALACIÓN CON SOPORTE DE MONTAJE Remove the screws and star washers (1) from the bracket as shown above. Remove pre-installed screws from motor bracket and mounting plate. Hang Loosen (do not remove) the screws (2) from the bracket as shown above. fan from mounting plate by inserting "T"-shaped end of bracket into slot Install mounting bracket to outlet box in ceiling using the screws and washers pro- opening of mounting plate.
- Page 7 ETL-ES-Carolina LED-WH21 MOUNTING MONTAJE While fan is hanging from the mounting plate, connect the wires with wire connectors (included), using the following steps for wiring options. Mientras el ventilador está colgado de la placa de montaje, conecte los cables con los conectores para cables (incluidos) usando los siguientes pasos para opciones de cableado.
- Page 8 ETL-ES-Carolina LED-WH21 WIRING OPTIONS OPCIÓN DE CABLEADO WALL CONTROL WIRING OPTION PULL CHAIN WIRING OPTION *Connect blue wire only if attaching light kit with fan. *Connect blue wire only if attaching light kit with fan. Follow diagram above to make wiring connections for fan pull chain control. Follow diagram above to make wiring connections for wall control operation.
- Page 9 ETL-ES-Carolina LED-WH21 MOUNTING MONTAJE The decorative motor housing has two mating slots (1) and two mating holes (2). Position both slots on the motor housing directly under and in line with two screws in the mounting bracket (3). Lift the motor housing, allowing the two screws to slide into the mating slots.
- Page 10 ETL-ES-Carolina LED-WH21 BLADE INSTALLATION INSTALACIÓN DE LAS ALETAS Check the motor for plastic shipping stabilizer tabs (1), and remove them if they are pres- ent. Attach blade assembly to motor using the noise-dampening motor gaskets (2) and Attach blade brackets to blades using the blade bracket screws (1), metal motor screws provided.
- Page 11 ETL-ES-Carolina LED-WH21 LIGHT FIXTURE INSTALLATION INSTALACIÓN DEL ARTEFACTO LUMINOSO Remove the three pre-installed screws from the ceiling fan's light kit and save for later use. Find the wire plugs from the light kit and from the motor and slide together. Connect the blue wire from the switch housing, to the black wire from the light kit, and the white wire from the switch housing to the white wire from the light kit.
- Page 12 ETL-ES-Carolina LED-WH21 LIGHT FIXTURE INSTALLATION INSTALACIÓN DEL ARTEFACTO LUMINOSO Unscrew and remove the finial (1), decorative cap (2), nut (3), and rubber/metal washer (4) from the bottom of the light kit. Install the bulbs (included). Desenrosque y quite el florón (1), la tapa decorativa (2), la tuerca (3) y la arandela de caucho/metal (4) de la parte inferior del juego de luces. Instale las bombillas de luz (incluidas).
- Page 13 ETL-ES-Carolina LED-WH21 Install the glass (5) onto the light kit and tighten the washer (4) and nut (3) onto the bottom of glass. Make sure the ceiling fan pull chain is threaded through the side hole in the bottom of the glass. Place decorative cap (2) over the bottom of glass and secure by tightening decorative finial (1). Note: (6) Make sure the side hole on the decorative cap lines up with the side hole on the bottom of the glass so that the fan pull chain operates smoothly.
- Page 14 ETL-ES-Carolina LED-WH21 Assemble decorative fob and extension chains from hardware bag to fan pull chains by inserting end of chain into chain coupling. Confirm chains are held by lightly pulling both chains in coupling. Sujeta las cadenillas largas de tiro con las piezas finales correspondientes, a las cadenillas del ventilador, introduciendo el extremo de la cadenilla larga en la pieza de unión. Asegúrese de que las cadenillas están bien sujetas, tirando ligeramente de ambas cadenillas en la pieza de unión.
-
Page 15: Operation And Maintenance
ETL-ES-Carolina LED-WH21 OPERATION AND MAINTENANCE Operation Turn on the power and check operation of fan. The pull chain controls the fan speeds as follows: 1 pull - high; 2 pulls - medium; 3 pulls - low; 4 pulls - off. Speed settings for warm or cool weather depend on factors such as room size, ceiling height, number of fans and so on. -
Page 16: Operación Y Mantenimiento
ETL-ES-Carolina LED -WH21 OPERACIÓN Y MANTENIMIENTO Operación Encienda el ventilador y verifique su funcionamiento. La cadenilla de tiro controla las velocidades del ventilador de la siguiente manera: 1 jalón – rápida; 2 jalones - mediana; 3 jalones - lenta; 4 jalones - apagado. Las velocidades para clima cálido o frío dependen de factores como el tamaño de la habitación, la altura del ventilador, el número de ventiladores, etc. -
Page 17: Troubleshooting Guide
ETL-ES-Carolina LED -WH21 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or TROUBLESHOOTING GUIDE wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. - Page 18 ETL-ES-Carolina LED-WH21 Si tiene dificultades para hacer funcionar su nuevo ventilador, podría ser a causa del armado, GUÍA PARA SOLUCIONAR PROBLEMAS instalación o cableado incorrectos. En algunos casos, estos errores de instalación podrían ser confundidos con defectos. Si experiencia algun fallo, consulte esta guía para solucionar problemas.
-
Page 19: Warranty
If replacement product is not available through seller, please contact www.westinghouselighting.com/contact-us. GARANTÍA Este ventilador de Westinghouse Lighting se ofrece con una garantía limitada de por vida para el propietario original frente a defectos de material y de mano de obra. Esta garantía sustituye cualquier otra garantía expresa o implícita. - Page 20 ETL-ES-Carolina LED-WH21 PARTS LIST LISTA DE REPUESTOS Description 1 ....Mounting Bracket 2 ....Blade Bracket 3 .
- Page 21 ETL-ES-Carolina LED-WH21...
- Page 22 ETL-ES-Carolina LED-WH21...
- Page 23 ETL-ES-Carolina LED-WH21...
- Page 24 ETL-ES-Carolina LED-WH21 Westinghouse Lighting, Philadelphia, PA 19154-1029, U.S.A. www.westinghouselighting.com and Westinghouse are trademarks of Westinghouse Electric Corporation. Used under license by Westinghouse Lighting. All Rights Reserved. Made in China...
