Summary of Contents for Aus Electronics Direct AA6232
- Page 1 User Manual USB 2.0 HDMI Video Capturer Model No. AA6232...
-
Page 2: Connection And Operation
FEATURES: HDMI Input port USB2.0 Male Connector Connect to HDMI source with HDMI cable Plug into USB port Connection and Operation: 1. Connection diagram Video Player HD camera HDMI Cable Capturer Portable Equipment Game Machine... -
Page 3: Pc Hardware Requirements
2. PC hardware requirements Hardware Recommended Specifications PC i5-3400 or above NB i7-3537U 2.0GHZ or above Memory DDR3 4G or above PC NVIDIA GT630 or above Graphics card NB NVIDIA GT735M or above Hard disk 500G or above，SSD recommended 3. PC side system & software requirements Type Recommended version Windows XP/7/8/10... - Page 4 【 】 Ⅱ. Open the OBS software and click the button in the "Sources" control panel to add a video capture device. 【 】 Ⅲ. Select the capture device to preview the capture screen normally. Then click HDSW0031M1...
- Page 5 Ⅳ. Drag the red border to resize the capture screen. Ⅴ. 【 】 Click Settings button on the lower right corner to enter the setting interface to set audio & video format, 【 】 picture quality, output etc. After setting, click Start Recording button.
-
Page 6: Specifications
SPECIFICATIONS: Model No. HDCN0051M1 Model name HD-Video Capturer Input ports HDMI1.4 x1 Output ports USB2.0 x1 3840x2160@30Hz or 4096x2160@24Hz Max HDMI input resolution Support 3840x2160@60Hz YUV420 Input color space RGB、YUV444、YUV422、YUV420 Video output resolution 1920x1080@30Hz Max Video output format YUV or JPEG Audio format LPCM2.0/32~192KHz/16~24Bit AWG 26 HDMI standard cable ≤10m...
