IEMCA VIP80 Evolution Manual For Use And Maintenance

Automatic bar feeder
Hide thumbs

Advertisement

Quick Links

AUTOMATIC BAR FEEDER
GB
Rel. 1
S/N
MANUAL FOR USE AND MAINTENANCE
KEYBOARD INSTRUCTION MANUAL
SPARE PARTS BOOK
SCHEMATICS
EC CONFORMITY DECLARATION FOR MACHINE
VIP80 Evolution
VIP80r Evolution
MANUAL FOR USE AND MAINTENANCE
Date
21/10/02
COMPILER:
Ragazzini Gian Luca
ON APPROVAL:
ATTACHMENTS LIST
Cod.
806005400
Bevini Claudio

Advertisement

loading

Related Manuals for IEMCA VIP80 Evolution

Summary of Contents for IEMCA VIP80 Evolution

  • Page 1 AUTOMATIC BAR FEEDER ATTACHMENTS LIST MANUAL FOR USE AND MAINTENANCE KEYBOARD INSTRUCTION MANUAL SPARE PARTS BOOK SCHEMATICS EC CONFORMITY DECLARATION FOR MACHINE VIP80 Evolution VIP80r Evolution MANUAL FOR USE AND MAINTENANCE Rel. 1 Date 21/10/02 Cod. 806005400 COMPILER: Ragazzini Gian Luca...
  • Page 3 MANUFACTURER: IEMCA division of IGMI S.p.A. ADDRESS: Via Granarolo, 167 - 48018 Faenza (RA) - ITALY Tel. 0546/698000 - Fax. 0546/46338 - 0546/46224 TLX 550879 TYPE OF DOCUMENT: MANUAL FOR USE AND MAINTENANCE PRODUCT: AUTOMATIC BAR FEEDER MODEL: VIP80 Evolution VIP80r Evolution IEMCA S.p.A.

  • Page 5: Table Of Contents

    GENERAL INFORMATION ................VIP80E TECHNICAL INFORMATION ................VIP80E SAFETY PROCEDURES - GENERAL INFORMATION ........VIP80E HANDLING AND INSTALLATION..............VIP80E ADJUSTMENTS AND SETTING-UP ..............VIP80E USE AND OPERATION................... VIP80E BAR FEEDER MAINTENANCE ................ VIP80E TROUBLES - CAUSES - CURES............... VIP80E PART REPLACEMENT ..................VIP80E LIST OF AFTER-SALES CENTERS...
  • Page 7 1 - GENERAL INFORMATION VIP80E INDEX TERMS OF WARRANTY ...................2 MANUAL PURPOSE ....................2 MANUFACTURER AND BAR FEEDER IDENTIFICATION..........3 INSTRUCTIONS APPLICATION FOR SERVICE............4 GLOSSARY AND TERMINOLOGY ................4 ANNEXED LITERATURE ..................4 1 - Pag. 1 / 4...
  • Page 8 Certificate duly filled in and signed. The document must be sent per mail to: CUSTOMER SERVICE IEMCA division of IGMI spa 48018 Faenza (Ra) ITALY - Via Granarolo,167 MANUAL PURPOSE This manual, which is an integral part of the bar feeder, has been carried out by the manufacturer in order to provide all necessary information for those who are authorised to interact with it.
  • Page 9 1 - GENERAL INFORMATION VIP80E The manufacturer reserves the right to make any changes without the obligation to notify them in advance. In order to underline some very important parts of the text or to indicate some important specifications, some symbols have been adopted. Their meaning is described below. DANGER - WARNING: indicates some situations of great danger that, if neglected, can seriously put the health and safety of people at risk.
  • Page 10 1 - GENERAL INFORMATION VIP80E INSTRUCTIONS APPLICATION FOR SERVICE For any need apply to an authorised service centre. For any application for technical service concerning the bar feeder, indicate the data inserted on the nameplate, the approximate hours of use and the kind of defect found. GLOSSARY AND TERMINOLOGY Some recurrent words present in the manual are here described in order to provide a more complete understanding of their meaning.
  • Page 11 2 - TECHNICAL INFORMATION VIP80E INDEX BAR FEEDER GENERAL DESCRIPTION ..............2 2.1.1 MAIN COMPONENTS ....................3 OPERATING CYCLE ....................4 SAFETY DEVICES ....................7 SAFETY AND INFORMATION SIGNALS ..............8 2.4.1 BAR FEEDER DIMENSIONS ..................9 2.4.2 Noise levels ......................9 TECHNICAL DATA AND PERIMETRAL AREAS ............10 EQUIPMENT DESCPRIPTION (optional) ..............13 2 - Pag.
  • Page 12 2 - TECHNICAL INFORMATION VIP80E BAR FEEDER GENERAL DESCRIPTION The bar feeder in question has been planned and manufactured in order to automatically feed the bars to be turned on the lathe. It has been manufactured in two versions: VIP 80 E (standard version - the lathe on the right of the bar feeder) VIP 80r E (reversed version - the lathe on the left of the bar feeder) The figure represents the two versions.
  • Page 13 2 - TECHNICAL INFORMATION VIP80E 2.1.1 MAIN COMPONENTS A Magazine; contains the bars to be loaded. B Sorter unit; lifts the first bar, from the magazine, and unloads it on the "bar drop control device". C "Limit stop" device; correctly positions the first bar, within the magazine, before it is lifted by the bar selector unit.
  • Page 14 2 - TECHNICAL INFORMATION VIP80E OPERATING CYCLE Below are represented and described the phases of the bar feeder operating cycle. At the stop of the lathe operating cycle, the bar pusher (A) moves back to the limit stop position. The bar pusher (A) and the "bar drop control"...
  • Page 15 2 - TECHNICAL INFORMATION VIP80E The "bar drop control" unit (B) returns to its initial position enabling bar insertion into the guide (D). At the same time, the bar selector unit (C) returns to its initial position. Subsequently, the guide lifts and sets the bar in line with the loading axis.
  • Page 16 2 - TECHNICAL INFORMATION VIP80E The bar pusher (A) inserts the bar into the spindle liner. The bar ejects the remnant (F) as a residual of the previous machining, and is positioned for the facing. The lathe operating cycle starts with the beginning of the facing phase.
  • Page 17 2 - TECHNICAL INFORMATION VIP80E SAFETY DEVICES The figure indicates the position of the devices on the bar feeder. A- Interlocked sliding guard: is associated with an interlock device (microswitch A1). At the opening of the guard, in emergency condition, all the bar feeder and lathe functions stop. At the closing of the guard it is possible to start the operating cycle again.
  • Page 18 2 - TECHNICAL INFORMATION VIP80E SAFETY AND INFORMATION SIGNALS The figure indicates the position of the signals put on the bar feeder. A- Danger of crushing upper limbs: do not put hands inside when there are components in motion. B- No guard removal: it is forbidden to use the bar feeder without the guards installed and in operating conditions.
  • Page 19 2 - TECHNICAL INFORMATION VIP80E 2.4.1 BAR FEEDER DIMENSIONS BAR LOADING AREA WORK AREA 2.4.2 Noise levels During the machining, the bar feeder is not noisy. The only phase where there can be some short-lasting peaks (85 dbA), is the bar loading one. This measurement has been made in conformity with the regulation in force.
  • Page 20 2 - TECHNICAL INFORMATION VIP80E TECHNICAL DATA AND PERIMETRAL AREAS Technical data table VIP 80 E Bar min. diameter Ø 5 mm Bar max. diameter Ø 80 mm Bar min. length 250 mm Bar max. length 1615 mm Magazine capacity n.60 Bars Ø...

  • Page 21: Technical Information

    2 - TECHNICAL INFORMATION VIP80E Loading axis height table X - Loading axis Screw position height Threaded holes on the Slots on the supports base 900÷937 1 - 3 938÷969 2 - 4 970÷1007 1008÷1039 3 - 5 1040÷1077 1078÷1109 4 - 6 1110÷1147 1148÷1179...
  • Page 22 2 - TECHNICAL INFORMATION VIP80E Bar and bar pusher diameters table ø A - Bar diameter Ø B - Bar pusher ø C - Bar pusher (mm) diameter (mm) bearing diameter (mm) 5÷12 10÷19 16÷80 2 - Pag. 12 / 14...
  • Page 23 2 - TECHNICAL INFORMATION VIP80E EQUIPMENT DESCPRIPTION (optional) In order to increase the performances and the versatility of the bar feeder, the manufacturer puts the equipment indicated below at the customer's disposal. Bar feeder-lathe guide: directs the bar in the section between the bar feeder and the lathe.
  • Page 24 2 - TECHNICAL INFORMATION VIP80E Loading axis height table X - Loading axis Screw position height Threaded holes on the Slots on the supports base 930÷967 1 - 3 968÷999 2 - 4 1000÷1037 1038÷1069 3 - 5 1070÷1107 1108÷1139 4 - 6 1145÷1177 1178÷1209...
  • Page 25 3 - SAFETY PROCEDURES - GENERAL INFORMATION VIP80E INDEX GENERAL SAFETY PRESCRIPTIONS .................2 HANDLING AND INSTALLATION - Safety..............3 ADJUSTMENTS AND SETTING UP - Safety..............3 USE AND OPERATION - Safety ................4 BAR FEEDER MAINTENANCE - Safety...............4 3 - Pag. 1 / 4...
  • Page 26 Comply strictly with the work health and safety regulations issued by the relevant authorities in the country of installation of the machine. • IEMCA declines any liability whatsoever for injury to persons or damage to property if the relevant safety prescriptions are disregarded. 3 - Pag. 2 / 4...

  • Page 27: Handling And Installation

    3 - SAFETY PROCEDURES - GENERAL INFORMATION VIP80E HANDLING AND INSTALLATION - Safety • The bar feeder must be handled using suitable means and methods. • Persons must not stand or transit underneath a suspended load, or within the range of action of the crane, lift truck or other suitable means of lifting and transportation.

  • Page 28: Use And Operation

    Keep spent oil in suitable containers and consign it to companies specialized in the storage and disposal of polluting waste products. • Do not pollute the environment. • Use original IEMCA spare parts only. 3 - Pag. 4 / 4...
  • Page 29 4 - HANDLING AND INSTALLATION VIP80E INDEX PRELIMINARY NOTE ON MOTION AND INSTALLATION ........2 PACKAGING AND UNPACKAGING ..............2 TRANSPORT ....................3 MOTION AND LIFLTING ...................3 BAR FEEDER INSTALLATION (without displacement) ..........4 INSTALLATION PHASES ...................4 4.6.1 Loading axis height variation...................5 4.6.2 Assembling the backing plates.................5 4.6.3 Magazine positioning ....................6 4.6.4...
  • Page 30 4 - HANDLING AND INSTALLATION VIP80E PRELIMINARY NOTE ON MOTION AND INSTALLATION IMPORTANT: move and install the machine-tool by respecting the information provided by the manufacturer, which are directly written on the package, bar feeder and in the operation instructions. The person who is authorised to carry out these operations shall prepare, if necessary, a "safety plan"...
  • Page 31 4 - HANDLING AND INSTALLATION VIP80E TRANSPORT The transport can be carried out by different means, according to the destination. The diagram represents the most used solutions. In the transport phase, in order to avoid untimely movements, provide an adequate anchorage to the means of transport.
  • Page 32 4 - HANDLING AND INSTALLATION VIP80E BAR FEEDER INSTALLATION (without displacement) WARNING - CAUTION: installation and connections must be carried out according to the indications provided by the manufacturer. The responsible person will also take into account all regulative and law requirements, carrying out all the installations and connections workmanlike.
  • Page 33 4 - HANDLING AND INSTALLATION VIP80E 4.6.1 Loading axis height variation The bar feeder is generally supplied with the loading axis height aligned to that of lathe spindle. If you need to change it, proceed as follows: • Prepare the bar feeder to be lifted (sect. 4.4.). •...
  • Page 34 4 - HANDLING AND INSTALLATION VIP80E 4.6.3 Magazine positioning For the positioning proceed as follows. • Lift the magazine with the help of a lifting device. Check that during the lifting, the pin (B) is correctly inserted into the cam seat (C).
  • Page 35 4 - HANDLING AND INSTALLATION VIP80E 4 - Pag. 7 / 21...
  • Page 36 4 - HANDLING AND INSTALLATION VIP80E • Remove the safety brackets (L) and keep them for future removal. • Install the bar feeder-lathe guide (if provided). • Install the safety grid (fixed guard). 4 - Pag. 8 / 21...
  • Page 37 4 - HANDLING AND INSTALLATION VIP80E 4.6.4 Alignment and levelling IMPORTANT: only alignment levelling are fundamental for the correct running of the bar feeder and for the WARRANTY VALIDITY, but also they must be carried only SKILLED STAFF WITH PRECISE TECHNICAL COMPETENCE.
  • Page 38 4 - HANDLING AND INSTALLATION VIP80E • Adjust the loading axis vertically through screws (D). This adjustment can also be carried out by means of the screws (E), after loosening the screws (F). • Hit both sides of the plates (G) with a mallet for the adjustment of the loading axis horizontally.
  • Page 39 4 - HANDLING AND INSTALLATION VIP80E 4.6.5 Bar feeder fastening IMPORTANT: considering that this operation is vital to assure in time the bar feeder stability and the WARRANTY VALIDITY, the person who is authorised to carry it out, will have to take extreme care of it. For the fastening proceed as follows.
  • Page 40 4 - HANDLING AND INSTALLATION VIP80E BAR FEEDER INSTALLATION (with displacement) WARNING - CAUTION: the installation and connections must be carried out according to the indications provided by the manufacturer. The responsible person will also take into account all regulative and law requirements, carrying out all the installations and connections workmanlike.
  • Page 41 4 - HANDLING AND INSTALLATION VIP80E INSTALLATION PHASES Below are listed the installation steps. For further details see the relating sections. Loading axis height variation (section 4.8.1) Magazine positioning (section 4.8.2) Alignment and levelling (section 4.8.3) Bar feeder fastening (section 4.8.4) 4.8.1 Loading axis height variation The bar feeder is generally supplied with the...
  • Page 42 4 - HANDLING AND INSTALLATION VIP80E 4.8.2 Magazine positioning For the positioning proceed as follows. • Lift the magazine with the help of a lifting device. Check that during the lifting, the pin (B) is correctly inserted into the cam seat (C).
  • Page 43 4 - HANDLING AND INSTALLATION VIP80E 4 - Pag. 15 / 21...
  • Page 44 4 - HANDLING AND INSTALLATION VIP80E • Remove the safety brackets (L) and keep them for future removal. • Install the bar feeder-lathe guide (if provided). • Install the safety grid (fixed guard). 4 - Pag. 16 / 21...
  • Page 45 4 - HANDLING AND INSTALLATION VIP80E 4.8.3 Alignment and levelling IMPORTANT: not only alignment and levelling are fundamental for the correct running of the bar feeder and for the WARRANTY VALIDITY, but also they must be carried out only by a SKILLED STAFF WITH PRECISE TECHNICAL COMPETENCE. For these operations proceed as follows.
  • Page 46 4 - HANDLING AND INSTALLATION VIP80E Remove two sections (E) from the guide channel in order to use the beam plane to check the levelling Verify the alignment of both bar feeder axes and levelling. Adjust the loading axis vertically through screws (B).
  • Page 47 4 - HANDLING AND INSTALLATION VIP80E 4.8.4 Bar feeder fastening IMPORTANT: considering that this operation is fundamental to assure in time the bar feeder stability WARRANTY VALIDITY, the person who is authorised to carry it out, will have to take extreme care of it. For the fastening proceed as follows: Put the two remaining plates (A)
  • Page 48 4 - HANDLING AND INSTALLATION VIP80E Note: the manufacturer recommends to fasten the bar feeder to the lathe by means of the appropriate kit in the figure. The figure has a merely indicative purpose; for further details contact a service centre (see service centre list).
  • Page 49 4 - HANDLING AND INSTALLATION VIP80E CONNECTION TO THE POWER SUPPLY IMPORTANT: the connections to the power supply must be carried out following the indications on the wiring diagram provided by the manufacturer. The person who is authorised to carry out this operation, shall have special skills and experience acquired and recognised in the specific area.
  • Page 51 5 - ADJUSTMENTS AND SETTING-UP VIP80E INDEX PRELIMINARY NOTE ON ADJUSTMENT ..............2 MAGAZINE ADJUSTMENT..................2 LOADING AXIS ADJUSTMENT..................3 BAR FEEDER-LATHE GUIDE ADJUSTMENT ...............4 FEED BELT ADJUSTMENT ..................5 5 - Pag. 1 / 5...
  • Page 52 5 - ADJUSTMENTS AND SETTING-UP VIP80E PRELIMINARY NOTE ON ADJUSTMENT IMPORTANT: Before carrying out any adjustment, start all safety devices provided and check if it is necessary to inform the staff operating around and people close to the area. In particular, it is recommended to adequately signal the adjacent areas and to prevent anyone from approaching all the devices that, if started, could cause unexpected damages and harm to people.
  • Page 53 5 - ADJUSTMENTS AND SETTING-UP VIP80E Loosen the knobs (D), adjust the frame (E) at about 1- 2 mm from the bars (see figure) and tighten the knobs. LOADING AXIS ADJUSTMENT The adjustment has to be carried out according to the diameter of the barstock.
  • Page 54 5 - ADJUSTMENTS AND SETTING-UP VIP80E BAR FEEDER-LATHE GUIDE ADJUSTMENT The adjustment must be carried out according to the diameter of the bar pusher and barstock bearings. Adjust the guide height, displayed on the graduated rod (A), in order to respect the values reported in the table.
  • Page 55 5 - ADJUSTMENTS AND SETTING-UP VIP80E FEED BELT ADJUSTMENT For the adjustment proceed as follows: Open the upper carter. To check the belt tension, adopt the method indicated in the figure. The resutling value (C) must be 10 to 15 mm. Loosen the nut (A).
  • Page 57 6 - USE AND OPERATION VIP80E INDEX PRELIMINARY NOTE ON USE AND OPERATION ............2 CONTROL DESCRIPTION ..................2 KEYBOARD MANUAL CONTROLS DESCRIPTION............4 LUMINOUS SIGNAL DESCRIPTION................7 BAR PREPARATION (sections and tubes)..............7 MAGAZINE LOADING....................8 BAR FEEDER TOOLING ...................8 BAR PUSHER CHANGE ....................9 LATHE SPINDLE LINER CHANGE ................9 6.10 AUTOMATIC CYCLE START ...................11 6.11...
  • Page 58 6 - USE AND OPERATION VIP80E PRELIMINARY NOTE ON USE AND OPERATION IMPORTANT: the incidence of injuries cased by the use of machines, depends on many factors that cannot always be prevented and checked. Some accidents can depend on some unpreventable environmental factors, others can be especially due to the operators' behaviours.
  • Page 59 6 - USE AND OPERATION VIP80E A -Main switch; for switching power supply on and off. - 0 (OFF) power off. - I (ON) power on. B -Emergency stop push-button; stops the bar feeder in case of emergency. For restart release the push-button manually.
  • Page 60 6 - USE AND OPERATION VIP80E KEYBOARD MANUAL CONTROLS DESCRIPTION 1 - Start push-buttons; opposite push-buttons enabling the keys for some functions. Press both push-buttons and the key for the function to be selected simultaneously. 2 - It selects the keyboard modes; - position A;...
  • Page 61 6 - USE AND OPERATION VIP80E 12 - It lifts the bar pusher, bar drop control devices and selector units. It can be activated only after enabling the start push-buttons (1) (keep them pressed). Release when led signalling that the movement ended lights up. 13 - It lifts the guide channel unit and lowers the bar drop control devices and selectors units.
  • Page 62 6 - USE AND OPERATION VIP80E 22 - Multifunction key - Sets the numerical value. - Sets the carriage motor. This function must never be used in bar feeder everyday operation. 23 - It sets the numerical value. 24 - It sets the numerical value. 25 - Multifunction key - Sets the numerical value.
  • Page 63 6 - USE AND OPERATION VIP80E LUMINOUS SIGNAL DESCRIPTION Red light ; signals that the bar feeder is in stop mode, or that it is in manual mode. Green light; signals that the bar feeder is in automatic mode. Blue light; signals that the bar feeder is carrying out the bar change.
  • Page 64 6 - USE AND OPERATION VIP80E MAGAZINE LOADING WARNING - CAUTION: magazine loading must be carried using only personal safety garments and, necessary, appropriate means. person who is authorised carry these operations will have prepare necessary conditions safeguard himself and those who are directly involved them.It...
  • Page 65 6 - USE AND OPERATION VIP80E BAR PUSHER CHANGE For this operation, proceed as follows. Open the top cover. Adjust screw (A) and lock nut in order to uncouple the bar pusher rear end. Disassemble the bushing (B) in order to uncouple the bar pusher fore end.
  • Page 66 6 - USE AND OPERATION VIP80E Press the key (3) to select the manual mode. Press the start buttons (1) and the key (11) at the same time in order to lift the guide and the bar pusher units. Press the emergency stop key in order to stop the bar feeder in safety conditions.
  • Page 67 6 - USE AND OPERATION VIP80E 6.10 AUTOMATIC CYCLE START For this operation proceed as follows. Connect the lathe power supply. Rotate the bar feeder main switch in I (ON) position to connect the power supply. Press the pushbutton (C) on board the machine to start the bar feeder.
  • Page 68 6 - USE AND OPERATION VIP80E 6.11 ORDINARY STOP To stop the end working proceed as follows. IMPORTANT: for ordinary stop do not use emergency pushbuttons. Wait for workpiece machining and automatic cycle end. Press the pushbutton (D) on board the machine to stop the bar feeder.
  • Page 69 6 - USE AND OPERATION VIP80E 6.13 STEP-BY-STEP" CYCLE In order to check the bar feeder general running conditions, it may be necessary to carry out a "step-by-step" cycle. For this operation, proceed as follows. Press the pushbutton (C) on board the machine to start the bar feeder.
  • Page 71 7 - BAR FEEDER MAINTENANCE VIP80E INDEX PRELIMINARY NOTE ON MAINTENANCE ..............2 SCHEDULED MAINTENANCE ...................2 REVOLVING TIP CHECK ..................3 GREASING POINTS ....................3 DISPLACEMENT DEVICE USE ..................5 7 - Pag. 1 / 5...
  • Page 72 7 - BAR FEEDER MAINTENANCE VIP80E PRELIMINARY NOTE ON MAINTENANCE IMPORTANT: Before carrying out any maintenance, start all safety devices provided and check if it is necessary to inform the staff operating around and people close to the area. In particular, it is recommended to adequately signal the adjacent areas and to prevent anyone from approaching all the devices that, if started, could cause unexpected damages and harm to people.
  • Page 73 7 - BAR FEEDER MAINTENANCE VIP80E REVOLVING TIP CHECK For checking proceed as follows: Disassemble the bar pusher, (see section 6.8.). Check that the push-rod (A) and the bearings (B), of the revolving tip, move freely and without any excessive play. If need be, replace the revolving tip (see section 9.2.).
  • Page 74 7 - BAR FEEDER MAINTENANCE VIP80E Grease Grease 7 - Pag. 4 / 5...
  • Page 75 7 - BAR FEEDER MAINTENANCE VIP80E DISPLACEMENT DEVICE USE WARNING - CAUTION: before carrying out this intervention, disconnect the bar feeder power supply. During the intervention take extreme care so as not to damage the connection cables. For this operation proceed as follows.
  • Page 77 8 - TROUBLES - CAUSES - CURES VIP80E INDEX GENERIC TROUBLESHOOTING ................2 BAR MAGAZINE TROUBLESHOOTING ..............2 TROUBLESHOOTING DURING BAR FEEDING ............2 8 - Pag. 1 / 2...

  • Page 78: Troubles - Causes - Cures

    8 - TROUBLES - CAUSES - CURES VIP80E GENERIC TROUBLESHOOTING TROUBLES CAUSES RIMEDIES The bar feeder does not start. Blackout. Check the electrical connection. Open carter. Close the carter. Emergencies on. Disable emergencies. Burnt motor thermal cutout. Reset the thermal cutout with the appropriate pushbuttons.
  • Page 79 9 - PART REPLACEMENT VIP80E INDEX PRELIMINARY NOTE ON PARTS REPLACEMENT............2 REVOLVING TIP REPLACEMENT ................2 FEED BELT REPLACEMENT..................3 PLC BATTERY REPLACEMENT..................3 KEYBOARD BATTERY REPLACEMENT ...............4 RECOMMENDED SPARE PARTS................5 BAR FEEDER DISMANTLING..................5 9 - Pag. 1 / 5...
  • Page 80 9 - PART REPLACEMENT VIP80E PRELIMINARY NOTE ON PARTS REPLACEMENT Before carrying out any replacement, start all safety devices provided and check if it is necessary to inform the staff operating around and people close to the area. In particular, it is recommended to adequately signal the adjacent areas and to prevent anyone from approaching all the devices that, if started, could cause unexpected damages and harm to people.
  • Page 81 9 - PART REPLACEMENT VIP80E FEED BELT REPLACEMENT For this operation proceed as follows: Open the top cover. Loosen the nut (B). Loosen the belt through screw (A) and lock nut. Disassemble the plate (C) and replace the belt. Assemble the plate again (C). Adjust the belt tension (see section 5.5.).
  • Page 82 9 - PART REPLACEMENT VIP80E KEYBOARD BATTERY REPLACEMENT Replace battery once a year. IMPORTANT: the non-replacement implies the clock- dater memory erasure. For replacement proceed as follows. Disconnect the power supply. Tighten the six screws and disassemble the cover. Extract the battery (A) and insert the new battery (DURACELL DL2430 type), paying attention not to invert polarities.

  • Page 83: Part Replacement

    9 - PART REPLACEMENT VIP80E RECOMMENDED SPARE PARTS IMPORTANT: replace the too worn parts by using original spare parts. Use only oil and grease recommended by the manufacturer. All the above hints will assure the good performance of the bar feeder as well as its safety. Below are listed the recommended spare parts to have in stock.

  • Page 85: List Of After-Sales Centers

    UK : Fax ++44 1722 421071 Ltd. Estate, Southampton www.kitagawaeurope.com Road SP12NB Salisbury Tel +33 450 896960 IEMCA France Z.I. Des Grands Pres FRANCE: Telefax +33 450 896135 145, Email : rue Louis Armand 74300 Cluses Tel. ++49 02351 / 80521 GERMANY: Hoßfeld GmbH...
  • Page 86 10 - LIST OF AFTER-SALES CENTERS Email: Tel 0086 21 64686020 IGM of China Room 28F, Shanghai CHINA (PRC): Fax 0086 21 64877987 Shiye Apartment No.38, E-mail: North Cao Xi Road,Xu Hui District, Shanghai 200030 China 10 - Pag. 2 / 2...

This manual is also suitable for:

Vip80r evolution
